3. Instructions

• Specify the number displayed to the right of the SFC program in the workspace for the SFC task

number, as shown below.

As shown below, SFC programs can be created in interrupt tasks and executed as extra tasks.

When using an extra task, specify the SFC task number as shown above for the operand data. For

the program shown above for extra task 1 (interrupt task 1), the SFC task number specification

would be as follows:

• These instructions cannot be used for the task in which they are programmed. For example, if the

instruction is in cyclic task 0 (task number 0), a task number of 0 cannot be specified.

• This instruction cannot be input or displayed on a Programming Console. "?" will be displayed.

Interrupt task 01

CS/CJ/NSJ Series Instructions Reference Manual (W474)
