CN43: Feature Connector
Pin
Signal
1
+ 5V
3
+ 5V
5
I2C_DAT
7
I2C_CK
9
Internal Use
11
Internal Use
13
PS_ON#
15
SUS_S3#
17
GND
19
THRMTRIP#
21
GPI1
23
SUS_STAT#
25
GPI2
27
WDTRIG
29
GPI3
31
BATLOW#
33
PEF_ENABLE#
35
KBINH#
37
GND
39
PWBTN#
U55: Secondary SPI BIOS Socket
See JP23/JP24 BIOS Selection Jumpers on 6.19 Other Jumper Setting and 7.1 SPI Secondary BIOS for details.
Pin
Signal
1
CS#
2
DO
3
WP#
4
GND
5
DI
6
CLK
7
HOLD#
8
+ 3.3V
34
Pin
Signal
2
+ 5VSB
4
Hard Disk Activity
6
SMBCLK_SB
8
SMBDAT_SB
10
GPO0
12
GPO1
14
GPO2
16
GPO3
18
GND
20
SMBALRT#
22
SUS_S4#
24
GPI0
26
SUS_S5#
28
THRM#
30
PCI_M66EN
32
WAKE1#
34
PEG_LANE_RV#
36
SYS_RESET#
38
GND
40
PWR_OK
1
2
39
40
Connectors, Pinouts and Jumpers
