Bose ControlSpace ESP-880 Service Manual page 8

CC-16, RS-232, and ESPLink connections (continued)
Manufactured Versions
Product Description
ControlSpace ESP-880 120V – US
ControlSpace ESP-880 230V – EU
ControlSpace ESP-880 100V – JPN
ControlSpace ESP-880 230V – UK/Sing
ControlSpace ESP-880 240V – AU
ControlSpace ESP-1240 120V – US
ControlSpace ESP-1240 230V – EU
ControlSpace ESP-1240 100V – JPN
ControlSpace ESP-1240 230V – UK/Sing
ControlSpace ESP-1240 240V – AU
ControlSpace ESP-4120 120V – US
ControlSpace ESP-4120 230V – EU
ControlSpace ESP-4120 100V – JPN
ControlSpace ESP-4120 230V – UK/Sing
ControlSpace ESP-1240 240V – AU
Note: Early versions of these products did not include a fan inside the chassis.
Continued on next page --->
PRODUCT DESCRIPTION
Product
Codes
359868-1110
359868-2110
359868-3110
359868-4110
359868-5110
359869-1110
359869-2110
359869-3110
359869-4110
359869-5110
359870-1110
359870-2110
359870-3110
359870-4110
359870-5110
RS-232 Connector
Standard DB-9 male connector
Allows the ESP processor to send commands to other devices
and receive commands intended to trigger parameter sets.
See DTE pinout below.
ESPLink Connector
Using TOSLINK connection, 8 channels of uncompressed
low-latency audio can be distributed to one or many Bose
PowerMatch amplifiers that are outfitted with ESPLink digital
input cards.
No Fan /
With Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
No Fan
8
# Analog # Analog
Inputs Outputs
8 8
8 8
8 8
8 8
8 8
12 4
12 4
12 4
12 4
12 4
4 12
4 12
4 12
4 12
4 12
