Reference
Designator
C925
0.1uF, CER, 16V, 10% , X7R, 0402
C926
0.1uF, CER, 16V, 10% , X7R, 0402
C927
0.1uF, CER, 16V, 10% , X7R, 0402
C928
0.1uF, CER, 16V, 10% , X7R, 0402
C929
0.1uF, CER, 16V, 10% , X7R, 0402
C930
0.1uF, CER, 16V, 10% , X7R, 0402
C931
0.1uF, CER, 16V, 10% , X7R, 0402
C932
0.1uF, CER, 16V, 10% , X7R, 0402
C933
68uF, TANT, 6.3V, 10% , 1206
C934
68uF, TANT, 6.3V, 10% , 1206
C935
68uF, TANT, 6.3V, 10% , 1206
C936
68uF, TANT, 6.3V, 10% , 1206
C937
1uF, CER, 25V, X7R, 10%, 0603
C938
1000pF, CER, 25V, 10%, X7R, 0603
Reference
Designator
L201
S MT, FERRITE BEAD, 25%, 2A, 0805,
BLM21PG221SN1D
L251
CHIP EMI FILTER
L252
CHIP EMI FILTER
L401
S MT, FERRITE BEAD, 25%, 2A, 0805,
BLM21PG221SN1D
L801
Power inductor, shielded, 1.5uH, 30%, SMT
L802
Power inductor, shielded, 2.5uH, 30%, SMT
L831
Power inductor, shielded, 3.8uH, 30%, SMT
L832
S MT, FERRITE BEAD, 25%, 2A, 0805,
BLM21PG221SN1D
F201
E MI/RFI Suppressors & Ferrites
F202
E MI/RFI Suppressors & Ferrites
F203
E MI/RFI Suppressors & Ferrites
F204
E MI/RFI Suppressors & Ferrites
F401
E MI/RFI Suppressors & Ferrites
F402
E MI/RFI Suppressors & Ferrites
F404
E MI/RFI Suppressors & Ferrites
F405
E MI/RFI Suppressors & Ferrites
F406
E MI/RFI Suppressors & Ferrites
F407
E MI/RFI Suppressors & Ferrites
F651
E MI/RFI Suppressors & Ferrites
F652
E MI/RFI Suppressors & Ferrites
F653
E MI/RFI Suppressors & Ferrites
F654
E MI/RFI Suppressors & Ferrites
F655
E MI/RFI Suppressors & Ferrites
F656
E MI/RFI Suppressors & Ferrites
F657
E MI/RFI Suppressors & Ferrites
F658
E MI/RFI Suppressors & Ferrites
F659
E MI/RFI Suppressors & Ferrites
F660
E MI/RFI Suppressors & Ferrites
ELECTRICAL PART LIST
Main PCB Assembly
Capacitors (continued)
Description
Inductors and Ferrite Beads
Description
30
Vendor
Vendor Part Number
Name
Murata
GRM155R71C104KA88D
Murata
GRM155R71C104KA88D
Murata
GRM155R71C104KA88D
Murata
GRM155R71C104KA88D
Murata
GRM155R71C104KA88D
Murata
GRM155R71C104KA88D
Murata
GRM155R71C104KA88D
Murata
GRM155R71C104KA88D
Nichicon
F950J686KAAAQ2
Nichicon
F950J686KAAAQ2
Nichicon
F950J686KAAAQ2
Nichicon
F950J686KAAAQ2
Murata
GRM188R71E105KA12D
Murata
GRM033R71E102KA01D
Vendor
Vendor Part Number
Name
Murata
BLM21PG221SN1D
Murata
BLM31P500SPT
Murata
BLM31P500SPT
Murata
BLM21PG221SN1D
Coilcraft
MSS1038-152NLB
Coilcraft
MSS1038-252NLB
Coilcraft
MSS1038-382NLB
Murata
BLM21PG221SN1D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Murata
NFM21CC222R1H3D
Note
Note
