Chapter 3: Maintenance and Component Installation
Installing Drives
Removing Drive Carriers from the Chassis
1. Remove the top chassis cover as described in Section 3.2.
2. Remove the drive's top screws and pull the drive bracket out of the chassis.
Figure 3-4. Installing a 2.5" Drive
3. Insert the SSD 1 in the bracket and tighten the four screws.
S
Figure 3-5. Installing SSD 1 in the Bracket
47
