Reference
Designator
R711
20.0K, 1/10W, 1%, 0402, SMD
R712
20.0K, 1/10W, 1%, 0402, SMD
R713
20.0K, 1/10W, 1%, 0402, SMD
R714
20.0K, 1/10W, 1%, 0402, SMD
R715
20.0K, 1/10W, 1%, 0402, SMD
R718
20.0K, 1/10W, 1%, 0402, SMD
R719
20.0K, 1/10W, 1%, 0402, SMD
R720
20.0K, 1/10W, 1%, 0402, SMD
R721
20.0K, 1/10W, 1%, 0402, SMD
R722
20.0K, 1/10W, 1%, 0402, SMD
R723
20.0K, 1/10W, 1%, 0402, SMD
R724
20.0K, 1/10W, 1%, 0402, SMD
R725
20.0K, 1/10W, 1%, 0402, SMD
R726
51.0K, OHM, 1/10W, 1%, 0402, SMD
R731
10.0K, 1/10W, 1%, 0402, SMD
R732
10.0K, 1/10W, 1%, 0402, SMD
R733
10.0K, 1/10W, 1%, 0402, SMD
R734
10.0K, 1/10W, 1%, 0402, SMD
R735
3.30K, 1/10W, 1%, 0603, SMD
R736
3.30K, 1/10W, 1%, 0603, SMD
R737
3.30K, 1/10W, 1%, 0603, SMD
R738
3.30K, 1/10W, 1%, 0603, SMD
R739
3.30K, 1/10W, 1%, 0603, SMD
R740
3.30K, 1/10W, 1%, 0603, SMD
R741
3.30K, 1/10W, 1%, 0603, SMD
R742
3.30K, 1/10W, 1%, 0603, SMD
R743
10.0K, 1/10W, 1%, 0402, SMD
R744
10.0K, 1/10W, 1%, 0402, SMD
R746
10.0K, 1/10W, 1%, 0402, SMD
R747
1.0K, 1/10W, 1%, 0402, SMD
R748
1.0K, 1/10W, 1%, 0402, SMD
R749
3.30K, 1/10W, 1%, 0603, SMD
R750
3.30K, 1/10W, 1%, 0603, SMD
R752
0.0 OHM, 1/10W , 0402, SMD
R753
200K, 1/10W, 1%, 0603, SMD
R754
10.0K, 1/10W, 1%, 0402, SMD
R802
20.0K, 1/10W, 1%, 0402, SMD
R805
15.4K, OHM, 1/10W, 1%, 0603, SMD
R806
22.1K, 1/10W, 1%, 0603, SMD
R808
22.1K, 1/10W, 1%, 0603, SMD
R809
73.2K, 1/10W, 1%, 0603, SMD
R810
110K, 1/10W, 1%, 0603, SMD
R811
110K, 1/10W, 1%, 0603, SMD
R812
0.0 OHM, 1/10W , 0402, SMD
R837
124K, 1/8W, 1%, 0805, SMD
R839
20.0K, 1/10W, 1%, 0402, SMD
R840
22.1K, 1/10W, 1%, 0603, SMD
R841
20.0K, 1/10W, 1%, 0402, SMD
R842
20.0K, 1/10W, 1%, 0402, SMD
R843
0.0 OHM, 1/10W , 0402, SMD
R844
110K, 1/10W, 1%, 0603, SMD
R845
0.0 OHM, 1/10W , 0402, SMD
R861
1.0K, 1/10W, 1%, 0402, SMD
R865
470 OHM, 1/10W , 1%, 0402, SMD
R901
330 OHM, 1/10W , 1%, 0603, SMD
R902
330 OHM, 1/10W , 1%, 0603, SMD
R903
330 OHM, 1/10W , 1%, 0603, SMD
ELECTRICAL PART LIST
Main PCB Assembly
Resistors (continued)
Description
24
Vendor
Vendor Part Number
Name
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF5102X
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF1001X
Panas onic
ERJ-2RKF1001X
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-3EKF3301V
Panas onic
ERJ-2GE0R00X
Panas onic
ERJ-3EKF2003V
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-3EKF1542V
Panas onic
ERJ-3EKF2212V
Panas onic
ERJ-3EKF2212V
Panas onic
ERJ-3EKF7322V
Panas onic
ERJ-3EKF1103V
Panas onic
ERJ-3EKF1103V
Panas onic
ERJ-2GE0R00X
Panas onic
ERJ-6ENF1243V
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-3EKF2212V
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2GE0R00X
Panas onic
ERJ-3EKF1103V
Panas onic
ERJ-2GE0R00X
Panas onic
ERJ-2RKF1001X
Panas onic
ERJ-2GEJ 471X
Panas onic
ERJ-3EKF3300V
Panas onic
ERJ-3EKF3300V
Panas onic
ERJ-3EKF3300V
Note
