Bose ControlSpace ESP-880 Service Manual page 52

Reference
Designator
C13 0.1uF, Ceramic, Radial, 630V
C14 1500uF, Electrolytic , Low-Z, Radial, 25V,
20%
C15 1500uF, Electrolytic , Low-Z, Radial, 25V,
20%
C16 27pF, CHIP, NPO, 50V, 5%, 0805
C17 27pF, CHIP, NPO, 50V, 5%, 0805
C18 220uF, SMD, E.CAP, 25V, +/-20%
C19 220uF, SMD, E.CAP, 25V, +/-20%
C20 100uF, Electrolytic, SMT, 25V, ±20%
C21 100uF, Electrolytic, SMT, 25V, ±20%
C22 100uF, Electrolytic, SMT, 25V, ±20%
C23 0.1uF, CHIP, X7R, 50V +/-10%, 0603
C24 47uF, Electrolytic , SMT, 35V, 20%
C25 330NF, X7R, 50V, 10%, +125-55C, 0805
C26 4.7uF, X7R, 25V, 10% , +85-55C, 1206
C27 4.7uF, X7R, 25V, 10% , +85-55C, 1206
C28 1uF, X7R, 25V, 10%, +125-55C, 0805
C29 1uF, X7R, 25V, 10%, +125-55C, 0805
C30 47pF, MLCC, NP0, 1kV, 10%
Reference
Designator
L1 Inductor, Common Mode B82732R2142B30
L2 3.3uH, Inductor, Shielded, SMT, 6A, 20%
L3 3.3uH, Inductor, Shielded, SMT, 2A, 20%
L4 3.3uH, Inductor, Shielded, SMT, 2A, 20%
Reference
Designator
BR1 SMT DIODE RECTIFIER, DF06S-T
D1 SMT DIODE RECTIFIER
D2 SMT DIODE RECTIFIER
D3 SMT DIODE, FAST RECOVERY, SMB
D4 SMT DIODE, Rectifier, Schottk y, 5A, 60V,
SMPC PKG
D5 SMT DIODE RECTIFIER
D6 SMT DIODE RECTIFIER
D7 ZENER, SMT, 20V, 300mW, 5%, SOT-23
D8 Sc hottky , 1A, 40V, SOD-123
D9 Sc hottky , 1A, 40V, SOD-123
ELECTRICAL PART LIST
Power Supply PCB Assembly
Capacitors (continued)
Description
Inductors
Description
Diodes
Description
52
Vendor Vendor Part Number
Name
Kemet C1808W104KBRACTU
Nichicon UPW 1E152MHD6
Nichicon UPW 1E152MHD6
Kemet C0805C270J 5GACTU
Kemet C0805C270J 5GACTU
Nichicon UCL1E221MNL1G S
Nichicon UCL1E221MNL1G S
Nichicon UCL1E101MCL1G S
Nichicon UCL1E101MCL1G S
Nichicon UCL1E101MCL1G S
Kemet C0603C104K5RACTU
Nichicon UUD1V470MCL1GS
Murata GRM219R71H334KA88D
Kemet C1206C475K3RACTU
Kemet C1206C475K3RACTU
Kemet C0805C105K3RAC
Kemet C0805C105K3RAC
Kemet C1206C470KDGACTU
Vendor Vendor Part Number
Name
Epcos B82732R2142B30
TDK SLF10165T-3R3N5R83PF
TDK VLC5020T-3R3N
TDK VLC5020T-3R3N
Vendor Vendor Part Number
Name
Diodes, Inc DF06S-T
Vishay- US1G-E3/61T
GenSemi
Vishay- ES1D-E3/61T
GenSemi
Vishay- US1MHE3/61T
GenSemi
Diodes, Inc PDS560-13
Vishay- ES1D-E3/61T
GenSemi
Vishay- ES1D-E3/61T
GenSemi
Diodes, Inc / BZX84C20-7-F
Digi-Key
ST Micro STPS140Z
ST Micro STPS140Z
Note
3
3
Note
Note
