Reference
Designator
R107
22.0 OHM, 1/10W , 1%, 0402, SMD
R108
22.0 OHM, 1/10W , 1%, 0402, SMD
R109
22.0 OHM, 1/10W , 1%, 0402, SMD
R111
22.0 OHM, 1/10W , 1%, 0402, SMD
R112
22.0 OHM, 1/10W , 1%, 0402, SMD
R113
0.0 OHM, 1/10W , 0402, SMD
R114
22.0 OHM, 1/10W , 1%, 0402, SMD
R120
22.0 OHM, 1/10W , 1%, 0402, SMD
R121
22.0 OHM, 1/10W , 1%, 0402, SMD
R122
22.0 OHM, 1/10W , 1%, 0402, SMD
R123
22.0 OHM, 1/10W , 1%, 0402, SMD
R124
22.0 OHM, 1/10W , 1%, 0402, SMD
R125
22.0 OHM, 1/10W , 1%, 0402, SMD
R127
22.0 OHM, 1/10W , 1%, 0402, SMD
R128
22.0 OHM, 1/10W , 1%, 0402, SMD
R129
22.0 OHM, 1/10W , 1%, 0402, SMD
R130
22.0 OHM, 1/10W , 1%, 0402, SMD
R131
22.0 OHM, 1/10W , 1%, 0402, SMD
R132
22.0 OHM, 1/10W , 1%, 0402, SMD
R137
22.0 OHM, 1/10W , 1%, 0402, SMD
R138
22.0 OHM, 1/10W , 1%, 0402, SMD
R139
22.0 OHM, 1/10W , 1%, 0402, SMD
R154
22.0 OHM, 1/10W , 1%, 0402, SMD
R155
22.0 OHM, 1/10W , 1%, 0402, SMD
R156
20.0K, 1/10W, 1%, 0402, SMD
R157
2.0K, 1/10W, 1%, 0402, SMD
R158
22.0 OHM, 1/10W , 1%, 0402, SMD
R159
20.0K, 1/10W, 1%, 0402, SMD
R160
20.0K, 1/10W, 1%, 0402, SMD
R161
20.0K, 1/10W, 1%, 0402, SMD
R162
22.0 OHM, 1/10W , 1%, 0402, SMD
R163
22.0 OHM, 1/10W , 1%, 0402, SMD
R164
22.0 OHM, 1/10W , 1%, 0402, SMD
R165
22.0 OHM, 1/10W , 1%, 0402, SMD
R166
22.0 OHM, 1/10W , 1%, 0402, SMD
R167
22.0 OHM, 1/10W , 1%, 0402, SMD
R168
22.0 OHM, 1/10W , 1%, 0402, SMD
R169
22.0 OHM, 1/10W , 1%, 0402, SMD
R171
20.0K, 1/10W, 1%, 0402, SMD
R172
20.0K, 1/10W, 1%, 0402, SMD
R173
2.0K, 1/10W, 1%, 0402, SMD
R174
20.0K, 1/10W, 1%, 0402, SMD
R176
2.0K, 1/10W, 1%, 0402, SMD
R177
20.0K, 1/10W, 1%, 0402, SMD
R178
2.0K, 1/10W, 1%, 0402, SMD
R179
2.0K, 1/10W, 1%, 0402, SMD
R201
15.0K, 1/10W, 1%, 0402, SMD
R202
24.9 OHM, 1/10W , 1%, 0402, SMD
R203
24.9 OHM, 1/10W , 1%, 0402, SMD
R204
10.0K, 1/10W, 1%, 0402, SMD
R207
15.0K, 1/10W, 1%, 0402, SMD
R210
0.0 OHM, 1/10W , 0402, SMD
R212
0.0 OHM, 1/10W , 0402, SMD
R242
22.0 OHM, 1/10W , 1%, 0402, SMD
R246
22.0 OHM, 1/10W , 1%, 0402, SMD
R247
22.0 OHM, 1/10W , 1%, 0402, SMD
R248
22.0 OHM, 1/10W , 1%, 0402, SMD
ELECTRICAL PART LIST
Main PCB Assembly
Resistors
Description
21
Vendor
Vendor Part Number
Name
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2GE0R00X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2001X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2001X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2001X
Panas onic
ERJ-2RKF2002X
Panas onic
ERJ-2RKF2001X
Panas onic
ERJ-2RKF2001X
Panas onic
ERJ-2RKF1502X
Panas onic
ERJ-2RKF24R9X
Panas onic
ERJ-2RKF24R9X
Panas onic
ERJ-2RKF1002X
Panas onic
ERJ-2RKF1502X
Panas onic
ERJ-2GE0R00X
Panas onic
ERJ-2GE0R00X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Panas onic
ERJ-2RKF22R0X
Note
