EMBC
Instruction
SELECT EM BANK
Symbol
Applicable Program Areas
Function block
Area
definitions
Usage OK
Operands
Operand
N EM bank number
N: EM Bank Number
Specifies the new EM bank number in hexadecimal (0000 to 0018).
Operand Specifications
Word addresses
Area
CIO WR HR
N OK OK OK
Flags
Operand
Error Flag
Related Auxiliary Area Words and Bits
Name
Current EM Bank
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Mnemonic Variations
EMBC @EMBC
Block program areas Step program areas
Ok OK
Description
AR T C DM EM
OK OK OK
OK OK
Description
ER • ON if N specifies a non-existent EM bank number.
• ON if automatic address allocation has been set for the specified EM bank (CJ2 CPU
• ON if EMBC(281) is executed in an interrupt task for a CJ2 CPU Unit with high-speed
• OFF in all other cases.
Address
A301 Contains the current EM bank number in hexadecimal
Function
code
281 Changes the current EM bank.
EMBC
EMBC(281)
N N: EM bank number
Subroutines
OK
Data type
UINT
Indirect DM/EM
addresses
Con-
stants
@DM *DM
DR
@EM *EM
OK OK OK OK
(This error will occur if the specified EM bank has been registered as file memory in
the PLC Setup.)
Units only).
interrupt function enabled.
3. Instructions
Function
SFC action or transition
Interrupt tasks
programs
OK OK
Size
1
Registers Flags
Pulse
Indirect
IR TK CF
using IR
--- OK --- ---
Data type
Operation
3
TR
bits bits
--- ---
993
