Bose ControlSpace ESP-880 Service Manual page 35

Reference
Designator
R412 100 OHM, THICK, FC, 1/8W, 0805, 1%
R413 20K, THICK, FC, 1/10W, 0603, 1%
R414 200K, 1/10W, 1%, 0603, SMD
R415 10K, THICK, FC, 1/10W, 0603, 1%
R416 10K, THICK, FC, 1/10W, 0603, 1%
R417 820 OHM, THICK, FC, 1/10W , 0603, 1%
R418 820 OHM, THICK, FC, 1/10W , 0603, 1%
R419 220 OHM, THICK, FC, 1/10W , 0603, 1%
R420 220 OHM, THICK, FC, 1/10W , 0603, 1%
R421 82.5 OHM, 1/10W , 1%, 0603, SMD
R422 82.5 OHM, 1/10W , 1%, 0603, SMD
R423 19.1 OHM, 1/10W , 1%, 0603, SMD
R424 19.1 OHM, 1/10W , 1%, 0603, SMD
R426 0 OHM, THICK, FC, 1/10W, 0603, 1%
R428 0 OHM, THICK, FC, 1/10W, 0603, 1%
R429 0 OHM, THICK, FC, 1/10W, 0603, 1%
R451 1.96K, THICK, FC, 1/10W, 0603, 1%
R452 1.96K, THICK, FC, 1/10W, 0603, 1%
R453 330 OHM, THICK, FC, 1/10W , 0603, 1%
R454 4.99K, THICK, 1/10W, 1%, 0603
R455 4.99K, THICK, 1/10W, 1%, 0603
R456 330 OHM, THICK, FC, 1/10W , 0603, 1%
R457 91 OHM, THICK, FC, 1/10W, 0603, 1%
R458 91 OHM, THICK, FC, 1/10W, 0603, 1%
R459 2.7K, THICK, FC, 1/10W, 0603, 1%
R507 100K, 1/10W, 1%, 0603, SMD
R516 33 OHM, THICK, FC, 1/10W, 0603, 1%
R517 33 OHM, THICK, FC, 1/10W, 0603, 1%
R518 33 OHM, THICK, FC, 1/10W, 0603, 1%
R522 0 OHM, THICK, FC, 1/10W, 0603, 1%
R524 0 OHM, THICK, FC, 1/10W, 0603, 1%
R606 0 OHM, THICK, FC, 1/10W, 0603, 1%
R607 0 OHM, THICK, FC, 1/10W, 0603, 1%
R608 20K, THICK, FC, 1/10W, 0603, 1%
R609 0 OHM, THICK, FC, 1/10W, 0603, 1%
R610 20K, THICK, FC, 1/10W, 0603, 1%
R711 33 OHM, THICK, FC, 1/10W, 0603, 1%
R712 33 OHM, THICK, FC, 1/10W, 0603, 1%
R715 0 OHM, THICK, FC, 1/10W, 0603, 1%
R716 10K, THICK, FC, 1/10W, 0603, 1%
R726 20.0 OHM, 1/10W , 1%, 0603, SMD
R727 20.0 OHM, 1/10W , 1%, 0603, SMD
R728 0 OHM, THICK, FC, 1/10W, 0603, 1%
R729 0 OHM, THICK, FC, 1/10W, 0603, 1%
R730 0 OHM, THICK, FC, 1/10W, 0603, 1%
R731 100K, 1/10W, 1%, 0603, SMD
R732 100K, 1/10W, 1%, 0603, SMD
R733 100K, 1/10W, 1%, 0603, SMD
R737 0 OHM, THICK, FC, 1/10W, 0603, 1%
R738 0 OHM, THICK, FC, 1/10W, 0603, 1%
R739 0 OHM, THICK, FC, 1/10W, 0603, 1%
R740 0 OHM, THICK, FC, 1/10W, 0603, 1%
R741 0 OHM, THICK, FC, 1/10W, 0603, 1%
R742 0 OHM, THICK, FC, 1/10W, 0603, 1%
R745 10K, THICK, FC, 1/10W, 0603, 1%
R746 10K, THICK, FC, 1/10W, 0603, 1%
R747 11.3K, 1/10W, 1%, 0603, SMD
R748 11.3K, 1/10W, 1%, 0603, SMD
ELECTRICAL PART LIST
Analog Input PCB Assembly
Resistors (continued)
Description
35
Vendor Vendor Part Num ber
Name
Panasonic ERJ6ENF1000V
Panasonic ERJ3EKF2002V
Panasonic ERJ-3EKF2003V
Panasonic ERJ3EKF1002V
Panasonic ERJ3EKF1002V
Panasonic ERJ-3EKF8200V
Panasonic ERJ-3EKF8200V
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF19R1V
Panasonic ERJ-3EKF19R1V
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF2701V
Panasonic ERJ-3EKF1003V
Panasonic ERJ3EKF33R0V
Panasonic ERJ3EKF33R0V
Panasonic ERJ3EKF33R0V
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Panasonic ERJ3EKF2002V
Yageo RC0603FR-070RL
Panasonic ERJ3EKF2002V
Panasonic ERJ3EKF33R0V
Panasonic ERJ3EKF33R0V
Yageo RC0603FR-070RL
Panasonic ERJ3EKF1002V
Panasonic ERJ-3EKF20R0V
Panasonic ERJ-3EKF20R0V
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Panasonic ERJ-3EKF1003V
Panasonic ERJ-3EKF1003V
Panasonic ERJ-3EKF1003V
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Panasonic ERJ3EKF1002V
Panasonic ERJ3EKF1002V
Panasonic ERJ-3EKF1132V
Panasonic ERJ-3EKF1132V
Note
