ADLINK Technology COM Express Express-BASE7 User Manual page 27

Pin Signal
B15 PCIE8_TXN
B16 GND
B17 NC
B18 GND
B19 PCIE9_TXP
B20 PCIE9_TXN
B21 GND
B22 GND
B23 PCIE10_TXP
B24 PCIE10_TXN
B25 GND
B26 GND
B27 PCIE11_TXP
B28 PCIE11_TXN
B29 GND
B30 NC
B31 NC
B32 GND
B33 PCIE12_TXP
B34 PCIE12_TXN
B35 GND
B36 GND
B37 PCIE13_TXP
B38 PCIE13_TXN
B39 GND
B40 GND
B41 PCIE14_TXP
B42 PCIE14_TXN
B43 GND
B44 GND
B45 PCIE15_TXP
B46 PCIE15_TXN
B47 GND
B48 NC
B49 GND
Connectors, Pinouts and Jumpers
Pin Signal
A15 GND
A16 PCIE8_RXP
A17 PCIE8_RXN
A18 GND
A19 NC
A20 GND
A21 PCIE9_RXP
A22 PCIE9_RXN
A23 GND
A24 GND
A25 PCIE10_RXP
A26 PCIE10_RXN
A27 GND
A28 GND
A29 PCIE11_RXP
A30 PCIE11_RXN
A31 GND
A32 NC
A33 NC
A34 GND
A35 PCIE12_RXP
A36 PCIE12_RXN
A37 GND
A38 GND
A39 PCIE13_RXP
A40 PCIE13_RXN
A41 GND
A42 GND
A43 PCIE14_RXP
A44 PCIE14_RXN
A45 GND
A46 GND
A47 PCIE15_RXP
A48 PCIE15_RXN
A49 GND
Express-BASE7
21
