SuperServer

SYS-210P-FRDN6T

USER'S MANUAL

Revision 1.0d

Table of Contents

Troubleshooting

Need help?

Do you have a question about the SuperServer SYS-210P-FRDN6T and is the answer not in the manual?

Questions and answers

Summary of Contents for Supermicro SuperServer SYS-210P-FRDN6T

Page 1 SuperServer ® SYS-210P-FRDN6T USER’S MANUAL Revision 1.0d...
Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
Page 3: About This Manual
If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...
Page 4: Table Of Contents
Contents Contents Chapter 1 Introduction 1.1 Overview ..........................9 1.2 System Features ........................10 Front View .........................10 Control Panel .........................13 Rear View ..........................14 1.3 System Architecture ......................15 PCB Locations ........................15 1.4 Motherboard Layout ......................16 Quick Reference Table ......................17 Motherboard Block Diagram .....................19 Chapter 2 Server Installation 2.1 Overview ..........................20 2.2 Preparing for Setup ......................20...
Page 5 Contents Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................30 3.2 Accessing the Chassis .......................31 3.3 Static-Sensitive Devices ......................32 Precautions ........................32 3.4 Processor and Heatsink .....................33 Prepare the System ......................33 ESD Precautions .......................33 Overview of the Processor Carrier Assembly ..............34 Overview of the CPU Socket ....................34 Overview of the Processor Heatsink Module ..............35 Creating the 3rd Generation Intel®...
Page 6 Contents Chapter 4 Motherboard Connections 4.1 Power Connections ......................58 Control Panel .........................60 4.2 Headers and Connectors ....................63 4.3 Input/Output Ports ......................69 4.4 Jumpers ..........................72 How Jumpers Work ......................72 4.5 LED Indicators ........................74 Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................76 5.2 Driver Installation ........................78 5.3 SuperDoctor 5 ........................79...
Page 7 Contents 6.8 Reporting an Issue ......................93 Technical Support Procedures ..................93 Returning Merchandise for Service ...................93 Vendor Support Filing System ..................94 6.9 Feedback ..........................94 Appendix A Standardized Warning Statements for DC Systems Appendix B System Specifications...
Page 8: Contacting Supermicro
San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
Page 9: Chapter 1 Introduction
2U 17.2 x 3.5 x 11.8in. / 437 x 89 x 299mm (WxHxD) A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with SYS-210P-FRDN6T have been certified as compliant...
Page 10: System Features
Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Handle Dedicated IPMI LAN Port Handle DC Power Supply Dual Function Switch COM Port GbE RJ45 Ports VGA Port 10G RJ45 Ports Control Panel...
Page 11 Chapter 1: Introduction System Features: Rear Feature Description Control Panels Control panel with power button, UID LED, BMC reset, and LEDs. Power Supplies SYS-210P-FRDN6T: Two 600 W redundant DC power supplies COM Port One COM port VGA Port One video port USB Ports Two USB 2.0 ports and two USB 3.0 ports LAN Ports...
Page 12 Chapter 1: Introduction Expansion Slot Locations Item Description (all PCIe 4.0) Riser Card x8 low-profile, configurable to x16 if merged with slot 2 RSC-H2-68G4 x8 low-profile or disabled when merged with slot 1 RSC-H2-68G4 x8 FHHL (with 1U heatsink and CPU TDP less than 165W RSC-S2R-68G4 and air shroud) RSC-S2R-68G4...
Page 13: Control Panel
Chapter 1: Introduction Control Panel Power BMC Reset Power LED Drive LED NIC (LAN2) LED NIC (LAN1) LED Information LED Power Fail LED Figure 1-2. Control Panel Control Panel Features Feature Description The main power switch applies or removes primary power from the power supply to the server Power button but maintains standby power.
Page 14: Rear View
Chapter 1: Introduction Rear View Figure 1-3. System: Rear View System Features: Rear Feature Description Fans Four internal fans...
Page 15: System Architecture
Chapter 1: Introduction 1.3 System Architecture This section covers the printed circuit board (PCB) locations. PCB Locations Motherboard Power Distribution Board Backplane Riser Card Riser Card Riser Card Figure 1-4. PCB Locations...
Page 16: Motherboard Layout
Chapter 1: Introduction 1.4 Motherboard Layout Below is a layout of the X12SPM-LN6TF motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4 or the Motherboard Manual.
Page 17: Quick Reference Table
Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JPL1 LAN3/4/5/6 Enable/Disable Pins 1-2 (Enabled) JPME2 ME Recovery Pins 1-2 (Normal) JPTG1 LAN1/2 (10G Base-T) Enable/Disable Pins 1-2 (Enabled) Description Status LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal LEDPWR Power on LED...
Page 18 Chapter 1: Introduction Connector Description M.2-H M.2 M-Key 2280/22110 Slot (supports PCIe 3.0 x4/SATA3) SLOT4 CPU PCIe 4.0 x16 SLOT6 CPU PCIe 4.0 x16 SLOT7 CPU PCIe 4.0 x8 S-SATA0, S-SATA1 SATA 3.0 Ports with SATA DOM Power S-SGPIO1 Serial Link General Purpose I/O Connection Header TPM1/PORT80 Trusted Platform Module (TPM)/Port 80 Connector USB0/1...
Page 19: Motherboard Block Diagram
Chapter 1: Introduction Motherboard Block Diagram DIMMG1 DIMMC1 DIMMH1 DIMMD1 DIMME1 DIMMA1 DIMMF1 DIMMB1 PCI-E X16-Gen4 JPCIE4 PE2[0:15] PCI-E X4-Gen4 RJ45 PE0[0:3] Rear I/O intel PCI-E X16-Gen4 10G *2 NCSI JPCIE6 X550-AT2 PE1[0:15] PCI-E X8-Gen4 JPCIE7 PE0[8:15] PCI-E X4-Gen4 intel RJ45 Rear I/O PE0[4:7]...
Page 20: Chapter 2 Server Installation
Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with system memory etc., refer to Chapter 3 details on installing those specific components.
Page 21: Rack Precautions
Chapter 2: Server Installation Warning: The intra-building port(s) (10Gb DAC SFP and 100Gb DAC QSFP ports) of the equipment or subassembly must use shielded intra-building cabling/wiring that is grounded at both ends. Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them.
Page 22: Airflow
Chapter 2: Server Installation Airflow Equipment should be mounted into a rack so that the amount of airflow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.
Page 23: Identifying The Rack Rails
Chapter 2: Server Installation 2.3 Identifying the Rack Rails The chassis package includes outer and inner rack rail assemblies in the rack mounting kit. Left Right Secure to the Front of the Rack Secure to the Rear of the Rack Figure 2-1.
Page 24: Installing The Inner Rails
Chapter 2: Server Installation 2.4 Installing the Inner Rails The inner rails can be installed onto the chassis without any tools. Figure 2-3. Installing the Inner Rails Installing the Inner Rails 1. Place the inner rail on the side of the chassis aligning the hooks of the chassis with the inner rail holes.
Page 25: Installing The Outer Rails To The Rack
Chapter 2: Server Installation 2.5 Installing the Outer Rails to the Rack Outer rails attach to the rack and hold the server in place. The outer rails for the chassis extend between 18 inches and 24 inches. Installing the Outer Rails to the Rack 1.
Page 26: Installing The Chassis Into The Rack
Chapter 2: Server Installation 2.6 Installing the Chassis into the Rack The chassis is secured to the rack with the locking tabs on the inner rails and two front screws. Installing the Chassis into the Rack 1. Confirm that the chassis includes the inner rails and rail extensions. Also, confirm that the outer rails are installed on the rack.
Page 27: Removing The Chassis From The Rack
Chapter 2: Server Installation Figure 2-6. Installing Front Screws onto the Rack Note: Figures are for illustrative purposes only. Always install servers to the bottom of a rack first. 2.7 Removing the Chassis from the Rack To remove the chassis from the rack, perform the installation steps in reverse. Removing the Chassis 1.
Page 28: Connecting Power And Ground In A Nebs Environment
Safety Ground, indicated by “Earth GND Symbol”. (Optional because Chassis GND stud is connected) • +Return, positive terminal (Battery Return, BR). Supermicro provides a cable for connection to the DC power supply. You should use the provided cable or an equivalent cable with the following specifications: • Positronic CBD connector.
Page 29: Chassis Ground Stud Connections For Dc Systems
Chapter 2: Server Installation Note: The SYS-210P-FRDN6T is DC-I and can be grounded in both CBN and IBN networks. It is suitable for installation in Network Telecommunication Facilities and in locations where the NEC applies. Connection of the +Return (BR) supports both North America, Isolated GP (single point connection to CBN) and Europe, Integrated GP (Multiple point connection to CBN) configurations.
Page 30: Chapter 3 Maintenance And Component Installation
Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.
Page 31: Accessing The Chassis
Chapter 3: Maintenance and Component Installation 3.2 Accessing the Chassis The top cover is removable to access the chassis components. Removing the Top Cover 1. Remove two screws and slide the cover back and off. Caution: Except for short periods of time, do not operate the server without the cover in place. The chassis cover must be in place to allow for proper airflow and to prevent overheating.
Page 32: Static-Sensitive Devices
Chapter 3: Maintenance and Component Installation 3.3 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic components. To avoid damaging your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect the system PCBs from ESD. Precautions •...
Page 33: Processor And Heatsink
3. Check that the plastic protective cover is on the CPU socket and that none of the socket pins are bent. If they are, contact your retailer. 4. Refer to the Supermicro website for updates on processor and memory support. Note: All graphics in this manual are for illustration only. Your components may look different.
Page 34: Overview Of The Processor Carrier Assembly
Chapter 3: Maintenance and Component Installation Overview of the Processor Carrier Assembly The processor carrier assembly contains the Intel Xeon Scalable Family 3rd Gen/4th Gen Series and a processor carrier. 1. Processor 2. Processor Carrier Overview of the CPU Socket The CPU socket is protected by a plastic protective cover.
Page 35: Overview Of The Processor Heatsink Module
Chapter 3: Maintenance and Component Installation Overview of the Processor Heatsink Module The Processor Heatsink Module (PHM) contains a heatsink, a processor carrier, and the. 1. Heatsink with Thermal Grease 2. Processor Carrier 3. Processor...
Page 36: Creating The 3Rd Generation Intel® Xeon® Scalable Processors Carrier Assembly
CPU Pin 1 Processor Carrier Assembly Note: The following CPU carriers have been successfully tested in our labs and are available from Supermicro. Please order the CPU carriers with the CPU heatsink. SKT-1205L-P4IC-FXC Intel 3rd Generation Xeon Scalable Processors...
Page 37: Assembling The Processor Heatsink Module
Chapter 3: Maintenance and Component Installation Assembling the Processor Processor Carrier Assembly Heatsink Module (Upside Down) After creating the processor carrier assembly for the processor, mount it onto the heatsink to create the processor heatsink module (PHM): 1. Note the label on top of the heatsink, which marks the heatsink mounting holes as 1, 2, 3, and 4.
Page 38: Preparing The Cpu Socket For Installation
Chapter 3: Maintenance and Component Installation Preparing the CPU Socket for Installation This motherboard comes with a plastic protective cover installed on the CPU socket. Remove it from the socket to install the Processor Heatsink Module (PHM). Gently pull up one corner of the plastic protective cover to remove it.
Page 39: Installing The Processor Heatsink Module
Chapter 3: Maintenance and Component Installation Installing the Processor Heatsink Module After assembling the Processor Heatsink Module (PHM), install it onto the CPU socket: 1. Align hole 1 of the heatsink with the printed triangle on the CPU socket. See the left image below.
Page 40: Removing The Processor Heatsink Module
Chapter 3: Maintenance and Component Installation Removing the Processor Heatsink Module Before removing the processor heatsink module Remove the screws in the sequence of 4, 3, 2, 1 (PHM) from the motherboard, shut down the system and then unplug the AC power cord from all power supplies.
Page 41: Memory
Chapter 3: Maintenance and Component Installation 3.5 Memory The X12SPM-LN6TF supports up to 2048 GB of ECC RDIMM/LRDIMM/LRDIMM 3DS with speeds of up to 3200 MHz in eight slots. Refer to the tables below for the recommended DIMM population order and additional memory information. 1 CPU, 8-DIMM Slots Number of DIMMs Memory Population Sequence...
Page 42: Dimm Installation
Chapter 3: Maintenance and Component Installation DIMM Installation UID_LED1 JUIDB1 JLANLED1 JLANLED2 JIPMB1 SRW1 SRW1 1. Insert the desired number of DIMM modules USB6/7 (3.0) JVRM2 AST2600 USB0/1 LEDM1 JVRM1 LAN5/6 LAN3/4 IPMI_LAN COM1 based on the recommended DIMM population LAN1/2 JNVI2C1 SRW2...
Page 43: Motherboard Battery
Chapter 3: Maintenance and Component Installation 3.6 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing the top cover from the system. 1.
Page 44: Storage Drives
The CSE-211M-R000NDP chassis supports up to two 2.5" storage drives in drive carriers to simplify their removal from the chassis. These carriers also help promote proper airflow. Note: Enterprise level drives are recommended for use in Supermicro chassis and servers. For information on recommended drives, visit the Supermicro website at http://www.supermicro.
Page 45: Installing Drives
Chapter 3: Maintenance and Component Installation Installing Drives Removing Drive Carriers from the Chassis 1. Push the release button on the drive carrier. This releases and extends the drive carrier handle. 2. Swing the handle fully out. 3. Grasp the handle and use it to pull the drive carrier out of its bay. Caution: Except for short periods of time (swapping drives), do not operate the server with the drive carriers removed from the bays, regardless of how many drives are installed, for proper airflow.
Page 46 Chapter 3: Maintenance and Component Installation Installing a 2.5" Drive 1. Place the drive carrier on a flat surface. 2. The physical size of the drive does not permit using the stubs to hold the right side of the drive. Instead, install the drive directly into the tray and secure with four screws underneath.
Page 47: Expansion Cards
Chapter 3: Maintenance and Component Installation 3.8 Expansion Cards The system includes slots for PCI expansion cards. Riser cards position the expansion cards at a 90 degree angle, allowing them to fit inside the 2U chassis. The left bracket supports Slots 1 and 2 and is the default.
Page 48: Optional Configuration
Chapter 3: Maintenance and Component Installation Optional Configuration If populating Slot 3 or 4, use a 1U heatsink, CPU TDP less than 165 W, and air shrouds. See Figure 3-6. The left riser card is not included. The center riser card is included. Left Riser Card •...
Page 49: Installing Expansion Cards
Chapter 3: Maintenance and Component Installation Installing Expansion Cards Follow the steps below to install expansion cards into brackets. Installing a PCI Expansion Card 1. Power down the system and remove the cover. 2. For each bracket, remove the screw as shown below. 3.
Page 50 Chapter 3: Maintenance and Component Installation Figure 3-8. PCIe Slots and Cable Connectors Left Bracket Slots and Cable Connections Riser Card Configurations Left Bracket Slot MB Connector SlimSAS Cable Connector Configuration 1 PCIe Slot 1: PCIe 4.0 x16 JNVME0 CBL-SAST-1207LP-85 JPCIE1A1 PCIe Slot 2: N/A JNVME1...
Page 51 Chapter 3: Maintenance and Component Installation Figure 3-9. PCIe Slots and Cable Connectors Center Bracket Slots and Cable Connections Center Bracket Slot MB Slot or Connector SlimSAS Cable Riser Card Connector PCIe Slot 3: PCIe 4.0 x8 CPU SLOT7 PCIe 4.0 x8 Two CBL-SAST- PCIe Slot 4: PCIe 4.0 x16 JNVME 0/1...
Page 52 Chapter 3: Maintenance and Component Installation Figure 3-10. PCIe Slots Right Bracket and MB Slots Right Bracket Slot Motherboard Slots PCIe Slot 5: PCIe 4.0 x16 CPU SLOT6 PCIe 4.0 x16 PCIe Slot 6: PCIe 4.0 x16 CPU SLOT4 PCIe 4.0 x16...
Page 53: Installing M.2 Solid State Drives
Chapter 3: Maintenance and Component Installation Installing M.2 Solid State Drives The X12SPM-LN6TF supports PCIe 3.0 x4 NVMe/SATA M.2 SSDs. The M.2 slot supports the 2280 and 22110 form factors. Installing M.2 Drives 1. Remove power from the system and then remove the top cover as described in Sections 3.1 and 3.2.
Page 54: System Cooling
Chapter 3: Maintenance and Component Installation 3.9 System Cooling Fans Four internal fans provide cooling to the system. Changing a System Fan 1. Determine which fan is failing. If possible, use BMC. If not, remove the chassis cover while the power is on, and examine the fans to determine which one has failed. 2.
Page 55: Air Shroud
Chapter 3: Maintenance and Component Installation Air Shroud The air shroud distributes cooling air from the fan throughout the system. The "barebone" system does not include an air shroud. If populating the center riser slots, configure the system with a 1U heatsink, air shroud, and CPU TDP below 165 W.
Page 56: Power Supply
The power supplies are auto-switching capable. The 600 W DC power supplies can operate at a -44 Vdc to -65 Vdc input range. If replacing a power supply, the system does not need to be powered down. New units can be ordered directly from Supermicro or authorized distributors.
Page 57: Bmc Reset
Chapter 3: Maintenance and Component Installation 3.11 BMC Reset The BMC can be reset using the button on the front control panel or on the chassis rear. • Reset – Press and hold the button. After six seconds, the LED blinks at 2 Hz. The BMC resets and the reset duration is approximately 250 ms.
Page 58: Chapter 4 Motherboard Connections
Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
Page 59 Chapter 4: Motherboard Connections 8-Pin Power Connector JPV1 is an 8-pin 12V DC power input for the CPU that must be connected to the power supply. Refer to the table below for pin definitions. 8-pin Power Pin Definitions Pin# Definition 1 - 4 Ground 5 - 8...
Page 60: Control Panel
JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
Page 61 Chapter 4: Motherboard Connections Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Refer to the table below for pin definitions. Power Fail LED Pin Definitions (JF1) Pin# Definition 3.3 V PWR Supply Fail Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of the Front Control Panel to use the Overheat/Fan Fail LED connections.
Page 62: Nmi Button
Chapter 4: Motherboard Connections Power LED The Power LED connection is located on pins 15 and 16 of JF1. Refer to the table below for pin definitions. Power LED Pin Definitions (JF1) Pins Definition 3.3 V Stby PWR LED NMI Button The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1.
Page 63: Headers And Connectors
Chapter 4: Motherboard Connections 4.2 Headers and Connectors Fan Headers There are four 4-pin fan headers on the motherboard: two (FAN3~FAN4) on the front plane (see locations below), and two (FAN1~FAN2) on the drive backplane. All these 4-pin fan headers are backwards compatible with the traditional 3-pin fans. However, fan speed control is available for 4-pin fans only by Thermal Management via the BMC interface.
Page 64 The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from Supermicro (optional). A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.
Page 65 Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...
Page 66: Standby Power
Data PMBUS_Alert Ground +3.3 V NVMe I C Header Connector JNVI C1 is a management header for the Supermicro AOC NVMe PCIe peripheral cards. Please connect the I C cable to this connector. NVMe I2C Header Pin Definitions Pin# Definition...
Page 67 Chapter 4: Motherboard Connections External (I²C) Header The system management bus header is located at JIPMB1. Connect the approriate cable here to use the IPMB I2C connection on your system. Refer to the table below for pin definitions. SMBus Header Pin Definitions Pin# Definition...
Page 68 In addition, there are also two S-SATA ports (S-SATA0, S-SATA1) that include SATA DOM power. Refer to the table below for pin definitions. Note: For more information on the SATA HostRAID configuration, please refer to the Intel SATA HostRAID user's guide posted on our website at http://www.supermicro.com. SATA 3.0 Ports Pin Definitions Pin#...
Page 69: Input/Output Ports
Chapter 4: Motherboard Connections 4.3 Input/Output Ports See the figure below for the locations and descriptions of the I/O ports on the rear of the motherboard. Figure 4-2. I/O Port Locations and Definitions Rear I/O Ports Description Description VGA Port LAN1 (10G on -LN6TF) Dedicated IPMI LAN LAN4...
Page 70: Universal Serial Bus (Usb) Ports
Chapter 4: Motherboard Connections Universal Serial Bus (USB) Ports There are two USB 2.0 ports (USB0/1) and two USB 3.2 Gen 1 ports (USB6/7) located on the I/O back panel. The motherboard also has two front access USB 2.0 headers (USB2/3 and USB4/5) and one front access USB 3.2 Gen 1 header (USB8/9).
Page 71 Chapter 4: Motherboard Connections Unit Identifier Switch (UID-SW): One button with two functions A Unit Identifier (UID) switch and two LED Indicators are located on the motherboard. The UID switch, UID-SW, is located next to the VGA port on the back panel. Function User Input Behavior...
Page 72: Jumpers
Chapter 4: Motherboard Connections 4.4 Jumpers How Jumpers Work To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. Refer to the diagram below for an example of jumping pins 1 and 2.
Page 73 Chapter 4: Motherboard Connections 1 GbE LAN Enable/Disable JPL1 allows you to enable or disable the 1 GbE LAN for the X12SPM-LN6TF motherboard. The default setting is Enabled. 1 GbE LAN Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enable Pins 2-3 Disable 10 GbE LAN Enable/Disable...
Page 74: Led Indicators
Chapter 4: Motherboard Connections 4.5 LED Indicators LAN LEDs Six LAN ports (LAN1~6) are located on the back I/O panel of the motherboard. Each Ethernet LAN port has two LEDs. The yellow LED indicates activity, while the other Link LED may be green, amber, or off to indicate the speed of the connection.
Page 75 Chapter 4: Motherboard Connections Onboard Power LED The Onboard Power LED is located at LEDPWR on the motherboard. When this LED is on, the system is on. Be sure to turn off the system and unplug the power cord before removing or installing components.
Page 76: Chapter 5 Software
1. Create a method to access the MS Windows installation ISO file. That might be a USB flash or media drive or the BMC KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
Page 77 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.
Page 78: Driver Installation
The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash or media.
Page 79: Superdoctor ® 5
5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).
Page 80: Bmc
There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.
Page 81: Chapter 6 Troubleshooting And Support
Chapter 6 Troubleshooting and Support 6.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Products Figure 6-1. Supermicro Website • Specifications for servers and other hardware are available by clicking the Products option.
Page 82: Baseboard Management Controller (Bmc)
Direct Links (continued) Security Center for recent security notices Supermicro Phone and Addresses 6.2 Baseboard Management Controller (BMC) The system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring and management. There are several BIOS settings that are related to BMC.
Page 83: Troubleshooting Procedures
Chapter 6: Troubleshooting and Support 6.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. Power down the system before changing any non hot-swap hardware components.
Page 84: No Video
• Memory: Make sure that the memory modules are supported. Refer to the product page on our website at www.supermicro.com. Test the modules using memtest86 or a similar utility. • Storage drives: Make sure that all drives work properly. Replace if necessary.
Page 85 Also check the Control panel Overheat LED. • Adequate power supply: Make sure that the power supply provides adequate power to the system. Make sure that all power connectors are connected. Refer to the Supermicro website for the minimum power requirements. •...
Page 86: Crash Dump Using Bmc
In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using BMC. The BMC manual is available at https://www.supermicro.com/en/solutions/ management-software/bmc-resources. Check BMC Error Log 1.
Page 87: Uefi Bios Recovery
Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
Page 88 USB flash or media drive. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
Page 89 Chapter 6: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
Page 90 Chapter 6: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
Page 91 Chapter 6: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.
Page 92: Cmos Clear
Chapter 6: Troubleshooting and Support 6.6 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.
Page 93: Where To Get Replacement Components
6.7 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.
Page 94: Vendor Support Filing System
For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 6.9 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. Please email us at techwriterteam@supermicro.com to provide feedback on our manuals.
Page 95: Appendix A Standardized Warning Statements For Dc Systems
Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
Page 96 Appendix A: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
Page 97 Appendix A: Standardized Warning Statements ‫תקנון הצהרות אזהרה‬ ‫הצהרות הבאות הן אזהרות על פי תקני התעשייה, על מנת להזהיר את המשתמש מפני חבלה‬ ‫פיזית אפשרית. במידה ויש שאלות או היתקלות בבעיה כלשהי, יש ליצור קשר עם מחלקת תמיכה‬ .‫טכנית של סופרמיקרו. טכנאים מוסמכים בלבד רשאים להתקין או להגדיר את הרכיבים‬ .‫יש...
Page 98: Installation Instructions
Appendix A: Standardized Warning Statements Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書システムを電源に接続する前に、設置手順書をお読み下さい。警告将此系统连接电源前,请先阅读安装说明。警告將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.
Page 99: Circuit Breaker
Appendix A: Standardized Warning Statements Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 60VDC, 20A. サーキット・ブレーカーこの製品は、短絡（過電流）保護装置がある建物での設置を前提としています。保護装置の定格が60VDC、 20Aを超えないことを確認下さい。警告...
Page 100 Appendix A: Standardized Warning Statements ‫מוצר זה מסתמך על הגנה המותקנת במבנים למניעת קצר חשמלי. יש לוודא כי‬ 60VDC, 20A-‫המכשיר המגן מפני הקצר החשמלי הוא לא יותר מ‬ ‫هذا املنتج يعتمد عىل معداث الحاميت مه الدوائ ر القصرية التي تم تثبيتها يف‬ ‫املبنى‬...
Page 101: Power Disconnection Warning
Appendix A: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components (except for hot-swap components). 電源切断の警告...
Page 102 Appendix A: Standardized Warning Statements Attention Le système doit être débranché de toutes les sources de puissance ainsi que de son cordon d'alimentation secteur avant d'accéder à l'intérieur du chassis pour installer ou enlever des composants de systéme. ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬...
Page 103: Equipment Installation
Appendix A: Standardized Warning Statements Equipment Installation Warning! Only authorized personnel and qualified service persons should be allowed to install, replace, or service this equipment. 機器の設置トレーニングを受け認定された人だけがこの装置の設置、交換、またはサービスを許可されています。警告只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。警告只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.
Page 104: Restricted Area
Appendix A: Standardized Warning Statements Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. (This warning does not apply to workstations). アクセス制限区域...
Page 105 Appendix A: Standardized Warning Statements ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ (.‫'כלי אבטחה בלבד (מפתח, מנעול וכד‬ . ‫تخصيص هذه انىحذة نترك ب ُ ها ف مناطق محظورة تم‬ ‫،...
Page 106: Battery Handling
Appendix A: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
Page 107: Redundant Power Supplies
Appendix A: Standardized Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
Page 108 Appendix A: Standardized Warning Statements Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden. ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones.
Page 109: Backplane Voltage
Appendix A: Standardized Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧システムの稼働中は危険な電圧または電力が、バックプレーン上にかかっています。修理する際には注意ください。警告当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。警告當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
Page 110: Comply With Local And National Electrical Codes
Appendix A: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
Page 111: Product Disposal
Appendix A: Standardized Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
Page 112 Appendix A: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
Page 113 Appendix A: Standardized Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
Page 114: Dc Power Supply
Appendix A: Standardized Warning Statements DC Power Supply Warning! When stranded wiring is required, use approved wiring terminations, such as closedloop or spade-type with upturned lugs. These terminations should be the appropriate size for the wires and should clamp both the insulation and conductor. 警告...
Page 115: Dc Power Disconnection
Appendix A: Standardized Warning Statements ‫وأ ةقلغم ةقلح لثم ،اهيلع ةقفاوملا ءاهنإ كالسألا مادختساو ،لبسلا مهب تعطقت نيذلا كالسألا ابولطم نوكي امدنع‬ ‫بجيو كالسألل بسانملا مجحلا نوكي تاءاهنإلا هذهل يغبنيو .ةبولقم تاورعلا عم عونلا ةيقيقحلا اهئامسأب ءايشألا‬ ‫.لصومو لزعلا نم لك حبك‬ 주의! 꼬인...
Page 116 Appendix A: Standardized Warning Statements 警告進行以下任一操作程序前，請確保直流電路已斷電。警告请在进行以下任一操作程序前，确保直流电路的电源已经断开。 Warnung Vor Ausführung der folgenden Vorgänge ist sicherzustellen, daß die Gleichstromschaltung keinen Strom erhält. ¡Advertencia! Antes de proceder con los siguientes pasos, comprobar que la alimentación del circuito de corriente continua (CC) esté cortada (OFF). Attention Avant de pratiquer l'une quelconque des procédures ci-dessous, vérifier que le circuit en courant continu n'est plus sous tension.
Page 117: Hazardous Voltage Or Energy Present On Dc Power Terminals
Appendix A: Standardized Warning Statements Hazardous Voltage or Energy Present on DC Power Terminals Warning! Hazardous voltage or energy may be present on DC power terminals. Always replace cover when terminals are not in service. Be sure uninsulated conductors are not accessible when cover is in place.
Page 118 Appendix A: Standardized Warning Statements ‫امدنع امئاد ءاطغ لادبتسا .ةمصاعلا ةقاطلا تاطحم ىلع ةدوجوم نوكت ةقاطلا وأ ةرطخلا دهجلا دق‬ ‫ءاطغلا امدنع اهيلإ لوصولا نكمي ال لوزعم ريغ تالصوملا هيف كش ال امم .ةمدخلا يف تسيل تاطحملا‬ ‫.هناكم يف‬ 주의! DC전원...
Page 119: Appendix B System Specifications
Appendix B: System Specifications Appendix B System Specifications Processors Single 3rd Generation Intel® Xeon® Scalable processor (LGA4189) Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel® C621A BIOS 256Mb AMI BIOS SPI Flash BIOS ®...
Page 120 Appendix B: System Specifications Operating Environment Operating Temperature: 10º to 35º C (50º to 95º F) Non-operating Temperature: -40º to 60º C (-40º to 140º F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) Regulatory Compliance FCC, ICES, CE, VCCI, RCM, UKCA, NRTL, CB Applied Directives, Standards...
