Replaceable Mechanical Parts - 576
I
Fig.
&
.~
Index Tektronix
Serial/Assembly
No. Mfr.
No.
Part
No.
Effective
Dscont
Q!;t
12345
Milne &
Descri
I!!
ion
Cede
Mfr.
Part
No.
2- 672-0932-00 6010100 8359650 1 CIRCUIT BD ASSY:CURRENT/DIV 80009 672-0932-00
672-0932-01 8359651
1
CIRCUIT BD ASSY:VERT CURRENT/DIY 80009 672-0932-01
-1
----- -----
1 .CKT BOARD ASSY:VERTICAL CURRENT,DIV SW
I
.(PART OF 672-0932-XX)
-2 - 131-()633-00
30 .. TERMINAL,PIN:0.385 LX 0.048 OD 8RS TIN 80009 131-0633-00
-3
131-0639-00 12 .. CONTACT,ELEC:SPR CLIP TYPE 22526 44642
-4
131-0604-00 30 .. CONTACT,ELEC:CKT BD SW,SPR,CU BE 80009 131-0604-QO
263-1195-00 6010100
8359650 1 .SW CAM ACTR AS:CURRENT/DIV 80009 263-1195-00
I
263-1195-01 8359651 1 .SW CAM ACTR AS:VERT CURRENT/DIY 80009 263-1195-01
407-0653-00 B100000 8359650 1 .. BRACKET,COVER:CAM SWITCH,DELRIN 80009 407-0653-00
407-1199-04 8359651 1 .. BRACKET,COVER:PLASTIC 80009 407 -1199-Q4
.. (ATTACHING PARTS)
I
211-0116-00 B100000 8359650
2
.. SCR,ASSEM WSHR:4-40 X 0.312,PNH,BRS,NP,POZ 77900 ORDER BY DESCR
211-0292-00 8359651 2 .. SCR,ASSEM WSHR:4-40 X 0.29,PNH,BRS NI PL 78189 51-040445-01
210-0406-00 B100000
2
.. NUT,PLAIN,HEX:4-40 X 0.188,BRS CD PL 73743 12161-50
.. (END ATTACHING PARTS)
-5 401-0054-00 6010100
8359650
.. 8EARING,CAM SW:FRONT, 80009 401-0054-00
I
401-0178-08 8359651 .. BEARING,CAM SW:REAR 80009 401-0178-08
.. (ATTACHING PARTS)
-6 211-0116-00
2
.. SCR,ASSEM WSHR:4-40 X 0.312,PNH,BRS,NP,POZ 77900 ORDER BY DESCR
-7 210-0406-00
2 .. NUT,PLAIN,HEX:4-40 X 0.188,BRS CD PL
73743 12161-50
I
.. (END ATTACHING PARTS)
-8 354-0219-00 6010100 8359650 1 .. RING,RETAINING:EXT,CRESCENT,U/0 0.25 DIA 79136 5103-25-S-ZD-R
354-0390-00 8359651 1 .. RING,RETAINING:BASIC EXT,U/0 0.375 DIA SFT 79136 5100-37-ZD
-9 214-1127-00 6010100 8359650 1 .. ROLLER,DETENT:0.125 DIA X 0.125,SST 80009 214-1127-00
214-1752-00 8359651
2
.. ROLLER,DETENT:0.125 00 X 0.16,SST 80009 214-1752-00
I
-10 214-1139-02 6010100
8359650 1 .. SPRING,FLAT:0.885 X 0.156 CUBE GRN CLR 80009 214-1139-02
214-1139-03 6010100
8359650 1
.. SPRING,FLAT:0.885 X 0.156 CUBE RED CLR 80009 214-1139-03
214-1139-03 8359651 2 .. SPRING,FLAT:0.885 X 0.156 CUBE RED CLR 80009 214-1139-03
-11
105-0085-00 6010100 8359650 1 .. ACTUATOR,CAM SW:VERT CUR/DIV 80009 105-0085-00
I\.
105-0085-04 8359651 1 .. ACTUATOR,CAM SW:VERT CUR/DIV 80009 105-0085-04
384-1642-00 8359651
1 .. SHAFT,CAM SW:W/EXTENTION AND DRIVER
80009 384-1642-00
-12 401-0056-00 6010100 8359650 1 .. BEARING,CAM SW:REAR,0.83 DIA CAM 80009 401-0056-00
401-0180-04 8359651
1 .. BEARING,CAM SW:FRONT,W/INSERTS
80009 401-0180-04
.. (ATTACHING PARTS)
I
-13 211-0116-00 6010100
8359650 2
.. SCR,ASSEM WSHR:4-40 X 0.312,PNH,BRS,NP,POZ 77900 ORDER BY DESCR
211-0292-00 8359651 2 .. SCR,ASSEM WSHR:4-40 X 0.29,PNH,BRS NI PL 78189 51-040445-01
-14
210-0406-00 2 .. NUT,PLAIN,HEX:4-40 X 0.188,BRS CD PL 73743 12161-50
• .. (END ATTACHING PARTS)
I
-15 263-0511-00 .. SW SECTION,RTRY:15 DEG,VERT CURRENT/DIY 80009 263-0511-00
.. (ATTACHING PARTS)
-16 211-0100-00 6010100 8359650 2 .. SCREW,MACHINE:2-56 X 0.750,PNH,STL 83385 ORDER BY DESCR
211-0022-00 8359651
2
.. SCREW,MACHINE:2-56 X 0.188,PNH,STL TK0435 ORDER BY DESCR
210-0001-00 8359651 2 .. WASHER,LOCK:#2 INTL,0.013 THK,STL 77900 1202-00-00-0541C
I
210-0053-00 6010100
8359650 2
.. WASHER,LOCK:#2 SPLIT,0.02 THK STL 78189 ORDER BY DESCR
-17 210-0405-00 6010100
8359650 2 .. NUT ,PLAIN,HEX:2-56 X 0.188,BRS CO PL
73743 12157-50
210-0406-00 8359651 2 .. NUT,PLAIN,HEX:4-40 X 0.188,BRS CD PL 73743 12161-50
.. (END ATTACHING PARTS)
I
361-0219-00 8359651 2 .. SPACER,SLEEVE:0.06 LX 0.093 ID,BRS 80009 361-0219-00
386-3069-00 8359651 1 .. PLATE, SW MTG:BAND 80009 386-3069-00
-18
200-0940-00 B010100 B099999 1 .. COVER,CAM SW:30 ELEMENTS 80009 200-0940-00
200-0940-01 B100000
8359650 1 .. COVER,CAM SW:30 ELEMENTS
80009 200-0940-01
200-2717-00 8359651
1 .. COVER, CAM SW:40 ELEMENT
80009 200-2717-00
I
.. (ATTACHING PARTS)
-19
211-0079-00 6010100 B099999 2 .. SCREW,MACHINE:2-56 X 0.188,PNH,STL TK0435 5549-418
211-0079-00 B100000
8359650 4
.. SCREW,MACHINE:2-56 X 0.188,PNH,STL TK0435 5549-418
211-0292-00 8359651 2 .. SCR,ASSEM WSHR:4-40 X 0.29,PNH,BRS NI PL 78189 51-040445-01
I
210-0001-00 6010100
B099999 2
.. WASHER,LOCK:#2 INTL,0.013 THK,STL 77900 1202-00-00-0541C
210-0001-00 B100000 4 .. WASHER,LOCK:#2 INTL,0.013 THK,STL 77900 1202-00-00-0541C
-20 210-0405-00 6010100 B099999 2 .. NUT,PLAIN,HEX:2-56 X 0.188,BRS CD PL 73743 12157-50
210-0405-00 B100000 8359650 4
.. NUT,PLAIN,HEX:2-56 X 0.188,BRS CD PL 73743 12157-50
210-0406-00 8359651 4 .. NUT,PLAIN,HEX:4-40 X 0.188,BRS CD PL 73743 12161-50
1
.. (END ATTACHING PARTS)
.. (ATTACHING PARTS FOR CKT BD ASSY)
-21 211-0601-00 SCR,ASSEM WSHR:6-32 X 0.312,PNH,BRS NP,POZ
TK0435 ORDER BY DESCR
~
210-0012-00
WASHER,LOCK:0.384 ID,INTL,0.022 THK,STL 09772 ORDER BY DESCR
210-0978-00
WASHER,FLAT:0.375 ID X 0.5 00 X 0.024,STL 12327 ORDER BY DESCR
l
210-0590-00
NUT,PLAIN,HEX:0.375-32 X 0.438 BRS CD PL 73743 28269-402
1
