Bose ControlSpace ESP-880 Service Manual page 27

Reference
Designator
C295 0.1uF, CER, 16V, 10% , X7R, 0402
C296 0.1uF, CER, 16V, 10% , X7R, 0402
C297 0.1uF, CER, 16V, 10% , X7R, 0402
C298 0.1uF, CER, 16V, 10% , X7R, 0402
C299 0.1uF, CER, 16V, 10% , X7R, 0402
C300 0.1uF, CER, 16V, 10% , X7R, 0402
C301 0.1uF, CER, 16V, 10% , X7R, 0402
C302 0.1uF, CER, 16V, 10% , X7R, 0402
C303 0.1uF, CER, 16V, 10% , X7R, 0402
C304 0.1uF, CER, 16V, 10% , X7R, 0402
C305 0.1uF, CER, 16V, 10% , X7R, 0402
C306 0.1uF, CER, 16V, 10% , X7R, 0402
C307 0.1uF, CER, 16V, 10% , X7R, 0402
C308 0.1uF, CER, 16V, 10% , X7R, 0402
C309 0.1uF, CER, 16V, 10% , X7R, 0402
C310 0.1uF, CER, 16V, 10% , X7R, 0402
C311 0.1uF, CER, 16V, 10% , X7R, 0402
C312 33uF, TANT, 6.3V, 20% , 1206
C313 33uF, TANT, 6.3V, 20% , 1206
C314 33uF, TANT, 6.3V, 20% , 1206
C315 33uF, TANT, 6.3V, 20% , 1206
C351 0.1uF, CER, 16V, 10% , X7R, 0402
C353 0.1uF, CER, 16V, 10% , X7R, 0402
C354 0.1uF, CER, 16V, 10% , X7R, 0402
C355 0.1uF, CER, 16V, 10% , X7R, 0402
C356 22uF, TANT, 6.3V, 10% , 1206
C357 0.1uF, CER, 16V, 10% , X7R, 0402
C358 0.1uF, CER, 16V, 10% , X7R, 0402
C359 0.1uF, CER, 16V, 10% , X7R, 0402
C360 0.1uF, CER, 16V, 10% , X7R, 0402
C361 0.1uF, CER, 16V, 10% , X7R, 0402
C362 0.1uF, CER, 16V, 10% , X7R, 0402
C363 0.1uF, CER, 16V, 10% , X7R, 0402
C364 22uF, TANT, 6.3V, 10% , 1206
C365 0.1uF, CER, 16V, 10% , X7R, 0402
C366 22uF, TANT, 6.3V, 10% , 1206
C367 0.1uF, CER, 16V, 10% , X7R, 0402
C368 0.1uF, CER, 16V, 10% , X7R, 0402
C371 0.1uF, CER, 16V, 10% , X7R, 0402
C372 0.1uF, CER, 16V, 10% , X7R, 0402
C401 1uF, CER, 25V, X7R, 10%, 0603
C402 0.1uF, CER, 16V, 10% , X7R, 0402
C403 0.1uF, CER, 16V, 10% , X7R, 0402
C405 0.1uF, CER, 16V, 10% , X7R, 0402
C406 0.1uF, CER, 16V, 10% , X7R, 0402
C407 0.1uF, CER, 16V, 10% , X7R, 0402
C408 0.1uF, CER, 16V, 10% , X7R, 0402
C411 68uF, TANT, 6.3V, 10% , 1206
C412 0.1uF, CER, 16V, 10% , X7R, 0402
C413 68uF, TANT, 6.3V, 10% , 1206
C431 0.1uF, CER, 16V, 10% , X7R, 0402
C432 10uF, CER, 16V, 20% , X5R, 1206
C451 0.1uF, CER, 16V, 10% , X7R, 0402
C452 0.1uF, CER, 16V, 10% , X7R, 0402
C453 0.1uF, CER, 16V, 10% , X7R, 0402
C454 0.1uF, CER, 16V, 10% , X7R, 0402
C455 0.1uF, CER, 16V, 10% , X7R, 0402
ELECTRICAL PART LIST
Main PCB Assembly
Capacitors (continued)
Description
27
Vendor Vendor Part Number
Name
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Kemet T491A336M006AT
Kemet T491A336M006AT
Kemet T491A336M006AT
Kemet T491A336M006AT
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Kemet T491A226K006AT
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Kemet T491A226K006AT
Murata GRM155R71C104KA88D
Kemet T491A226K006AT
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM188R71E105KA12D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Kemet T491A686K006AT
Murata GRM155R71C104KA88D
Kemet T491A686K006AT
Murata GRM155R71C104KA88D
TDK C3216X5R1C106M
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Murata GRM155R71C104KA88D
Note
