Analog Input Pcb Assembly - Bose ControlSpace ESP-880 Service Manual

Reference
Designator
JP12 UNSHROUDED, STRT THRU HOLE, 2 POS
JP14 UNSHROUDED, STRT THRU HOLE, 2 POS
JP101 UNSHROUDED, STRT THRU HOLE, 2 POS
JP831 UNSHROUDED, STRT THRU HOLE, 2 POS
Y1 CRYSTAL, 32.768KHZ, 12.5PF, SMD
Y2 O SC, CLOCK, 24.000000 MHZ, 3.3V, SMD
Reference
Designator
R101 6.8K, THICK, FC, 1/4W , 1210, 1%
R101 6.8K, THICK, FC, 1/4W , 1210, 1%
R103 39.0K, CHIP, 1/10W, 1% , 0603
R104 39.0K, CHIP, 1/10W, 1% , 0603
R106 3.3K, THICK, FC, 1/10W, 0603, 1%
R107 3.3K, THICK, FC, 1/10W, 0603, 1%
R111 200K, 1/8W, 1%, 0805, SMD
R112 100 OHM, THICK, FC, 1/8W, 0805, 1%
R113 20K, THICK, FC, 1/10W, 0603, 1%
R114 200K, 1/10W, 1%, 0603, SMD
R115 10K, THICK, FC, 1/10W, 0603, 1%
R116 10K, THICK, FC, 1/10W, 0603, 1%
R117 820 OHM, THICK, FC, 1/10W , 0603, 1%
R118 820 OHM, THICK, FC, 1/10W , 0603, 1%
R119 220 OHM, THICK, FC, 1/10W , 0603, 1%
R120 220 OHM, THICK, FC, 1/10W , 0603, 1%
R121 82.5 OHM, 1/10W , 1%, 0603, SMD
R122 82.5 OHM, 1/10W , 1%, 0603, SMD
R123 19.1 OHM, 1/10W , 1%, 0603, SMD
R124 19.1 OHM, 1/10W , 1%, 0603, SMD
R126 0 OHM, THICK, FC, 1/10W, 0603, 1%
R128 0 OHM, THICK, FC, 1/10W, 0603, 1%
R129 0 OHM, THICK, FC, 1/10W, 0603, 1%
R151 1.96K, THICK, FC, 1/10W, 0603, 1%
R152 1.96K, THICK, FC, 1/10W, 0603, 1%
R153 330 OHM, THICK, FC, 1/10W , 0603, 1%
R154 4.99K, THICK, 1/10W, 1%, 0603
R155 4.99K, THICK, 1/10W, 1%, 0603
R156 330 OHM, THICK, FC, 1/10W , 0603, 1%
R157 91 OHM, THICK, FC, 1/10W, 0603, 1%
R158 91 OHM, THICK, FC, 1/10W, 0603, 1%
R159 2.7K, THICK, FC, 1/10W, 0603, 1%
R201 6.8K, THICK, FC, 1/4W , 1210, 1%
R202 6.8K, THICK, FC, 1/4W , 1210, 1%
R203 39.0K, CHIP, 1/10W, 1% , 0603
R204 39.0K, CHIP, 1/10W, 1% , 0603
R206 3.3K, THICK, FC, 1/10W, 0603, 1%
R207 3.3K, THICK, FC, 1/10W, 0603, 1%
R211 200K, 1/8W, 1%, 0805, SMD
R212 100 OHM, THICK, FC, 1/8W, 0805, 1%
R213 20K, THICK, FC, 1/10W, 0603, 1%
R214 200K, 1/10W, 1%, 0603, SMD
R215 10K, THICK, FC, 1/10W, 0603, 1%
R216 10K, THICK, FC, 1/10W, 0603, 1%
R217 820 OHM, THICK, FC, 1/10W , 0603, 1%
R218 820 OHM, THICK, FC, 1/10W , 0603, 1%
ELECTRICAL PART LIST
Main PCB Assembly
Miscellaneous (continued)
Description

Analog Input PCB Assembly

Resistors
Description
33
Vendor Vendor Part Number
Name
FCI 77311-124-02LF
FCI 77311-124-02LF
FCI 77311-124-02LF
FCI 77311-124-02LF
Abracon ABS13-32.768k Hz
CTS 636L3C024M00000
Vendor Vendor Part Num ber
Name
Panasonic ERJ14NF6801U
Panasonic ERJ14NF6801U
Panasonic ERJ3EKF3902V
Panasonic ERJ3EKF3902V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-6ENF2003V
Panasonic ERJ6ENF1000V
Panasonic ERJ3EKF2002V
Panasonic ERJ-3EKF2003V
Panasonic ERJ3EKF1002V
Panasonic ERJ3EKF1002V
Panasonic ERJ-3EKF8200V
Panasonic ERJ-3EKF8200V
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF2200V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF82R5V
Panasonic ERJ-3EKF19R1V
Panasonic ERJ-3EKF19R1V
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Yageo RC0603FR-070RL
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF1961V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF4991V
Panasonic ERJ3EKF3300V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF91R0V
Panasonic ERJ3EKF2701V
Panasonic ERJ14NF6801U
Panasonic ERJ14NF6801U
Panasonic ERJ3EKF3902V
Panasonic ERJ3EKF3902V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-3EKF3301V
Panasonic ERJ-6ENF2003V
Panasonic ERJ6ENF1000V
Panasonic ERJ3EKF2002V
Panasonic ERJ-3EKF2003V
Panasonic ERJ3EKF1002V
Panasonic ERJ3EKF1002V
Panasonic ERJ-3EKF8200V
Panasonic ERJ-3EKF8200V
Note
Note
