SC6000 Series Smart Camera Quick Start Guide
Steps
1. Use M4 screws to fix the device to the installation bracket.
2. Install the device to other mechanical parts via the installation bracket.
Note
Front installation and rear installation are both available, as shown below.
Figure 4-1 Rear Installation
Figure 4-2 Front Installation
3. (Optional) Adjust the device's installation angle according to actual demands.
4. Use the GigE network cable to connect the device to a switch or a NIC.
5. Use the power and I/O cable to connect the device to a DC switch power supply.
11
