6

Additional Features

6.1

Power Button

The Qseven module performs a power up sequence when you press this button . The power button is connected to the
®
Qseven module's PWRBTN# signal.
®
6.2

Sleep Button

The Qseven module enters a sleep state when you press this button. The sleep button is connected to the Qseven
®
SLP_BTN# signal.
6.3

Reset Button

When you press this button, the Qseven
The reset button is connected to the Qseven
6.4

LID Button

Pressing the LID button creates a low active signal used by the ACPI operating system to detect a LID switch and to bring the
system into either a sleep state or to wake it up again. The LID button is connected to the Qseven
External LID switch can be connected to connector X18.
Connector Type
X18: 2 pin 2.54mm grid female.
Copyright © 2014 congatec AG
module and all components connected on the QEVAL 2.0 will perform a hard reset.
®
module's RSTBTN# signal.
®
LID
(X18)
1
module's LID_BTN# signal.
®
2
QEV2m11
Pwr On
(M3)
Sleep
(M5)
module's
®
Reset
(M4)
LID
(M6)
42/49
