Bose ControlSpace ESP-880 Service Manual page 55

Reference
Designator
C105 0.1uF, 0603, Y5V, 50V, 85C, 20%
C106 0.1uF, 0603, Y5V, 50V, 85C, 20%
C107 0.1uF, 0603, Y5V, 50V, 85C, 20%
C108 0.1uF, 0603, Y5V, 50V, 85C, 20%
C109 0.1uF, 0603, Y5V, 50V, 85C, 20%
C110 0.1uF, 0603, Y5V, 50V, 85C, 20%
C200 1000pF, CER, Y5P, 2KV, 125C, 10%
C201 0.01uF, 0603, X7R, 50V, 125C, 10%
C202 0.01uF, 0603, X7R, 50V, 125C, 10%
C203 12pF, 0603, NPO, 50V, 125C, 5%
C204 12pF, 0603, NPO, 50V, 125C, 5%
C205 0.1uF, 0603, Y5V, 50V, 85C, 20%
C206 0.1uF, 0603, Y5V, 50V, 85C, 20%
C207 0.1uF, 0603, Y5V, 50V, 85C, 20%
C208 0.1uF, 0603, Y5V, 50V, 85C, 20%
C209 0.1uF, 0603, Y5V, 50V, 85C, 20%
C210 0.1uF, 0603, Y5V, 50V, 85C, 20%
C211 0.1uF, 0603, Y5V, 50V, 85C, 20%
C213 0.1uF, 0603, Y5V, 50V, 85C, 20%
C214 1000pF, CER, Y5P, 2KV, 125C, 10%
C300 0.1uF, 0603, Y5V, 50V, 85C, 20%
C301 22pF, 0603, NPO, 50V, 125C, 5%
C302 10uF, SMD E CAP, 16V, 105C, 20%
C400 0.1uF, 0603, Y5V, 50V, 85C, 20%
C401 0.1uF, 0603, Y5V, 50V, 85C, 20%
C402 0.1uF, 0603, Y5V, 50V, 85C, 20%
C403 0.1uF, 0603, Y5V, 50V, 85C, 20%
C404 0.01uF, 0603, X7R, 50V, 125C, 10%
C405 0.01uF, 0603, X7R, 50V, 125C, 10%
C406 0.01uF, 0603, X7R, 50V, 125C, 10%
C407 0.01uF, 0603, X7R, 50V, 125C, 10%
C408 0.01uF, 0603, X7R, 50V, 125C, 10%
C409 0.01uF, 0603, X7R, 50V, 125C, 10%
C410 0.01uF, 0603, X7R, 50V, 125C, 10%
C411 0.01uF, 0603, X7R, 50V, 125C, 10%
C412 0.01uF, 0603, X7R, 50V, 125C, 10%
C413 0.01uF, 0603, X7R, 50V, 125C, 10%
C500 220uF, SMD E CAP, 10V, 105C, 20%
C501 0.1uF, 0603, Y5V, 50V, 85C, 20%
C502 0.1uF, 0603, Y5V, 50V, 85C, 20%
C503 0.1uF, 0603, Y5V, 50V, 85C, 20%
C504 0.1uF, 0603, Y5V, 50V, 85C, 20%
C505 220uF, SMD E CAP, 10V, 105C, 20%
C507 0.1uF, 0603, Y5V, 50V, 85C, 20%
C508 0.1uF, 0603, Y5V, 50V, 85C, 20%
C509 10uF, E CAP, 16V, 105C, 20%
ELECTRICAL PART LIST
CC-64 Control Center
Capacitors (continued)
Description
55
Vendor
Vendor Part
Name Number
Samsung
CL10F104ZBNC
Samsung CL10F104ZBNC
CL10F104ZBNC
Samsung
Samsung
CL10F104ZBNC
Samsung
CL10F104ZBNC
CL10F104ZBNC
Samsung
ECKD3D102KBP
Panasonic
Samsung
CL10B103KBNC
CL10B103KBNC
Samsung
CL10C120JBNC
Samsung
Samsung CL10C120JBNC
Samsung
CL10F104ZBNC
CL10F104ZBNC
Samsung
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung
CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Panasonic ECKD3D102KBP
Samsung CL10F104ZBNC
Samsung CL10C220JBNC
Nichicon
UZT1C100MCR1GB
Samsung CL10F104ZBNC
CL10F104ZBNC
Samsung
CL10F104ZBNC
Samsung
Samsung
CL10F104ZBNC
CL10B103KBNC
Samsung
CL10B103KBNC
Samsung
Samsung
CL10B103KBNC
Samsung
CL10B103KBNC
CL10B103KBNC
Samsung
Samsung CL10B103KBNC
Samsung
CL10B103KBNC
CL10B103KBNC
Samsung
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Nichicon UWT1A221MCL1GS
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
CL10F104ZBNC
Samsung
Samsung
CL10F104ZBNC
Nichicon UWT1A221MCL1GS
CL10F104ZBNC
Samsung
CL10F104ZBNC
Samsung
Nichicon UZT1C100MCR1GB
