4. Instruction Execution Times and Number of Steps
4-1-8 Increment/Decrement Instructions
Instruction
INCREMENT BINARY
DOUBLE INCREMENT
BINARY
DECREMENT BINARY
DOUBLE DECREMENT
BINARY
INCREMENT BCD
DOUBLE INCREMENT BCD
DECREMENT BCD
DOUBLE DECREMENT BCD – –BL
4-1-9 Symbol Math Instructions
Instruction
SIGNED BINARY ADD WITH-
OUT CARRY
DOUBLE SIGNED BINARY
ADD WITHOUT CARRY
SIGNED BINARY ADD WITH
CARRY
DOUBLE SIGNED BINARY
ADD WITH CARRY
BCD ADD WITHOUT CARRY +B
DOUBLE BCD ADD WITH-
OUT CARRY
BCD ADD WITH CARRY
DOUBLE BCD ADD WITH
CARRY
SIGNED BINARY SUB-
TRACT WITHOUT CARRY
DOUBLE SIGNED BINARY
SUBTRACT WITHOUT
CARRY
SIGNED BINARY SUB-
TRACT WITH CARRY
DOUBLE SIGNED BINARY
SUBTRACT WITH CARRY
BCD SUBTRACT WITHOUT
CARRY
DOUBLE BCD SUBTRACT
WITHOUT CARRY
BCD SUBTRACT WITH
CARRY
DOUBLE BCD SUBTRACT
WITH CARRY
SIGNED BINARY MULTIPLY
DOUBLE SIGNED BINARY
MULTIPLY
UNSIGNED BINARY MULTI-
PLY
DOUBLE UNSIGNED
BINARY MULTIPLY
BCD MULTIPLY
DOUBLE BCD MULTIPLY
1104
Mnemonic Length (steps)
++ 2
++L 2
– – 2
– –L 2
++B 2
++BL 2
– –B 2
2
Mnemonic Length (steps)
+ 4
+L 4 to 6
+C 4
+CL 4 to 6
4
+BL 4 to 6
+BC 4
+BCL 4 to 6
– 4
–L 4 to 6
–C 4
–CL 4 to 6
–B 4
–BL 4 to 6
–BC 4
–BCL 4 to 6
* 4
*L 4 to 6
*U 4
*UL 4 to 6
*B 4
*BL 4 to 6
ON execution time ( s)
CJ2H CPU6@(-EIP)
0.18 ---
0.18 ---
0.18 ---
0.18 ---
3.0 ---
3.2 ---
3.0 ---
3.2 ---
ON execution time ( s)
CJ2H CPU6@(-EIP)
0.18 ---
0.18 ---
0.18 ---
0.18 ---
4.0 ---
4.9 ---
4.4 ---
5.2 ---
0.18 ---
0.18 ---
0.18 ---
0.18 ---
4.1 ---
4.9 ---
4.5 ---
5.3 ---
0.26 ---
3.6 ---
0.26 ---
3.6 ---
3.6 ---
4.9 ---
CS/CJ/NSJ Series Instructions Reference Manual (W474)
Conditions
Conditions
