Bose ControlSpace ESP-880 Service Manual page 45

Reference
Designator
C264 0.012uF, CER, 25V, 5%, NP0, 0603
C301 0 OHM, THICK, FC, 1/10W, 0603
C302 3600pF, CER, 50V, 5%, NP0, 0603
C303 3600pF, CER, 50V, 5%, NP0, 0603
C304 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C305 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C306 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C307 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C308 33uF, SMD, E CAP, 25V, 20%, +85-40C
C309 33uF, SMD, E CAP, 25V, 20%, +85-40C
C310 22pF, CER, 50V, 5% , NP0, 0603
C311 22pF, CER, 50V, 5% , NP0, 0603
C312 22pF, CER, 50V, 5% , NP0, 0603
C313 22pF, CER, 50V, 5% , NP0, 0603
C316 3600pF, CER, 50V, 5%, NP0, 0603
C318 100nF, CHIP, X7R, 50V, 10%, +125-55C, 0603
C319 100nF, CHIP, X7R, 50V, 10%, +125-55C, 0603
C320 100nF, CHIP, X7R, 50V, 10%, +125-55C, 0603
C331 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C332 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C351 10uF, SMD, E CAP, 16V, 20%
C352 10uF, SMD, E CAP, 16V, 20%
C353 1800pF, CER, 50V, 5%, NP0, 0603
C354 1800pF, CER, 50V, 5%, NP0, 0603
C355 0.012uF, CER, 25V, 5%, NP0, 0603
C356 3600pF, CER, 50V, 5%, NP0, 0603
C357 1800pF, CER, 50V, 5%, NP0, 0603
C358 1800pF, CER, 50V, 5%, NP0, 0603
C359 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C360 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C361 3600pF, CER, 50V, 5%, NP0, 0603
C362 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C363 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C364 0.012uF, CER, 25V, 5%, NP0, 0603
C401 0 OHM, THICK, FC, 1/10W, 0603
C402 3600pF, CER, 50V, 5%, NP0, 0603
C403 3600pF, CER, 50V, 5%, NP0, 0603
C404 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C405 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C406 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C407 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C408 33uF, SMD, E CAP, 25V, 20%, +85-40C
C409 33uF, SMD, E CAP, 25V, 20%, +85-40C
C410 22pF, CER, 50V, 5% , NP0, 0603
C411 22pF, CER, 50V, 5% , NP0, 0603
C412 22pF, CER, 50V, 5% , NP0, 0603
C413 22pF, CER, 50V, 5% , NP0, 0603
C416 3600pF, CER, 50V, 5%, NP0, 0603
C418 100nF, CHIP, X7R, 50V, 10%, +125-55C, 0603
C419 100nF, CHIP, X7R, 50V, 10%, +125-55C, 0603
C420 100nF, CHIP, X7R, 50V, 10%, +125-55C, 0603
C431 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C432 100nF, CHIP, X7R, 25V, 10%, +125-55C, 0603
C451 10uF, SMD, E CAP, 16V, 20%
C452 10uF, SMD, E CAP, 16V, 20%
C453 1800pF, CER, 50V, 5%, NP0, 0603
C454 1800pF, CER, 50V, 5%, NP0, 0603
ELECTRICAL PART LIST
Analog Output PCB Assembly
Capacitors (continued)
Description
45
Vendor Vendor Part Number
Name
Kemet C0603C123J3GACTU
Panasonic ERJ 3G EY0R00V
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
EMVA250ADA330ME55G
Nippon
Nippon EMVA250ADA330ME55G
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H362JA01D
Yageo CC0603KRX7R9BB104
Yageo CC0603KRX7R9BB104
Yageo CC0603KRX7R9BB104
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
EMVY160ADA100MD55G
Nippon
Nippon EMVY160ADA100MD55G
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Kemet C0603C123J3GACTU
Murata GRM1885C1H362JA01D
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
Murata GRM1885C1H362JA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
Kemet C0603C123J3GACTU
Panasonic ERJ 3G EY0R00V
Murata GRM1885C1H362JA01D
Murata GRM1885C1H362JA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
EMVA250ADA330ME55G
Nippon
EMVA250ADA330ME55G
Nippon
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H220JA01D
Murata GRM1885C1H362JA01D
Yageo CC0603KRX7R9BB104
Yageo CC0603KRX7R9BB104
Yageo CC0603KRX7R9BB104
Murata GRM188R71E104KA01D
Murata GRM188R71E104KA01D
EMVY160ADA100MD55G
Nippon
Nippon EMVY160ADA100MD55G
Murata GRM1885C1H182JA01D
Murata GRM1885C1H182JA01D
Note
