3. Instructions
Sample program
• Operation of TMHW(815)
When 0.01 is ON, BPRG1 is executed. After program A is executed, the set value is preset in timer 2
and the program jumps to BEND. A is not executed in the next cycle; execution takes place from the
TMHW instruction. When the time elapses (0.2 seconds), program B is executed.
0.01
1032
1
Coding
Address Instruction
000221 LD
000222 BPRG
.
A
.
000250 TMHW
.
B
.
000281 BEND
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Operand
0.01
0
.
.
2
#0020
.
.
---
