CN36/CN39: GPIO Headers
GPIOs of CN36 come from the COM Express module. GPIOs to CN39 come from Express-BASE7.
Pin
Signal
1
GPI0
3
GPI1
5
GPI2
7
GPI3
CN32: Miscellaneous Connector
Pin
Signal
1
Power_LED
2
WDT_LED
3
GND
4
NC
5
GND
6
GND
7
NC
8
PS_ON
9
+ 5VSB
10
SIO_PME
Note: <<<< indicates default setting
CN41/42: Digital I/O
The Express-BASE7 provides GPIO expansion for I2C applications via a Phillips PCA955 with 16-bit I2C I/O port
and interrupt (for CN41 n=0, for CN42 n=1). See 8.4 Digital I/O LEDs for CN41 LED descriptions.
Pin
Signal
1
I/O n.0
2
I/O n.1
3
I/O n.2
4
I/O n.3
5
I/O n.4
6
I/O n.5
7
I/O n.6
8
I/O n.7
9
INT#
10
+ 3.3V
Connectors, Pinouts and Jumpers
Pin
Signal
2
GPO1
4
GPO2
6
GPO3
8
GPO4
Pin
Signal
11
BUZZER
12
NC
13
NC
14
+ 5V
15
SYS_RESET
16
GND
17
ATA_ACT
18
+ 3.3V
19
PWR_BTN
20
GND
Pin
Signal
11
GND
12
GND
13
GND
14
GND
15
GND
16
GND
17
GND
18
GND
19
BATLOW#
20
+ 3.3V
1
2
7
8
1
11
10
20
