3. FIRST POWER-ON, CONTROL SYSTEM, AND INITIAL CHECK

Do not turn the amplifier on for at least 2 hours after unpacking it in the room where it
will be used. Pay particular attention when you move it from a very cold into a warm
place - condensation is likely and this could result in damage to the high voltage circuits.
In such a case, wait at least 4 hours. A similar effect can occur after a rapid warming of
the operating room (for instance after switching on a powerful heater in a cold shack).
After following all instructions in Section
rocker switch is turned OFF (see
mains plug into the wall outlet prepared for it. The amplifier remains switched off.

Figure 3-1 | Amplifier and RCU Front panels - Controls and Readouts

a)
Figure 3-1 | Amplifier and RCU Front panels - Controls and Readouts

Low Energy STANDBY Mode of the Power Supply

3.1.
Now you can turn on the amplifier's mains rocker switch (see
Pos. 3). This will activate only the low-energy STANDBY mode of the amplifier power supply and the red LED
on amplifier's front panel will light up (see
Pos. (a)), as well as the red LED on RCU's front panel will light up also (see
Front panels - Controls and Readouts
display is dark (see
Figure 3-1 | Amplifier and RCU Front panels - Controls and Readouts
Page 28 of 76 | S e c t i o n FIRST POWER-ON, CONTROL SYSTEM, AND INITIAL CHECK
User's Manual | ACOM 2020S | 1.8-54 MHz Linear Power Amplifier
NOTICE
2 INSTALLATION
Figure 2-3 | Amplifier rear panel - Connections
Figure 3-1 | Amplifier and RCU Front panels - Controls and Readouts
, Pos. (b)), while the amplifier's main power supply is still off and the RCU
, check whether the amplifier's rear panel mains
, Pos. 3). Then insert amplifier's
Figure 2-3 | Amplifier rear panel - Connections
Figure 3-1 | Amplifier and RCU
c)
b)
, Pos. (c)).
