CHAPTER 3: APPLICATION
ITEM
TABLE 3-7. TRANSMITTER SETTINGS (CONTINUED)
DESCRIPTION
3. Default – system tuned to maintain visually lossless compression while increasing
the compression level during periods of network congestion to reduce frame loss.
This balances visual quality with frame loss in periods of congestion (for example,.
attempts to reduce/eliminate frame loss).
4. Optimized Bandwidth – system tuned to maintain visually lossless compression
but increased levels of compression level during periods of network congestion to
reduce frame loss. This is optimized towards lower bandwidth during congestion
periods compared to level three.
5. Best Compression – high level of compression to minimize average network
bandwidth. There is no dynamic change to compression levels – always seeking to
reduce bandwidth.
Discovering Transmitters
The DESKVUE can discover transmitters that are on the network when the IP
address is not known. In order to discover a transmitter, first be sure that the
transmitter is connected to the network or directly connected to the DESKVUE using
the Ethernet port closest to the power input. Then click on the "Discover" button
and follow the on-screen directions.
These options are shown below in Figure 3-32:
1.877.877.2269
FIGURE 3-32: TRANSMITTER QUALITY OPTIONS
