Bose ControlSpace ESP-880 Service Manual page 77

Switcher Name=OUT1 connections (to ESP & ATS-2) for ESP-4120
Switcher
IN CH1L ESP880 OUT1
IN CH1R ESP880 OUT2
IN CH2L ESP880 OUT3
IN CH2R ESP880 OUT4
IN CH3L ESP880 OUT5
IN CH3R ESP880 OUT6
IN CH4L ESP880 OUT7
IN CH4R ESP880 OUT8
OUT CH5L ESP880 OUT9
OUT CH5R ESP880 OUT10
OUT CH6L ESP880 OUT11
OUT CH6L ESP880 OUT12
COM-L ATS2 ANALOG IN CHA
COM-R ATS2 ANALOG IN CHB
PC/ESP/ATS-2/Switcher Connections for ESP-1600 (refer to Figure 10)
Switcher Name=IN1 connections (to Phantom & ATS-2) for ESP-1600
Switcher
OUT CH1L ESP880 IN9
OUT CH1R ESP880 IN10
OUT CH2L ESP880 IN11
OUT CH2R ESP880 IN12
OUT CH3L ESP880 IN13
OUT CH3R ESP880 IN14
OUT CH4L ESP880 IN15
OUT CH4R ESP880 IN16
Phantom Voltage checker or
OUT CH5L
Phantom indicator
Phantom Voltage checker or
OUT CH5R
Phantom indicator
OUT CH6L Switcher Name=IN2 COM-L
OUT CH6L Switcher Name=IN2 COM-R
COM-L ATS2 ANALOG OUT CHA
COM-R ATS2 ANALOG OUT CHB
Note: Same connections as for ESP-880
TEST PROCEDURES
ESP/ATS-2
ESP/ATS-2
77
Label
1
2
3
4
5
6
7
8
1
2
3
4
OUT1-COM-L
OUT1-COM-R
Label
1
2
3
4
5
6
7
8
IN1-CH5L
IN1-CH5R
IN1-CH6L
IN1-CH6R
IN1-COM-L
IN1-COM-R
