SC6000 Series Smart Camera Quick Start Guide
Parameter Name
Output Logic Level Low
Output Logic Level High
Output Falling Delay
Output Rising Delay
Output Falling Time
Output Rising Time
6.1.3 Configurable Input/Output Signal
The device's Line 2/3 can be configured to input or output signals via the VM software, and
their internal circuit is as follows.
Configured as Input Signal
Input Level
High
Input Level
Low
Internal
Logic
Table 6-2 Output Electrical Feature
Figure 6-5 Internal Circuit of Bi-Directional Signal
50%
TDF
50%
Figure 6-6 Input Logic Level
Symbol
VL
VH
TDF
TDR
TF
TR
20
Value
730 mV
3.2 VDC
6.3 μs
68 μs
3 μs
60 μs
50%
TDF
50%
