Bose ControlSpace ESP-880 Service Manual page 25

Reference
Designator
R904 330 OHM, 1/10W , 1%, 0603, SMD
R905 51.0K, OHM, 1/10W, 1%, 0402, SMD
R906 51.0K, OHM, 1/10W, 1%, 0402, SMD
R907 51.0K, OHM, 1/10W, 1%, 0402, SMD
R908 51.0K, OHM, 1/10W, 1%, 0402, SMD
R909 51.0K, OHM, 1/10W, 1%, 0402, SMD
R911 51.0K, OHM, 1/10W, 1%, 0402, SMD
R912 51.0K, OHM, 1/10W, 1%, 0402, SMD
R913 51.0K, OHM, 1/10W, 1%, 0402, SMD
R914 51.0K, OHM, 1/10W, 1%, 0402, SMD
R915 51.0K, OHM, 1/10W, 1%, 0402, SMD
R916 51.0K, OHM, 1/10W, 1%, 0402, SMD
R917 51.0K, OHM, 1/10W, 1%, 0402, SMD
R918 20.0K, 1/10W, 1%, 0402, SMD
R919 20.0K, 1/10W, 1%, 0402, SMD
R920 20.0K, 1/10W, 1%, 0402, SMD
R921 20.0K, 1/10W, 1%, 0402, SMD
R927 470 OHM, 1/10W , 1%, 0603, SMD
R928 10 OHM, 1%, 1/8W, 0603, SMD
R929 10 OHM, 1%, 1/8W, 0603, SMD
R930 10 OHM, 1%, 1/8W, 0603, SMD
R931 10 OHM, 1%, 1/8W, 0603, SMD
R932 10 OHM, 1%, 1/8W, 0603, SMD
R934 470 OHM, 1/10W , 1%, 0603, SMD
R936 470 OHM, 1/10W , 1%, 0603, SMD
R938 470 OHM, 1/10W , 1%, 0603, SMD
R942 470 OHM, 1/10W , 1%, 0603, SMD
R943 10.0K, 1/10W, 1%, 0402, SMD
R944 10.0K, 1/10W, 1%, 0402, SMD
R945 10.0K, 1/10W, 1%, 0402, SMD
R946 10.0K, 1/10W, 1%, 0402, SMD
R947 10.0K, 1/10W, 1%, 0402, SMD
R949 1.0K, 1/10W, 1%, 0402, SMD
R950 1.0K, 1/10W, 1%, 0402, SMD
R951 1.0K, 1/10W, 1%, 0402, SMD
R952 1.0K, 1/10W, 1%, 0402, SMD
R953 1.0K, 1/10W, 1%, 0402, SMD
R954 1.50K, 1/10W, 1%, 0603, SMD
R955 51.0K, OHM, 1/10W, 1%, 0402, SMD
R956 51.0K, OHM, 1/10W, 1%, 0402, SMD
R957 22.0 OHM, 1/10W , 1%, 0402, SMD
R958 22.0 OHM, 1/10W , 1%, 0402, SMD
R959 1.0K, 1/10W, 1%, 0402, SMD
R960 1.0K, 1/10W, 1%, 0402, SMD
R961 1.0K, 1/10W, 1%, 0402, SMD
R962 1.0K, 1/10W, 1%, 0402, SMD
R963 1.0K, 1/10W, 1%, 0402, SMD
R968 0.0 OHM, 1/10W , 0402, SMD
RN231 RES ARRAY, 22 OHM, 8 RES, 1506
RN232 RES ARRAY, 22 OHM, 8 RES, 1506
RN270 RES ARRAY, 22 OHM, 8 RES, 1506
RN271 RES ARRAY, 10 OHM, 8 RES, 1506
RN272 RES ARRAY, 10 OHM, 8 RES, 1506
RN273 RES ARRAY, 10 OHM, 8 RES, 1506
RN274 RES ARRAY, 10 OHM, 8 RES, 1506
RN275 RES ARRAY, 22 OHM, 8 RES, 1506
RN351 RES ARRAY, 10 OHM, 8 RES, 1506
RN352 RES ARRAY, 10 OHM, 8 RES, 1506
RN353 RES ARRAY, 10 OHM, 8 RES, 1506
RN354 RES ARRAY, 10 OHM, 8 RES, 1506
ELECTRICAL PART LIST
Main PCB Assembly
Resistors (continued)
Description
25
Vendor Vendor Part Number
Name
Panas onic ERJ-3EKF3300V
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF2002X
Panas onic ERJ-2RKF2002X
Panas onic ERJ-2RKF2002X
Panas onic ERJ-2RKF2002X
Panas onic ERJ-3EKF4700V
Panas onic RNCP0603FTD10R0
Panas onic RNCP0603FTD10R0
Panas onic RNCP0603FTD10R0
Panas onic RNCP0603FTD10R0
Panas onic RNCP0603FTD10R0
Panas onic ERJ-3EKF4700V
Panas onic ERJ-3EKF4700V
Panas onic ERJ-3EKF4700V
Panas onic ERJ-3EKF4700V
Panas onic ERJ-2RKF1002X
Panas onic ERJ-2RKF1002X
Panas onic ERJ-2RKF1002X
Panas onic ERJ-2RKF1002X
Panas onic ERJ-2RKF1002X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-3EKF1501V
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF5102X
Panas onic ERJ-2RKF22R0X
Panas onic ERJ-2RKF22R0X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2RKF1001X
Panas onic ERJ-2GE0R00X
Panas onic EXB-2HV220JV
Panas onic EXB-2HV220JV
Panas onic EXB-2HV220JV
Panas onic EXB-2HV100JV
Panas onic EXB-2HV100JV
Panas onic EXB-2HV100JV
Panas onic EXB-2HV100JV
Panas onic EXB-2HV220JV
Panas onic EXB-2HV100JV
Panas onic EXB-2HV100JV
Panas onic EXB-2HV100JV
Panas onic EXB-2HV100JV
Note
