3.2 Connector

The device's main connector includes power and I/O connector, and extended interface.
Refer to the information below for details.

3.2.1 Power and I/O Connector

The device's power and I/O connector is a 17-pin M12 male connector that provides opto-
isolated input × 2 (Line 0/1), opto-isolated output × 2 (Line 4/5), configurable non-isolated
input/output × 2 (Line 2/3), RS-232 × 1, and light source output (max. 30 W) × 1.
The pin definition of the connector is shown below.
No. Signal
1
VCC+
2
3
VCC-
4
5 LED+
6 LED-
7 RS232_T
SC6000 Series Smart Camera Quick Start Guide
Figure 3-2 Power and I/O Connector
Table 3-2 Pin Definition
I/O Signal Source
--
--
--
--
--
Description
When an external
DC Power
light source is not
Supply+
required, use either
of the two pairs "1
and 3" or "2 and 4".
If an external light
source is required,
these 4 pins need
Power Supply
to be wired, and
Ground
power supply of 24
V, 2A or more is
recommended.
External Light Source+
External Light Source-
RS-232 Output
7
Cable Color
White
Brown
Green/White
Blue/White
Red/Blue
