SC6000 Series Smart Camera Quick Start Guide
No. Name
1 Lens Cap
2 Acquisition Module
3 Screw Hole
4 Network Interface
5 Extended Interface
6 Power and I/O Connector
7 PWR Indicator
8 LNK Indicator
9 U1/U2 Indicator
10 STS Indicator
Table 3-1 Component Description
The device adopts a transparent lens cap by default.
It is used to acquire images.
There are mounting screw holes on the front and rear
of the device (2 on the front and 4 on the rear) to fix
the device to the bracket. It is recommended to use
M4 screws in the device package.
Note
If other screws are used, it is recommended to
choose metric M4 screws, and the screw length
should be less than the sum of the thickness of the
mounting plate and the depth of the screw hole.
It is GigE interface for transmitting data.
Note
The interface has threads, and it is recommended to
tighten the interface when using the device to reduce
looseness due to the vibration on-site.
It is a 17-pin M12 female connector providing VGA ×
1 and USB host × 1.
It is a 17-pin M12 male connector providing power
supply, I/O signals, and RS-232 communication.
It is a power indicator, and is solid blue when the
device's power supply is normal.
It is a network indicator, and is solid green when the
device's network is normal.
They are user-defined indicators. U1 and U2 can
display red or blue color.
Note
U1 and U2 currently are not available for using.
It is a status indicator for indicating the VM service
status. It is solid green when the VM service is
normal. Otherwise, the indicator is solid red.
6
Description
