Test Procedures - Bose ControlSpace ESP-880 Service Manual

Software Required:
• ®
ControlSpace Designer
•
ESP-88F Firmware V1.140 build 1 or later
•
ESP-88F DSP firmware version DSP: 1.2.0 build 0 or later
• ESP88C_Test_Macro_Rev_21b.atsb
• RedlineAudioPerformanceTestingModule01a.atsb
• RedlinePhantomTestingModule.atsb
•
Other items are described following part.
•
These files are for other products. Recommended to locate same folder.
−
ESP_ESP-00II_AcommandII01.atsb
−
ESP_GPIO-II.atsb
−
ESP_INPUT-II+OUTPUT-II
−
PMAES3IN.atsb
Test Overview
This test procedure is used for light-up-and-play testing of the ControlSpace ESP-880 ,
ESP-1240, ESP-4120 and ESP-1600.
This test use the DNC-R card for testing of expansion slot.
Definitions and Abbreviations
Definition
Term Definition
ESP-880 Digital audio processor with 1U chassis 3.5mm pitch connectors.
8 analog inputs / 8 analog outputs.
ESP-1240 Digital audio processor with 1U chassis 3.5mm pitch connectors.
12 analog inputs / 4 analog outputs.
ESP-4120 Digital audio processor with 1U chassis 3.5mm pitch connectors.
4 analog inputs / 12 analog outputs.
ESP-1600 Digital audio processor with 1U chassis 3.5mm pitch connectors.
16 analog inputs / 0 analog outputs. All outputs are digital, either
8 channels via ESPLink or 16 channels via plug-in Dante card.
These products do not include an expansion card. The card slot ships empty and is covered with
a blank panel.
Acronyms
Term
ESP
CSD
NIC
MAC
DUT
Expansion Slot
Expansion card
Dante Controller

TEST PROCEDURES

TM
, Rev 4.2 or later
Definition
ControlSpace Engineered Sound Processor with 2U chassis and 8 slot
expandable type.
ControlSpace Designer software
PC Ethernet Network Interface Card
Media Access Control address – unique identifier/physical address
Device Under Test
The space for the optional function modules.
The unit that provides optional function for ESP88F series.
The setting software for Dante network.
65
