Bose ControlSpace ESP-880 Service Manual page 26

Reference
Designator
C202 0.1uF, CER, 16V, 10% , X7R, 0402
C203 0.1uF, CER, 16V, 10% , X7R, 0402
C204 10000pF, CER, 25V, 10%, X7R, 0402
C205 1uF, CER, 25V, X7R, 10%, 0603
C207 0.1uF, CER, 16V, 10% , X7R, 0402
C208 10000pF, CER, 25V, 10%, X7R, 0402
C209 1uF, CER, 25V, X7R, 10%, 0603
C211 0.22uF, CER, 10V, 10%, X7R, 0603
C212 0.1uF, CER, 16V, 10% , X7R, 0402
C213 10uF, CER, 16V, 20% , X5R, 1206
C214 10uF, CER, 16V, 20% , X5R, 1206
C215 1uF, CER, 25V, X7R, 10%, 0603
C219 0.1uF, CER, 16V, 10% , X7R, 0402
C220 10000pF, CER, 25V, 10%, X7R, 0402
C221 1uF, CER, 25V, X7R, 10%, 0603
C223 0.1uF, CER, 16V, 10% , X7R, 0402
C224 10000pF, CER, 25V, 10%, X7R, 0402
C230 0.1uF, CER, 16V, 10% , X7R, 0402
C231 10000pF, CER, 25V, 10%, X7R, 0402
C232 18pF, CER, 50V, 5% , NP0, 0402
C233 18pF, CER, 50V, 5% , NP0, 0402
C234 0.1uF, CER, 16V, 10% , X7R, 0402
C236 0.1uF, CER, 16V, 10% , X7R, 0402
C237 22pF, CER, 50V, 5% , NP0, 0402
C238 22pF, CER, 50V, 5% , NP0, 0402
C239 0.1uF, CER, 16V, 10% , X7R, 0402
C251 10000pF, CER, 25V, 10%, X7R, 0402
C252 10000pF, CER, 25V, 10%, X7R, 0402
C253 10000pF, CER, 25V, 10%, X7R, 0402
C254 1uF, CER, 25V, X7R, 10%, 0603
C255 0.1uF, CER, 16V, 10% , X7R, 0402
C256 0.1uF, CER, 16V, 10% , X7R, 0402
C258 0.1uF, CER, 16V, 10% , X7R, 0402
C271 0.1uF, CER, 16V, 10% , X7R, 0402
C272 0.1uF, CER, 16V, 10% , X7R, 0402
C273 0.1uF, CER, 16V, 10% , X7R, 0402
C274 0.1uF, CER, 16V, 10% , X7R, 0402
C275 0.1uF, CER, 16V, 10% , X7R, 0402
C276 0.1uF, CER, 16V, 10% , X7R, 0402
C277 0.1uF, CER, 16V, 10% , X7R, 0402
C278 0.1uF, CER, 16V, 10% , X7R, 0402
C279 0.1uF, CER, 16V, 10% , X7R, 0402
C280 0.1uF, CER, 16V, 10% , X7R, 0402
C281 0.1uF, CER, 16V, 10% , X7R, 0402
C282 0.1uF, CER, 16V, 10% , X7R, 0402
C283 0.1uF, CER, 16V, 10% , X7R, 0402
C284 0.1uF, CER, 16V, 10% , X7R, 0402
C285 0.1uF, CER, 16V, 10% , X7R, 0402
C286 33uF, TANT, 6.3V, 20% , 1206
C287 33uF, TANT, 6.3V, 20% , 1206
C288 33uF, TANT, 6.3V, 20% , 1206
C289 33uF, TANT, 6.3V, 20% , 1206
C290 0.1uF, CER, 16V, 10% , X7R, 0402
C291 0.1uF, CER, 16V, 10% , X7R, 0402
C292 0.1uF, CER, 16V, 10% , X7R, 0402
C293 0.1uF, CER, 16V, 10% , X7R, 0402
C294 0.1uF, CER, 16V, 10% , X7R, 0402
ELECTRICAL PART LIST
Main PCB Assembly
Capacitors
Description
26
Vendor Vendor Part Number
Name
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71E103KA01D
Murata GRM188R71E105KA12D
Murata GRM155R71C104KA88D
Murata GRM155R71E103KA01D
Murata GRM188R71E105KA12D
Murata GRM188R71A224KA01D
Murata GRM155R71C104KA88D
TDK C3216X5R1C106M
TDK C3216X5R1C106M
Murata GRM188R71E105KA12D
Murata GRM155R71C104KA88D
Murata GRM155R71E103KA01D
Murata GRM188R71E105KA12D
Murata GRM155R71C104KA88D
Murata GRM155R71E103KA01D
Murata GRM155R71C104KA88D
Murata GRM155R71E103KA01D
Murata GRM1555C1H180J Z01D
Murata GRM1555C1H180J Z01D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM1555C1H220J Z01D
Murata GRM1555C1H220J Z01D
Murata GRM155R71C104KA88D
Murata GRM155R71E103KA01D
Murata GRM155R71E103KA01D
Murata GRM155R71E103KA01D
Murata GRM188R71E105KA12D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Kemet T491A336M006AT
Kemet T491A336M006AT
Kemet T491A336M006AT
Kemet T491A336M006AT
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Note
