Introduction
A known good ESP-88F/ESP-00/ESP-00 II chassis is used as part of the test equipment for this
test series.
This test consists of an analog I/O section and a digital system section.
The analog I/O section of the test checks the audio performance of the system.
This ESP-88F/ESP-00/ESP-00 II chassis has expansion slots for several kinds of expansion
cards. These cards will not be tested as part of this test series.
In this testing, the ControlSpace
will be utilized for testing of the expansion slot in the UUT chassis.
Setup
Hardware Setup - Refer to Figures 6 through 10.
Equipment Requirements
Equipment Manuf.
ESP-880 Bose
ESP-1240 Bose
ESP-4120 Bose
ESP-1600 Bose
ATS-2 Audio Precision
ATS-2 I/F card Audio Precision
Switcher AuBit
ESP Bose
CC16 Emu AuBit
USB hub Various
PC Various
Ethernet switch Various
Ethernet Various
Router
DNC-R Bose
Note: *DNC-R can be connected by a crossover cable to the DNC-E card on ESP-88 or ESP-
00 without an Ethernet hub. To use a Dante controller, a hub will be needed.
TEST PROCEDURES
®
ESP-880/-1240/-4120/-1600 a known good Dante network card
Notes
DUT
DUT
DUT
DUT
Install in test PC. USB interface also possible to use.
Switcher MS101
Switcher MS111
10 Phantom Voltage checker
9 GPIO CARD
0 DSP MAIN CARD
1 DNC-E CARD
2 Open Slot
3 Open Slot
4 Open Slot
5 Open Slot
6 Open Slot
7 ADAT-IN audio card
8 AES3OUT audio card
CC-16 emulator. (1U type or ESP built-in type)
With USB cable for PC and AC adaptor
ATS 1.60 software compatible.
5 ports or greater. Specific to DNC-R card test. *
When the DHCP function will be tested, the Ethernet
router is required.
The expansion card for reference. *
