Bose ControlSpace ESP-880 Service Manual page 41

Reference
Designator
R213 10K, THICK, FC, 1/10W, 0603, 1%
R214 10K, THICK, FC, 1/10W, 0603, 1%
R215 47 OHM, THICK, FC, 1/10W , 0603, 1%
R216 47 OHM, THICK, FC, 1/10W , 0603, 1%
R221 100K, THICK, FC, 1/10W, 0603, 1%
R222 47K, THICK, FC, 1/10W, 0603, 1%
R223 20K, THICK, FC, 1/10W, 0603, 1%
R224 4.99K, THICK, FC, 1/10W, 0603, 1%
R225 100K, THICK, FC, 1/10W, 0603, 1%
R226 100K, THICK, FC, 1/10W, 0603, 1%
R227 20K, THICK, FC, 1/10W, 0603, 1%
R228 1.00M, 1/10W , 1% , 0603, SMD
R229 1.00M, 1/10W , 1% , 0603, SMD
R251 10K, THICK, FC, 1/10W, 0603, 1%
R252 130 OHM, 1/10W, 1%, 0603, SMD
R253 130 OHM, 1/10W, 1%, 0603, SMD
R254, 10K, THICK, FC, 1/10W, 0603, 1%
R255 1.69K, 1/10W, 1%, 0603, SMD
R256 1.69K, 1/10W, 1%, 0603, SMD
R257 549 OHM, 1/10W, 1%, 0603, SMD
R258 3.30K, 1/10W, 1%, 0603, SMD
R259 549 OHM, 1/10W, 1%, 0603, SMD
R260 3.30K, 1/10W, 1%, 0603, SMD
R262 866 OHM, 1/10W, 1%, 0603, SMD
R263 866 OHM, 1/10W, 1%, 0603, SMD
R264 866 OHM, 1/10W, 1%, 0603, SMD
R265 866 OHM, 1/10W, 1%, 0603, SMD
R266 0 OHM, THICK, FC, 1/10W, 0603
R267 0 OHM, THICK, FC, 1/10W, 0603
R268 0 OHM, THICK, FC, 1/10W, 0603
R269 0 OHM, THICK, FC, 1/10W, 0603
R277 10K, THICK, FC, 1/10W, 0603, 1%
R278 10K, THICK, FC, 1/10W, 0603, 1%
R301 100K, THICK, FC, 1/10W, 0603, 1%
R302 100K, THICK, FC, 1/10W, 0603, 1%
R303 33 OHM, THICK, FC, 1/10W , 0603, 1%
R304 33 OHM, THICK, FC, 1/10W , 0603, 1%
R305 10 OHM, THICK, FC, 1/10W , 0603, 1%
R306 10 OHM, THICK, FC, 1/10W , 0603, 1%
R307 4.99K, THICK, FC, 1/10W, 0603, 1%
R308 4.99K, THICK, FC, 1/10W, 0603, 1%
R309 10K, THICK, FC, 1/10W, 0603, 1%
R310 10K, THICK, FC, 1/10W, 0603, 1%
R311 4.99K, THICK, FC, 1/10W, 0603, 1%
R312 4.99K, THICK, FC, 1/10W, 0603, 1%
R313 10K, THICK, FC, 1/10W, 0603, 1%
R314 10K, THICK, FC, 1/10W, 0603, 1%
R315 47 OHM, THICK, FC, 1/10W , 0603, 1%
R316 47 OHM, THICK, FC, 1/10W , 0603, 1%
R321 100K, THICK, FC, 1/10W, 0603, 1%
R322 47K, THICK, FC, 1/10W, 0603, 1%
R323 20K, THICK, FC, 1/10W, 0603, 1%
R324 4.99K, THICK, FC, 1/10W, 0603, 1%
R325 100K, THICK, FC, 1/10W, 0603, 1%
R326 100K, THICK, FC, 1/10W, 0603, 1%
R327 20K, THICK, FC, 1/10W, 0603, 1%
R328 1.00M, 1/10W , 1% , 0603, SMD
ELECTRICAL PART LIST
Analog Output PCB Assembly
Resistors (continued)
Description
41
Vendor Vendor Part Number
Name
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF47R0V
Panasonic ERJ 3EKF47R0V
Panasonic ERJ 3EKF1003V
Panasonic ERJ -3EKF4702V
Panasonic ERJ 3EKF2002V
Panasonic ERJ 3EKF4991V
Panasonic ERJ 3EKF1003V
Panasonic ERJ 3EKF1003V
Panasonic ERJ 3EKF2002V
Panasonic ERJ -3EKF1004V
Panasonic ERJ -3EKF1004V
Panasonic ERJ 3EKF1002V
Panasonic ERJ -3EKF1300V
Panasonic ERJ -3EKF1300V
Panasonic ERJ 3EKF1002V
Panasonic ERJ -3EKF1691V
Panasonic ERJ -3EKF1691V
Panasonic ERJ -3EKF5490V
Panasonic ERJ -3EKF3301V
Panasonic ERJ -3EKF5490V
Panasonic ERJ -3EKF3301V
Panasonic ERJ -3EKF8660V
Panasonic ERJ -3EKF8660V
Panasonic ERJ -3EKF8660V
Panasonic ERJ -3EKF8660V
Panasonic ERJ 3G EY0R00V
Panasonic ERJ 3G EY0R00V
Panasonic ERJ 3G EY0R00V
Panasonic ERJ 3G EY0R00V
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF1003V
Panasonic ERJ 3EKF1003V
Panasonic ERJ 3EKF33R0V
Panasonic ERJ 3EKF33R0V
Panasonic ERJ 3EKF10R0V
Panasonic ERJ 3EKF10R0V
Panasonic ERJ 3EKF4991V
Panasonic ERJ 3EKF4991V
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF4991V
Panasonic ERJ 3EKF4991V
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF1002V
Panasonic ERJ 3EKF47R0V
Panasonic ERJ 3EKF47R0V
Panasonic ERJ 3EKF1003V
Panasonic ERJ -3EKF4702V
Panasonic ERJ 3EKF2002V
Panasonic ERJ 3EKF4991V
Panasonic ERJ 3EKF1003V
Panasonic ERJ 3EKF1003V
Panasonic ERJ 3EKF2002V
Panasonic ERJ -3EKF1004V
