Settings Tab - Black Box EMERALD DESKVUE User Manual

CHAPTER 3: APPLICATION

3.6 SETTINGS TAB

When the "Settings" tab is selected, the system displays the options to configure the hot keys, audio interface,
system volume, and overlays, as shown in Figure 3-18 below:
Table 3-6 explains the options on the "Global Settings" page.
ITEM
Hot keys
OSD Inactivity Timer
FIGURE 3-18: GLOBAL SETTINGS PAGE
TABLE 3-6. GLOBAL SETTINGS
DESCRIPTION
Select the desired hot key from the drop-down list box. When the DESKVUE is
managed by Boxilla, the hot keys will be configured in the Boxilla web interface.
Set the connection inactivity timer. When no user activity has been executed in
this amount of time, the connection will be disconnected, and the DESKVUE will
show the On Screen Display. Setting to "Never" will not disconnect the sessions.
