Pin Signal
B70 PCIE29_TXP
B71 PCIE29_TXN
B72 GND
B73 GND
B74 PCIE30_TXP
B75 PCIE30_TXN
B76 GND
B77 GND
B78 PCIE31_TXP
B79 PCIE31_TXN
B80 GND
B81 NC
B82 NC
6.9.

LPC Debug

CN37: LPC Debug Header
Pin Signal
1 LPC_CLK
3 LPC_FRAME#
5 LPC_RST#
7 LPC_AD3
9 + 3.3VSB
11 LPC_AD0
13 SMB_CK
15 SPD_A1 (see JP25)
17 GND
19 NC
24
Pin Signal
A70 GND
A71 GND
A72 PCIE29_RXP
A73 PCIE29_RXN
A74 GND
A75 GND
A76 PCIE30_RXP
A77 PCIE30_RXN
A78 GND
A79 GND
A80 PCIE31_RXP
A81 PCIE31_RXN
A82 GND
Pin Signal
2 GND
4 KEY
6 + 5V
8 LPC_AD2
10 LPC_AD1
12 GND
14 SMB_DAT
16 SPD_A0 (see JP26)
18 LPC_SERIRQ
20 NC
1 2
19 20
