Main Pcb Assembly - Bose ControlSpace ESP-880 Service Manual

Reference
Designator
D1 TVS, 24V, 400W , UNI, 5%, SMA
D2 TVS, 24V, 400W , UNI, 5%, SMA
D3 TVS, 24V, 400W , UNI, 5%, SMA
D4 TVS, 24V, 400W , UNI, 5%, SMA
D5 TVS, 24V, 400W , UNI, 5%, SMA
D6 TVS, 5.0V, 400W , UNI, 5%, SMA
D7 TVS, 5.0V, 400W , UNI, 5%, SMA
D8 TVS, 5.0V, 400W , UNI, 5%, SMA
D9 TVS, 5.0V, 400W , UNI, 5%, SMA
D10 TVS, 5.0V, 400W , UNI, 5%, SMA
D801 SWITCH, 100V, 400MW, SOD123
D861 S MT, DIODE, SCHO TTKY BARRIER, SC-59
D862 S MT, DIODE, SCHO TTKY BARRIER, SC-59
D863 S MT, DIODE, SCHO TTKY BARRIER, SC-59
D873 S MT, DIODE, SCHO TTKY BARRIER, SC-59
D875 S MT, DIODE, SCHO TTKY BARRIER, SC-59
D877 S MT, DIODE, SCHO TTKY BARRIER, SC-59
D879 S MT, DIODE, SCHO TTKY BARRIER, SC-59
D883 S MT, DIODE, SCHO TTKY BARRIER, SC-59
DS901 LED, GREEN/CLEAR, 1206, SMD
DS902 LED, GREEN/CLEAR, 1206, SMD
DS903 LED, GREEN/CLEAR, 1206, SMD
DS904 LED, GREEN/CLEAR, 1206, SMD
Reference
Designator
Q1 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q2 NPN, GP, SOT-23
Q3 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q4 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q5 NPN, GP, SOT-23
Q6 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q7 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q8 NPN, GP, SOT-23
Q9 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q10 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q11 NPN, GP, SOT-23
Q12 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q13 MOSFET, N-CH, 60V/200mA, SC59, T&R
Q14 NPN, GP, SOT-23
Q15 MOSFET, N-CH, 60V/200mA, SC59, T&R
Reference
Designator
U101 XOMAPL137DZKB4, DSP, CORE CONSIGN
U102 SINGLE POSITIVE AND GATE, SC-70
U351 SDRA M, 256MBIT, 133MHZ, 54VFBGA
U352 SDRA M, 256MBIT, 133MHZ, 54VFBGA
U371 Flash, Serial, 3V, 512M-Bit, 16-Pin, SOP-II
U372 256K-Bit, I2C, Serial, CMOS E EPROM
U401 TXRX, DUAL RS232, 3-5.5V, 16 SOIC
U402 DIFF BUS TRANSCEIVER, 8-SOP
U403 BUFF/DVR, TRI-ST, 8 BIT, 20TSSO
U451 BUFF/DVR, TRI-ST, 8 BIT, 20TSSO
U452 BUFF/DVR, TRI-ST, 8 BIT, 20TSSO
ELECTRICAL PART LIST

Main PCB Assembly

Diodes
Description
Transistors
Description
Integrated Circuits
Description
31
Vendor Vendor Part Number
Name
Littlefuse SMAJ24A
Littlefuse SMAJ24A
Littlefuse SMAJ24A
Littlefuse SMAJ24A
Littlefuse SMAJ24A
Littlefuse SMAJ5.0A
Littlefuse SMAJ5.0A
Littlefuse SMAJ5.0A
Littlefuse SMAJ5.0A
Littlefuse SMAJ5.0A
DIODES 1N4148W-7-F
Toshiba 1SS294S,LF
Toshiba 1SS294S,LF
Toshiba 1SS294S,LF
Toshiba 1SS294S,LF
Toshiba 1SS294S,LF
Toshiba 1SS294S,LF
Toshiba 1SS294S,LF
Toshiba 1SS294S,LF
Lite-on LTST-C150GKT
Lite-on LTST-C150GKT
Lite-on LTST-C150GKT
Lite-on LTST-C150GKT
Vendor Vendor Part Number
Name
Vishay 2N7002K-T1-E3
Fairchild MMBT5550
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Fairchild MMBT5550
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Fairchild MMBT5550
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Fairchild MMBT5550
Vishay 2N7002K-T1-E3
Vishay 2N7002K-T1-E3
Fairchild MMBT5550
Vishay 2N7002K-T1-E3
Vendor Vendor Part Number
Name
TI XOMAPL137DZKB4
TI SN74LVC1G08DCKR
Micron MT48LC16M16A2BG-7E:G
Micron MT48LC16M16A2BG-7E:G
Micron N25Q512A13GSF40F
ON CAT24C256W I-GT3
Intersil ICL3232EIBNZ-T
TI SN75176B
TI SN74LVC541APW
TI SN74LVC541APW
TI SN74LVC541APW
Note
Note
Note
