ControlSpace
ESP-880,
ESP-1240, ESP-4120 and ESP-1600
Engineered Sound Processors
and CC-16 and CC-64 Controllers
(US and non-US units)
includes Dante Wallplates and Endpoint Accessories
©2015 Bose Corporation
Service Manual
Reference Number 359862-SM Rev. 01
