ADLINK Technology COM Express Express-BASE7 User Manual page 22

Pin Signal
B27 10G_KR_RX2_P
B28 10G_KR_RX2_N
B29 GND
B30 10G_PHY_RST_23
B31 10G_PHY_RST_01
B32 GND
B33 10G_KR_RX1_P
B34 10G_KR_RX1_N
B35 GND
B36 GND
B37 10G_PHY_MDIO_SDA1
B38 10G_PHY_MDC_SCL1
B39 GND
B40 GND
B41 10G_KR_RX0_P
B42 10G_KR_RX0_N
B43 GND
B44 GND
B45 10G_SDP3
B46 10G_SDP2
B47 GND
B48 10G_SDP1
B49 GND
B50 NC
B51 NC
B52 GND
B53 GND
B54 NC
B55 NC
B56 GND
B57 GND
B58 NC
B59 NC
B60 GND
B61 GND
16
Pin Signal
A27 GND
A28 GND
A29 10G_KR_TX2_P
A30 10G_KR_TX2_N
A31 GND
A32 10G_LED_SDA
A33 10G_LED_SCL
A34 GND
A35 10G_KR_TX1_P
A36 10G_KR_TX1_N
A37 GND
A38 GND
A39 10G_PHY_MDIO_SDA0
A40 10G_PHY_MDC_SCL0
A41 GND
A42 GND
A43 10G_KR_TX0_P
A44 10G_KR_TX0_N
A45 GND
A46 GND
A47 10G_PHY_CAP_23
A48 10G_PHY_CAP_01
A49 GND
A50 10G_SDP0
A51 GND
A52 NC
A53 NC
A54 GND
A55 GND
A56 NC
A57 NC
A58 GND
A59 GND
A60 NC
A61 NC
Connectors, Pinouts and Jumpers
