Features Classification
SPI eSPI
Boot SPI
General Purpose SPI
BIOS Select -
Display DDI
eDP
MIPI DSI
CSI
Audio SoundWire
I2S
Other Serial I2C
Ports
SMBus
IPMB
UART
GPIO -
Miscellaneous Watchdog Timer
Fan (PWM and
tachometer)
FuSa FuSa set of signals
Power Rails VCC
VCC_5V-SBY
VCC_RTC
GND
Connector J1
J2
Copyright © 2024 congatec GmbH
Mini Module Client Module Server Module
Min/Max Min/Max Min/Max
0 / 1 0 / 1 0 / 1
1 / 1 1 / 1 1 / 1
1 / 1 1 / 1 1 / 1
1 / 1 1 / 1 1/1
0 / 2 1 / 3 N.A
0 / 1 0 / 1 N.A
0 / 1 0 / 1 N.A
N.A 1 0 / 2 N.A
0 / 2 0 / 2 N.A
0 / 1 0 / 1 N.A
2 / 3 2 / 2 2 / 2
1 / 1 1 / 1 1 / 1
N.A 0 / 1 0 / 1
0 / 2 0 / 2 1 / 2
12 / 12 12 / 12
0 / 1 0 / 1 0 / 1
1 / 1 1 / 1 1 / 1
0 / 1 0 / 1 0 / 1
12 / 12 28 / 28 28 / 28
N.A 0 / 2 0 / 2
1 / 1 1 / 1 1 / 1
All All All
1 / 1 1 / 1 1 / 1
N.A 0 / 1 1 / 1
Comment
Additional display outputs may be available on the USB4 interface. On
mini module, DDI pins are shared with USB4.
1 Optional FFC connectors for MIPI-CSI on the mini module.
I2S pins may be used for one HDA port or two additional SoundWire
ports for a total of up to four SoundWire ports.
I2C0 and I2C1 for client and server modules. The mini module supports a
third I2C port (I2C2/MDIO (for SGMII PHY setup).
The mini module does not have 5V standby pins.
All available GND pins shall be used.
