4

Connectors and Features

Carrier Connector P1 (X1)
Table 4 Connector P1 (X1) Pinout
Pin Row A
A01 VCC
A02 VCC
A03 VCC
A04 VCC
A05 RAPID_SHUTDOWN
A06 FUSA_SPI_ALERT
A07 FUSA_STATUS0
A08 FUSA_STATUS1
A09 PCIe_PERST_IN0#
A10 GND
A11 PCIe_REFCLKIN0-
A12 PCIe_REFCLKIN0+
A13 GND
A14 USB7-
A15 USB7+
A16 GND
A17 USB6-
A18 USB6+
A19 GND
A20 SS23_SDA_AUX-
A21 SS23_SCL_AUX+
A22 GND
A23 SS2_TX-
A24 SS2_TX+
A25 GND
A26 SS2_RX-
A27 SS2_RX+
A28 GND
A29 SS3_TX-
A30 SS3_TX+
A31 GND
A32 SS3_RX-
A33 SS3_RX+
A34 GND
Copyright © 2024 congatec GmbH
Pin Row B
B01 VCC
B02 PWRBTN#
B03 VCC
B04 THERMTRIP#
1 B05 CAN_TX
2 B06 TAMPER# 2
2 B07 PROCHOT# 2
B08 SUS_S3#
2
B09 FUSA_VOLTAGE_ERR#
2
B10 WD_STROBE#
B11 WD_OUT
2
B12 GND
2
B13 USB5-
B14 USB5+
B15 GND
B16 USB4-
B17 USB4+
B18 GND
B19 I2S_LRCLK/SNDW_CLK3/HDA_SYNC
B20 I2S_DOUT/SNDW_DAT3/HDA_SDO
B21 I2S_MCLK/HDA_RST#
B22 I2S_DIN/SNDW_DAT2/HDA_SDI
B23 I2S_CLK/SNDW_CLK2/HDA_BCLK
B24 RSVD 1
B25 USB67_OC#
B26 USB45_OC#
B27 USB23_OC#
B28 USB01_OC#
B29 SML1_CLK
B30 SML1_DAT
B31 PMCALERT#
B32 SML0_CLK
B33 SML0_DAT
B34 USB_PD_ALERT#
Pin Row C
C01 VCC
C02 RSTBTN#
C03 VCC
C04 CARRIER_HOT#
C05 CAN_RX
C06 VIN_PWR_OK
C07 CATERR# 2
C08 SUS_S4_S5#
C09 FUSA_ALERT#
2 2
C10 BATLOW#
C11 FAN_PWMOUT
C12 FAN_TACHIN
C13 GND
C14 USB3-
C15 USB3+
C16 GND
C17 USB2-
C18 USB2+
C19 GND
C20 SNDW_DMIC_CLK1
C21 SNDW_DMIC_DAT1
C22 GND
C23 SNDW_DMIC_CLK0
C24 SNDW_DMIC_DAT0
C25 GND
C26 USB0_LSRX/DDI1_DDC_AUX_SEL
C27 USB1_LSRX
1
C28 USB0_LSTX/DDI1_HPD
C29 USB1_LSTX
1
C30 eDP_HPD
C31 eDP_VDD_EN
C32 eDP_BKLT_EN
C33 eDP_BKLTCTL
C34 GND
FMC1m001
Pin Row D
D01 VCC
D02 VCC
D03 VCC
D04 VCC
D05 PLTRST#
D06 FUSA_SPI_CS# 2
D07 FUSA_SPI_CLK 2
D08 FUSA_SPI_MISO
2
D09 FUSA_SPI_MOSI
2
D10 WAKE0#
D11 WAKE1#
D12 GND
D13 USB1-
D14 USB1+
D15 GND
D16 USB0-
D17 USB0+
D18 GND
D19 SS01_SDA_AUX-
D20 SS01_SCL_AUX+
D21 GND
D22 SS0_TX-
D23 SS0_TX+
D24 GND
D25 SS0_RX-
D26 SS0_RX+
D27 GND
D28 SS1_TX-
D29 SS1_TX+
D30 GND
D31 SS1_RX1
D32 SS1_RX+
D33 GND
D34 ACPRESENT
16/41
