Bose ControlSpace ESP-880 Service Manual page 34

Reference
Designator
R219 220 OHM, THICK, FC, 1/10W , 0603, 1%
R220 220 OHM, THICK, FC, 1/10W , 0603, 1%
R221 82.5 OHM, 1/10W , 1%, 0603, SMD
R222 82.5 OHM, 1/10W , 1%, 0603, SMD
R223 19.1 OHM, 1/10W , 1%, 0603, SMD
R224 19.1 OHM, 1/10W , 1%, 0603, SMD
R226 0 OHM, THICK, FC, 1/10W, 0603, 1%
R228 0 OHM, THICK, FC, 1/10W, 0603, 1%
R229 0 OHM, THICK, FC, 1/10W, 0603, 1%
R251 1.96K, THICK, FC, 1/10W, 0603, 1%
R252 1.96K, THICK, FC, 1/10W, 0603, 1%
R253 330 OHM, THICK, FC, 1/10W , 0603, 1%
R254 4.99K, THICK, 1/10W, 1%, 0603
R255 4.99K, THICK, 1/10W, 1%, 0603
R256 330 OHM, THICK, FC, 1/10W , 0603, 1%
R257 91 OHM, THICK, FC, 1/10W, 0603, 1%
R258 91 OHM, THICK, FC, 1/10W, 0603, 1%
R259 2.7K, THICK, FC, 1/10W, 0603, 1%
R301 6.8K, THICK, FC, 1/4W , 1210, 1%
R302 6.8K, THICK, FC, 1/4W , 1210, 1%
R303 39.0K, CHIP, 1/10W, 1% , 0603
R304 39.0K, CHIP, 1/10W, 1% , 0603
R306 3.3K, THICK, FC, 1/10W, 0603, 1%
R307 3.3K, THICK, FC, 1/10W, 0603, 1%
R311 200K, 1/8W, 1%, 0805, SMD
R312 100 OHM, THICK, FC, 1/8W, 0805, 1%
R313 20K, THICK, FC, 1/10W, 0603, 1%
R314 200K, 1/10W, 1%, 0603, SMD
R315 10K, THICK, FC, 1/10W, 0603, 1%
R316 10K, THICK, FC, 1/10W, 0603, 1%
R317 820 OHM, THICK, FC, 1/10W , 0603, 1%
R318 820 OHM, THICK, FC, 1/10W , 0603, 1%
R319 220 OHM, THICK, FC, 1/10W , 0603, 1%
R320 220 OHM, THICK, FC, 1/10W , 0603, 1%
R321 82.5 OHM, 1/10W , 1%, 0603, SMD
R322 82.5 OHM, 1/10W , 1%, 0603, SMD
R323 19.1 OHM, 1/10W , 1%, 0603, SMD
R324 19.1 OHM, 1/10W , 1%, 0603, SMD
R326 0 OHM, THICK, FC, 1/10W, 0603, 1%
R328 0 OHM, THICK, FC, 1/10W, 0603, 1%
R329 0 OHM, THICK, FC, 1/10W, 0603, 1%
R351 1.96K, THICK, FC, 1/10W, 0603, 1%
R352 1.96K, THICK, FC, 1/10W, 0603, 1%
R353 330 OHM, THICK, FC, 1/10W , 0603, 1%
R354 4.99K, THICK, 1/10W, 1%, 0603
R355 4.99K, THICK, 1/10W, 1%, 0603
R356 330 OHM, THICK, FC, 1/10W , 0603, 1%
R357 91 OHM, THICK, FC, 1/10W, 0603, 1%
R358 91 OHM, THICK, FC, 1/10W, 0603, 1%
R359 2.7K, THICK, FC, 1/10W, 0603, 1%
R401 6.8K, THICK, FC, 1/4W , 1210, 1%
R402 6.8K, THICK, FC, 1/4W , 1210, 1%
R403 39.0K, CHIP, 1/10W, 1% , 0603
R404 39.0K, CHIP, 1/10W, 1% , 0603
R406 3.3K, THICK, FC, 1/10W, 0603, 1%
R407 3.3K, THICK, FC, 1/10W, 0603, 1%
R411 200K, 1/8W, 1%, 0805, SMD
ELECTRICAL PART LIST
Analog Input PCB Assembly
Resistors (continued)
Description
34
Vendor Vendor Part Num ber
Name
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF19R1V
Panasonic ERJ-3EKF19R1V
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF2701V
Panasonic ERJ14NF6801U
Panasonic ERJ14NF6801U
Panasonic ERJ3EKF3902V
Panasonic ERJ3EKF3902V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-6ENF2003V
Panasonic ERJ6ENF1000V
Panasonic ERJ3EKF2002V
Panasonic ERJ-3EKF2003V
Panasonic ERJ3EKF1002V
Panasonic ERJ3EKF1002V
Panasonic ERJ-3EKF8200V
Panasonic ERJ-3EKF8200V
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF19R1V
Panasonic ERJ-3EKF19R1V
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF2701V
Panasonic ERJ14NF6801U
Panasonic ERJ14NF6801U
Panasonic ERJ3EKF3902V
Panasonic ERJ3EKF3902V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-6ENF2003V
Note
