5.1.4
Sleep
When you press the sleep button X41, it triggers the module's SLEEP# signal. The system's behavior depends on the ACPI settings of the
Operating System.
Table 34
X41 - Sleep Pinout
Pin
Signal
1
LID_BTN#
2
GND
Connector Type
X41: 2.54 mm pitch, 2x1 pin jumper
5.1.5
Temperature Sensor
The conga-HPC/3.5-Mini features onboard temperature sensor U60 (TI TMP1075N) connected to I2C0 with the address 0x48 - 7-bit (1001 000x).
Copyright © 2024 congatec GmbH
X41
1
2
FMC1m001
40/41
