SuperServer
®
SYS-221H-TNR
SYS-221H-TN24R
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SuperServer SYS-221H-TNR

Summary of Contents for Supermicro SuperServer SYS-221H-TNR

  • Page 1 SuperServer ® SYS-221H-TNR SYS-221H-TN24R USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Contacting Supermicro ......................9 Chapter 1 Introduction 1.1 Overview ..........................10 1.2 System Features ........................11 SYS-221H-TN24R Front View ..................11 SYS-221H-TNR Front View ....................12 Control Panel .........................13 Rear View ..........................14 1.3 System Architecture ......................16 Main Components ......................16 System Block Diagrams ....................18 SYS-221H-TNR ......................18...
  • Page 5 Preface 2.5 Installing the Chassis into a Rack ..................30 Removing the Chassis from the Rack ................31 Chapter 3 Maintenance and Component Installation 3.1 Removing Power .......................32 3.2 Accessing the System ......................33 Removing the Top Cover ....................33 3.3 Static-Sensitive Devices .....................34 Precautions ........................34 Unpacking .........................34 3.4 Processor and Heatsink Installation ...................35...
  • Page 6 Preface 3.8 System Cooling ........................59 Fans ..........................59 Air Shrouds ........................60 3.9 Expansion Cards ........................61 Expansion Card Slot Configurations .................61 Installing Expansion Cards ....................62 3.10 AIOM Network Cards ......................63 3.11 Cable Routing Diagrams ....................64 SYS-221H-TNR Storage Cables - NVMe .................64 SYS-221H-TN24R Storage Cables - NVMe ..............65 SYS-221H-TNR Storage Cables - SAS/SATA ..............66 SYS-221H-TN24R Storage Cables - SAS/SATA ..............67 PCIe Cables - Expansion Card Slots ................68...
  • Page 7 Preface Chapter 6 Optional Components 6.1 Storage Protocols Supported .....................91 6.2 Configuration Ordering Information ...................92 Hyper 2U SYS-221H-TNR Drive Bay Configuration Options ...........92 Hyper 2U SYS-221H-TNR PCIe Slot Configuration Options ..........94 Hyper 2U SYS-221H-TN24R Drive Bay Configuration Options ........97 Hyper 2U SYS-221H-TN24R PCIe Slot Configuration Options ........101 For Drive Bay Configuration Option 1 (24 NVMe) ............101 For Drive Bay Configuration Option 2 &...
  • Page 8 When the System Becomes Unstable ................124 7.4 CMOS Clear ........................126 7.5 Where to Get Replacement Components ................126 7.6 Technical Support Procedures ..................127 Returning Merchandise for Service .................128 7.7 Contacting Supermicro .....................129 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications...

  • Page 9: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 10: Chapter 1 Introduction

    2U Rackmount 1.7 x 17.2 x 29.3in. / 43 x 437 x 746mm (HxWxD) Note: A Quick Reference Guide can be found on the product page of the Supermicro website. Note: The following safety models associated with the SYS-221H-T Series have been...

  • Page 11: System Features

    Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. SYS-221H-TN24R Front View Control Panel Service Tag Figure 1-1. SYS-221H-TN24R Front View System Features: Front Feature Description Control Panel One control panel (see Control Panel...

  • Page 12: Sys-221H-Tnr Front View

    Chapter 1: Introduction SYS-221H-TNR Front View Control Panel Service Tag Figure 1-2. SYS-221H-TNR Front View System Features: Front Feature Description Control Panel One control panel (see Control Panel for details) Service Tag Service Tag with BMC Password Reset Logical Storage Drive Numbers Item Description 0 –...

  • Page 13: Control Panel

    Chapter 1: Introduction Control Panel Power Button UID Button Power LED HDD LED NIC2 LED NIC1 LED Power Fail LED Information LED Figure 1-3. Control Panel Control Panel Features Feature Description The main power button is used to apply or remove power from the power supply to the server. Power Button Turning off system power with this button removes the main power but maintains standby power.

  • Page 14: Rear View

    Chapter 1: Introduction Rear View BMC LAN Port VGA Port USB Ports PWS1 PWS2 Figure 1-4. System: Rear View System Features: Rear Feature Description Power Supplies Two redundant power supply modules, PWS1 on the left, PWS2 on the right Two USB 2.0 ports BMC LAN One RJ45 dedicated BMC LAN port One VGA port...
  • Page 15 Chapter 1: Introduction Power Supply Indicators Power Supply Condition Green LED Amber LED No AC Power to Power Supply Power Supply critical events causing a shutdown/ failure/ Amber LED OCP/ OVP/ Fan Fail/ OTP/ UVP Power Supply Warning Events Where the power supply continues to operate;...

  • Page 16: System Architecture

    Chapter 1: Introduction 1.3 System Architecture This section covers the locations of the system's main components, a system block diagram, and a motherboard layout with the connectors and jumpers called out. Main Components Internal M.2 Slot Internal M.2 Slot DIMMs Heatsink Fans 24 Drive Bays...
  • Page 17 Chapter 1: Introduction System Features: Top Feature Description SYS-221H-TNR: dual redundant modules, PWS-1K24A-1R Power Supply SYS-221H-TN24R: dual redundant modules, PWS-1K63A-1R DIMM slots 32 DIMM memory slots Supports dual 4th Gen Intel Xeon Scalable Processors (in Socket E LGA 4189) with four UPIs Processors (16GT/s max.) and a thermal design power (TDP) of up to 350W System Fans...

  • Page 18: System Block Diagrams

    Chapter 1: Introduction System Block Diagrams SYS-221H-TNR The block diagram below shows the connections and relationships between the subsystems and major components of the overall system. Optional Optional Rear PCIe Slots 5-8 Rear AIOM Slot A2 RSC-H2-6888G5L or AOM-AIOM-2X8-G5 RSC-H-68G5 Optional RSC-H-6G5L Rear PCIe Slots 3-4...

  • Page 19: Sys-221H-Tn24R

    Chapter 1: Introduction SYS-221H-TN24R The block diagram below shows the connections and relationships between the subsystems and major components of the overall system. Optional Optional Rear PCIe Slots 5-8 Rear AIOM Slot A2 RSC-H2-6888G5L or AOM-AIOM-2X8-G5 RSC-H-68G5 Optional RSC-H-6G5L Rear PCIe Slots 3-4 Rear AIOM Slot A1 Optional RSC-H-68G5...

  • Page 20: Motherboard Layout

    Chapter 1: Introduction 1.4 Motherboard Layout Below is a layout of the X13DEM motherboard with a jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4 or the Motherboard Manual.

  • Page 21: Quick Reference Table

    FAN1-FAN8, FAN9/ Eight 6-pin cooling fan headers (FAN1~FAN 8) and two 4-pin cooling fan headers FAN10 (FAN9-FAN10) Supermicro Advanced input/output Module (AIOM) PCIe 5.0 x16 connector for rear I/O JAIOM1 (P1_PE0 15-0) support JAIOM2SB1 Supermicro Advanced Input/Output Module (AIOM2) sideband connector JFP1 Front Control Panel header with I²C...
  • Page 22 Intel VROC key header for NVMe RAID support (See the note below.) (JRK1) Note: For detailed instructions on how to configure VROC RAID settings, please refer to the VROC RAID Configuration User's Guide posted on the webpage under the link: http://www. supermicro.com/support/manuals/.

  • Page 23: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those specific components.

  • Page 24: Rack Precautions

    Chapter 2: Server Installation • This product is not suitable for use with visual display workplace devices according to §2 of the German Ordinance for Work with Visual Display Units. Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them.

  • Page 25: Airflow

    Chapter 2: Server Installation Airflow Equipment should be mounted into a rack so that the amount of airflow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.

  • Page 26: Installing The Rails

    Chapter 2: Server Installation 2.4 Installing the Rails This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided.

  • Page 27: Releasing The Inner Rail

    Chapter 2: Server Installation Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the chassis from coming completely out of the rack when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. 1.

  • Page 28: Installing The Inner Rails

    Chapter 2: Server Installation Installing the Inner Rails Begin the rack mounting procedure by installing the inner rails to the chassis. 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 29: Installing The Outer Rails Onto The Rack

    Chapter 2: Server Installation Installing the Outer Rails onto the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3.

  • Page 30: Installing The Chassis Into A Rack

    Chapter 2: Server Installation 2.5 Installing the Chassis into a Rack Once rails are attached to the chassis and the rack, you can install the server. Warning: Mounting the system into the rack requires at least two people to support the chassis during installation.

  • Page 31: Removing The Chassis From The Rack

    Chapter 2: Server Installation Removing the Chassis from the Rack Caution! It is dangerous for a single person to off-load the heavy chassis from the rack without assistance. Be sure to have sufficient assistance supporting the chassis when removing it from the rack.

  • Page 32: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.

  • Page 33: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The CSE-HS219-R1K24P and CSE-HS219-R1K63P chassis feature a removable top cover, which allows easy access to the inside of the chassis. Removing the Top Cover 1. Press the release button and slide the cover toward the rear. 2.

  • Page 34: Static-Sensitive Devices

    Chapter 3: Maintenance and Component Installation 3.3 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your motherboard, it is important to handle it very carefully. The following measures are generally sufficient to protect the system PCBs from ESD. Precautions •...

  • Page 35: Processor And Heatsink Installation

    Thermal grease is pre-applied on a new heatsink. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor and memory support. • All graphics in this manual are for illustrations only. Your components may look different.

  • Page 36: The 4Th Gen Intel Xeon Scalable Processor

    Chapter 3: Maintenance and Component Installation The 4th Gen Intel Xeon Scalable Processor SP XCC Series SP MCC Series Max Series (HBM) Overview of the CPU Socket The CPU socket is protected by a plastic protective cover. Plastic Protective Cover CPU Socket...

  • Page 37: Overview Of The Processor Carrier Assembly

    Chapter 3: Maintenance and Component Installation Overview of the Processor Carrier Assembly The processor carrier assembly contains a 4th Gen Intel Xeon Scalable processor and a processor carrier. Carefully follow the instructions given in the installation section to place a processor into the carrier to create a processor carrier.

  • Page 38: Overview Of The Processor Heatsink Module (Phm)

    Chapter 3: Maintenance and Component Installation Overview of the Processor Heatsink Module (PHM) The Processor Heatsink Module (PHM) contains a heatsink, a processor carrier, and a 4th Gen Intel Xeon Scalable Processor. 1. 2U Heatsink (Bottom View) 2. Processor Carrier E1A 3.
  • Page 39 Chapter 3: Maintenance and Component Installation 1. 2U Heatsink (Bottom ViewShown Below for SP MCC Illustration) 2. CPU Carrier E1B 3. The 4th Gen Intel Xeon Scalable Processor (SP MCC Series Component Side) 4. Processor Heatsink Module (PHM) (Bottom View Shown Below)
  • Page 40 Chapter 3: Maintenance and Component Installation 1. 2U Heatsink (Bottom View Shown Below for Max Series (HBM Illustration)) 2. Processor Carrier E1C 3. The 4th Gen Intel Xeon Scalable Processor (Max Series (HBM) Component Side) 4. Processor Heatsink Module (PHM) (Bottom View Shown Below)

  • Page 41: Creating The Processor Carrier Assembly

    Chapter 3: Maintenance and Component Installation Creating the Processor Carrier Assembly The processor carrier assembly contains a 4th Gen Intel Xeon Scalable processor and a processor carrier.To create the processor carrier assembly, please follow the steps below: 1. Hold the processor with the component side (including the gold contacts) facing down. Locate the small, gold triangle at the corner of the processor and the corresponding hollowed triangle on the processor carrier as shown in the graphics below.
  • Page 42 Chapter 3: Maintenance and Component Installation 3. Locate the lever on the CPU socket and press it down as shown below. Lever Lever Make sure the lever is pressed down before installing the processor. Carrier E1A Carrier E1B 4. Using pin 1 as a guide, carefully align the CPU keys (A and B) on the processor against the CPU keys on the carrier (a and b) as shown in the drawing below.
  • Page 43 Chapter 3: Maintenance and Component Installation 6. After the processor is placed inside the carrier, examine the four sides of the processor, making sure that the processor is properly seated on the carrier. (Top View) (Component View) SP XCC Series (Top View) (Component View) SP MCC Series...

  • Page 44: Creating The Processor Heatsink Module (Phm)

    Chapter 3: Maintenance and Component Installation Creating the Processor Heatsink Module (PHM) After creating the processor carrier assembly, please follow the instructions below to mount the processor carrier into the heatsink to form the PHM. Note: If this is a new heatsink, the thermal grease has been pre-applied on the underside. Otherwise, apply the proper amount of thermal grease.

  • Page 45: Preparing The Cpu Socket For Installation

    Chapter 3: Maintenance and Component Installation Preparing the CPU Socket for Installation This motherboard comes with a plastic protective cover installed on the CPU socket. Remove it from the socket by following the instructions below: 1. Press the tabs inward. CPU Socket with Plastic Protective Cover 2.

  • Page 46: Installing The Phm Into The Cpu Socket

    Chapter 3: Maintenance and Component Installation Installing the PHM into the CPU Socket After assembling the Processor Heatsink Module, you are ready to install it into the CPU socket. To ensure proper installation, please follow the procedures below: 1. Locate four threaded fasteners (a, b, c, d) on the CPU socket. CPU Socket (a, b, c, d: Threaded Fasteners) CPU Socket Pin1...
  • Page 47 Chapter 3: Maintenance and Component Installation 3. Check the rotating wires (1, 2, 3, 4) to make sure that they are at unlatched positions as shown in the drawing below before installing the PHM into the CPU socket. Unlatched State Top View Side View Rotating Wire 1...

  • Page 48: Removing The Phm From The Cpu Socket

    Chapter 3: Maintenance and Component Installation Removing the PHM from the CPU Socket Before removing the processor heatsink module (PHM) from the motherboard, shut down the system and then unplug the AC power cord from all power supplies. Then follow the steps below: 1.

  • Page 49: Removing The Processor Carrier Assembly From The Phm

    Chapter 3: Maintenance and Component Installation Removing the Processor Carrier Assembly from the PHM To remove the processor carrier assembly from the PHM, please follow the steps below: 1. Detach the four plastic clips (marked a, b, c, d) on the processor carrier assembly from the four corners of the heatsink (marked A, B, C, D) as shown in the drawings below.

  • Page 50: Removing The Processor From The Processor Carrier Assembly

    Chapter 3: Maintenance and Component Installation Removing the Processor from the Processor Carrier Assembly Once you have removed the processor carrier assembly from the PHM, you are ready to remove the processor from the processor carrier by following the steps below. 1.

  • Page 51: Heatsinks (Optional)

    Chapter 3: Maintenance and Component Installation Heatsinks (Optional) The optional Extended Volume Air Cooling (EVAC) SNK-P2089P 2U heatsink designed for X13DEM supports dual 4th Gen Intel Xeon Scalable Processors (in Socket E LGA4189). Installing X13DEM EVAC Heatsinks Begin by creating the PHM installing the PHM into the CPU socket.

  • Page 52: Memory Support And Installation

    Chapter 3: Maintenance and Component Installation 3.5 Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing memory modules to prevent any possible damage. Memory Support The X13DEM motherboard supports up to 8TB of 3DS RDIMM/RDIMM DDR5 (288-pin) memory with speeds up to 4800MT/s.
  • Page 53 2 CPUs & 24 DIMMs DIMME1/P1-DIMME2/P1-DIMMF1/P1-DIMMF2/P1-DIMMG1/P1-DIMMG2/P1-DIMMH1/P1-DIMMH2 CPU2: P2-DIMMA1/P2-DIMMB1/P2-DIMMC1/P2-DIMMD1/P2-DIMME1/P2-DIMMF1/P2-DIMMG1/P2-DIMMH1 CPU1: P1-DIMMA1/P1-DIMMA2/P1-DIMMB1/P1-DIMMB2/P1-DIMMC1/P1-DIMMC2/P1-DIMMD1/P1-DIMMD2/P1- DIMME1/P1-DIMME2/P1-DIMMF1/P1-DIMMF2/P1-DIMMG1/P1-DIMMG2/P1-DIMMH1/P1-DIMMH2 2 CPUs & 32 DIMMs CPU2: P2-DIMMA1/P2-DIMMA2/P2-DIMMB1/P2-DIMMB2/P2-DIMMC1/P2-DIMMC2/P2-DIMMD1/P2-DIMMD2/P2- DIMME1/P2-DIMME2/P2-DIMMF1/P2-DIMMF2/P2-DIMMG1/P2-DIMMG2/P2-DIMMH1/P2-DIMMH2 Note: This memory configuration is recommended by Supermicro for optimal memory performance. Please use this configuration to maximize your memory performance.
  • Page 54 Chapter 3: Maintenance and Component Installation DDR5 Memory Population Table (with Max Series ((HBM)) CPUs and 32 DIMMs Installed) 1 CPU: Memory Population Sequence P1-DIMMA1 1 CPU & 1 DIMM P1-DIMME1 P1-DIMMA1/P1-DIMMG1 1 CPU & 2 DIMMs P1-DIMMC1/P1-DIMME1 1 CPU & 4 DIMMs P1-DIMMA1/P1-DIMMC1/P1-DIMME1/P1-DIMMG1 1 CPU &...

  • Page 55: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation JVRM1 P1-AIOM PCIe 5.0 X16 JUSB3 JPWR1 M.2-H2 JPWR4 M.2-H1 JIO1 JPCIE2B1 1. Insert the desired number of DIMMs into the memory MH10 PSU2 PSU1 JBT1 JAIOM2SB1 JPMW2 JPMW5 JPCIE5B1 JPCIE5A1 CLEAR MH11 JNCSI1 MH17...

  • Page 56: Motherboard Battery

    Chapter 3: Maintenance and Component Installation 3.6 Motherboard Battery Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock outwards to unlock it.

  • Page 57: Storage Drives

    Chapter 3: Maintenance and Component Installation 3.7 Storage Drives The storage drives are mounted in tool-less drive carriers that simplify their removal from the chassis. These carriers also help promote proper airflow. For compatible storage drives, see the SYS-221H-TNR and SYS-221H-TN24R product page. Figure 3-2.

  • Page 58: Hot-Swap For Nvme Drives

    Chapter 3: Maintenance and Component Installation Hot-Swap for NVMe Drives Supermicro servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using BMC. Note: If you are using VROC, see the VROC appendix in this manual instead.

  • Page 59: System Cooling

    Chapter 3: Maintenance and Component Installation 3.8 System Cooling Fans Four 8-cm heavy-duty fans provide cooling for the system. Fans are hot-swapped and can be replaced without powering down the system. The electrical connections are automatically made when a fan is inserted into its slot. Make sure the chassis cover is only off for a short time and makes a good seal when replaced for the cooling air to circulate properly through the system.

  • Page 60: Air Shrouds

    Chapter 3: Maintenance and Component Installation Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The SYS-221H-T Series includes one air shroud for each CPU. Air Shroud for Memory (CPU1/2) Two air shrouds cool the DIMM slots controlled by CPUs 1 and 2 (see figure below). 1.

  • Page 61: Expansion Cards

    Chapter 3: Maintenance and Component Installation 3.9 Expansion Cards The SYS-221H-T Series series can support up to eight expansion cards. BMC LAN Port VGA Port USB Ports Power Supply 1 Power Supply 2 Figure 3-7. Expansion Card Slots Expansion Card Slot Configurations Enabling any of the eight expansion card slots in this system requires optional parts that are sold separately.

  • Page 62: Installing Expansion Cards

    Chapter 3: Maintenance and Component Installation Before following the procedure below to install expansion cards, first turn off and remove power from the system as described in section 3.1 then remove the top cover. Installing Expansion Cards 1. Remove any slimline SAS cables connected to the riser card and pull up the riser card brackets.

  • Page 63: Aiom Network Cards

    Up to 15W* (Optional) *AIOM cards exceeding the 15W Slot Power Envelope may require restricted conditions to meet thermal specifications of the AIOM card. Contact your Supermicro account representative for more information. Installing AIOM Cards 1. Remove power as described in Section 3.1.

  • Page 64: Cable Routing Diagrams

    Chapter 3: Maintenance and Component Installation 3.11 Cable Routing Diagrams The below diagrams indicate the cable routing for the storage, PCIe, IO, and power cables. When disconnecting cables to add or replace components, refer to the diagrams so you can reroute them in the same manner.

  • Page 65: Sys-221H-Tn24R Storage Cables - Nvme

    Chapter 3: Maintenance and Component Installation SYS-221H-TN24R Storage Cables - NVMe 16 NVMe 24 NVMe 8 NVMe CPU1 CPU2 SYS-221H-TN24R Storage Cables - NVMe Cable Cable Part Number Connection From Connection To CBL-MCIO-1242AM5L Motherboard, JPCIE2A1 Front Backplane, NVMe0 NVMe1 CBL-MCIO-1249AM5LF Motherboard, JPCIE2B1 Front Backplane, NVMe2 NVMe3 CBL-MCIO-1221M5...

  • Page 66: Sys-221H-Tnr Storage Cables - Sas/Sata

    Chapter 3: Maintenance and Component Installation SYS-221H-TNR Storage Cables - SAS/SATA 16 SAS/SATA (AOC) 8 NVMe 8 SAS/SATA (AOC) 8 SAS/SATA (AOC) 8 SAS/SATA (AOC) 8 SATA (PCH) SYS-221H-TNR Storage Cables - SAS/SATA Cable Cable Part Number Connection From Connection To CBL-SAST-1276F-100 Storage AOC, CN0 Front Backplane (optional), CN1 &...

  • Page 67: Sys-221H-Tn24R Storage Cables - Sas/Sata

    Chapter 3: Maintenance and Component Installation SYS-221H-TN24R Storage Cables - SAS/SATA 16 + 8 SAS/SATA (AOC) 8 NVMe 16 SAS/SATA (AOC) 8 SAS/SATA (AOC) 8 SATA (PCH) SYS-221H-TN24R Storage Cables - SAS/SATA Cable Cable Part Number Connection From Connection To CBL-SAST-1264F-100 Storage AOC, CN0 Backplane, SAS 0-3 &...

  • Page 68: Pcie Cables - Expansion Card Slots

    Chapter 3: Maintenance and Component Installation PCIe Cables - Expansion Card Slots Slot 1,2: PCIe x8,x8 Slot 3,4: PCIe x8,x8 Slot 5,6: PCIe x8,x8 CPU1 CPU2 PCIe Cables - Expansion Card Slots Cable Cable Part Number Connection From Connection To CBL-MCIO-1233M5R Motherboard, JPCIE5A1 Riser Card, JPCIE1A1...

  • Page 69: Pcie Cables - Expansion Card Slots

    Chapter 3: Maintenance and Component Installation PCIe Cables - Expansion Card Slots Slot 1,2: PCIe x16,x0 Slot 3,4: PCIe x16,x0 Slot 5,6: PCIe x16,x0 CPU1 CPU2 PCIe Cables - Expansion Card Slots Cable Cable Part Number Connection From Connection To CBL-MCIO-1233M5R Motherboard, JPCIE5A1 Riser Card, JPCIE1A1...

  • Page 70: Pcie Cables - Aiom/Ocp 3.0 Nic Slots

    Chapter 3: Maintenance and Component Installation PCIe Cables - AIOM/OCP 3.0 NIC Slots CPU1 CPU2 PCIe Cables - AIOM/OCP 3.0 NIC Slots Cable Cable Part Number Connection From Connection To CBL-GNZ5-1307 Motherboard, JAIOM1 AIOM/OCP 3.0 NIC CBL-MCIO-1221M5 Motherboard, JPCIE3A1 AIOM Board, JPCIE1A1 CBL-MCIO-1218M5-1 Motherboard, JPCIE3B1 AIOM Board, JPCIE1B1...

  • Page 71: I/O Board Cable

    Chapter 3: Maintenance and Component Installation I/O Board Cable Cable Cable Part Number Connection From Connection To I/O Board Cable CBL-SAST-1225LP Motherboard, JIO1 I/O Board, JIO1 Cable Cable Part Number Connection From Connection To CBL-SAST-1225LP Motherboard, JIO1 I/O Board, JIO1...

  • Page 72: Power Cables

    Chapter 3: Maintenance and Component Installation Power Cables Storage Backplane (24 drive) Storage Backplane (8 drive) Storage Backplane (16 drive) Power Cables Cable Cable Part Number Connection From Connection To CBL-PWEX-1142-60 Motherboard, JPMW1 Backplane, JPWR1 CBL-PWEX-1142B-70 Motherboard, JPMW5 Backplane, JPWR1 CBL-PWEX-1142-40 Motherboard, JPMW5 Backplane, JPWR2...

  • Page 73: Power Supply

    Failed power supply modules can be replaced without powering down the system. Replacement modules can be ordered directly from Supermicro. An amber light on the power supply is illuminated when the power is switched off. A green light indicates that the power supply is operating.

  • Page 74: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 75: Headers And Connectors

    The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from Supermicro (optional). A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.
  • Page 76 BMC (Baseboard Controller) to communicate with a network. Note: For detailed instructions on how to confi gure Network Interface Card (NIC) settings, please refer to the Network Interface Card Confi guration User's Guide posted on the web page under the link: http://www.supermicro.com/support/manuals/.
  • Page 77 C) header (JNVI2C1), used for PCIe SMBus clock and data connections, provides hot-plug support via a dedicated SMBus interface. This feature is only available for a Supermicro complete system with an Supermicro proprietary NVMe add-on card and a proper cable installed. See the table below for pin definitions.
  • Page 78 Chapter 4: Motherboard Connections PCIe 3.0 M.2-H1/M.2-H2 Slots Two PCIe 3.0/SATA3 Hybrid M.2 slots are located at M.2-H1 and M.2-H2 on the motherboard. These M.2/SATA3 Hybrid slots support M.2 NVMe/SATA3 SSDs in the 2280 and 22110 form factors. To accommodate the 2280 and 22110 form factors, two M.2 mounting holes (MH17/MH18) are provided on the motherboard.

  • Page 79: Control Panel

    1, located at JFP1, contains header pins for various buttons and LED indicators with I²C support for front access. These front control panel headers are designed specifically for use with Supermicro chassis. See the figure below for the pin-out descriptions for JFP1. JFP1...
  • Page 80 Chapter 4: Motherboard Connections Power On and BMC/BIOS Status LED Button The Power On and BMC/BIOS Status LED button is located on pin 1 of the front control panel header located at JFP1. Momentarily contacting pin 1 of JFP1 will power on/off the system or display BMC/BIOS status.
  • Page 81 Chapter 4: Motherboard Connections Fail LED (Information LED for OH/FF/PF) The Fail LED (Information LED for OH/Fan Fail/PWR Fail) connection is located on pin 4 of JFP1. The LED provides warnings of overheating, power failure, or fan failure. Refer to the motherboard layout in Chapter 1 for more information.
  • Page 82 Chapter 4: Motherboard Connections RoT (Root of Trust) Power LED The Power LED for RoT (Root of Trust) connection is located on pin 9 of JFP1. If this LED is on, power for the RoT chip is on. Standby Power A Standby Power (I C) connection is located on pin 10 ~ pin 14 of JFP1 to provide power to the system when it is in standby mode.

  • Page 83: Input/Output Ports

    1 for the location of JIO1. Also refer to the LED Indicator section for LAN LED information. Advanced I/O Module (AIOM) for Rear I/O Support (JAIOM1) A Supermicro proprietary Advanced I/O Module (AIOM) connector used for a PCIe 5.0 x16 add-on module is located at JAIOM1. This AIOM connector (P1_PE0 15-0), supported by CPU1, provides input/output connections on the rear side of your system.
  • Page 84 Chapter 4: Motherboard Connections Universal Serial Bus (USB) 3.2 Header A USB header that supports two USB 3.2 Gen1 ports (USB2/3) is located at JUSB3 on the rear side of the motherboard. These USB ports can be used for USB support via USB cables (not included).
  • Page 85 Chapter 4: Motherboard Connections CMOS Clear JBT1 is used to clear CMOS, which will also clear passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1. First power down the system and unplug the power cord(s). 2.

  • Page 86: Led Indicators

    Chapter 4: Motherboard Connections 4.4 LED Indicators BMC LAN LEDs A dedicated BMC LAN connection is provided on the low-profile Slim SAS I/O connector (JIO1) located on the rear side of the motherboard. The LED on the right indicates activity, and the LED on the left indicates the speed of the connection.

  • Page 87: Chapter 5 Software

    Media drive, perheps using an external USB/SATA media drive, a USB flash drive, or the BMC KVM console. 2. Retrieve the proper drivers. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 88 Chapter 5: Software 4. During Windows Setup, continue to the dialog box where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 89: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash or a media drive.

  • Page 90: Bmc

    When logging in to the BMC for the first time, please use the unique password provided by Supermicro to log in. You can change the unique password to a user name and password of your choice for subsequent logins.

  • Page 91: Chapter 6 Optional Components

    Chapter 6: Optional Components Chapter 6 Optional Components This chapter describes alternate configurations and optional system components. Optional Parts Storage Protocals PCIe Options Power Options Cable Management Arm TPM security module Intel VROC RAID Key 6.1 Storage Protocols Supported The storage drive bays can be configured to support either SATA, SAS, or NVMe drives by adding optional parts to the system.

  • Page 92: Configuration Ordering Information

    Chapter 6: Optional Components 6.2 Configuration Ordering Information Hyper 2U SYS-221H-TNR Drive Bay Configuration Options Default Option 1: 8 NVMe Drive Bay # Drive Type Part Numbers CBL-MCIO-1250M5L-M CBL-MCIO-1219M5L Drive Bays 0-7 NVMe (from CPU2) CBL-MCIO-1234AM5LFRE CBL-MCIO-1234M5L Option 2: 8 SAS/SATA Drive Bay # Drive Type Part Numbers CBL-SAST-1276F-100 CBL-CDAT-1062 For Non RAID:...
  • Page 93 Chapter 6: Optional Components Option 5: 16 SAS/SATA Drive Bay # Drive Type Part Numbers MCP-220-00196-0B (x8) BPN-NVME5-HS219N-S8 CBL-SAST-1276F-100 (x2) CBL-PWEX-1142B-70 CBL-CDAT-1062Y-45 Drive Bays 0-15 SAS/SATA For Non-RAID: AOC-S3816L-L16IT-O¹ For Hardware RAID: AOC-S3916L-H16IR-32DD-O¹ Option 6: 8 NVMe + 8 SAS/SATA Drive Bay # Drive Type Part Numbers...

  • Page 94: Hyper 2U Sys-221H-Tnr Pcie Slot Configuration Options

    Chapter 6: Optional Components Hyper 2U SYS-221H-TNR PCIe Slot Configuration Options Slots 1-2 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 1 Not Available MCP-120-21101-0N (Included with system) Slot 2 Not Available Option 1: 2 PCIe x8 Slots Slot # Slot Config Part Numbers MCP-240-21108-0N Slot 1 PCIe 5.0 x8 (CPU2) RSC-H-68G5 CBL-MCIO-1233M5R Slot 2...
  • Page 95 Chapter 6: Optional Components Slots 3-4 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 3 Not Available MCP-120-21101-0N (Included with system) Slot 4 Not Available Option 1: 2 PCIe x8 Slots Slot # Slot Config Part Numbers Slot 3 PCIe 5.0 x8 (CPU2) MCP-240-21108-0N MCP-120-82927-0N RSC-H-68G5 Slot 4 PCIe 5.0 x8 (CPU2)
  • Page 96 Chapter 6: Optional Components Slots 5-8 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 5 Not Available Slot 6 Not Available MCP-120-21902-0N (Included with system) Slot 7 Not Available Slot 8 Not Available Option 1: 4 PCIe x8 Slots Slot # Slot Config Part Numbers Slot 5 PCIe 5.0 x8 (CPU1) MCP-240-21908-0N...

  • Page 97: Hyper 2U Sys-221H-Tn24R Drive Bay Configuration Options

    Chapter 6: Optional Components Hyper 2U SYS-221H-TN24R Drive Bay Configuration Options Option 1: 24 NVMe Drive Bay # Drive Type Part Numbers CBL-MCIO-1242AM5L Drive Bays 0-9 NVMe (from CPU1) CBL-MCIO-1249AM5LF CBL-MCIO-1221M5 (x2) CBL-MCIO-1222M5LF CBL-MCIO-1245M5 (x3) Drive Bays 10-23 NVMe (from CPU2) CBL-MCIO-1237M5 CBL-MCIO-1227M5 CBL-MCIO-1218AM5REF CBL-MCIO-1217M5 Option 2: 16 NVMe + 8 SAS/SATA Drive Bay # Drive Type Part Numbers...
  • Page 98 Chapter 6: Optional Components Option 3: 16 NVMe + 8 SATA Drive Bay # Drive Type Part Numbers CBL-MCIO-1221M5 Drive Bays 0-7 SATA CBL-MCIO-1245M5 (x3) CBL-MCIO-1237M5 Drive Bays 8-9 NVME (from CPU1) CBL-MCIO-1227M5 CBL-MCIO-1218AM5REF CBL-MCIO-1217M5 CBL-SAST-1258LP-100 Drive Bays 10-23 NVMe (from CPU2) CBL-CDAT-1062 (x2) LBL-0968 (x4) Option 4: 16 SAS/SATA + 8 SAS/SATA...
  • Page 99 Chapter 6: Optional Components Rear D Rear D Option 6: 16 SAS/SATA + 8 SAS/SATA + 2 NVMe Drive Bay # Drive Type Part Numbers MCP-240-21104-0N Drive Bays 0-15 SAS/SATA (controller 1) BPN-NVME5-826N-B2B CBL-MCIO-1217M5 CBL-SAST-1264F-100 Drive Bays 16-23 SAS/SATA (controller 2) CBL-SAST-1276F-100 CBL-SAST-1296F-100 CBL-CDAT-1062...
  • Page 100 Chapter 6: Optional Components Rear Drive Bay 1 Rear Drive Bay 3 Rear Drive Bay 0 Rear Drive Bay 2 Option 7: 16 SAS/SATA + 8 SAS/SATA + 2 NVMe Drive Bay # Drive Type Part Numbers MCP-240-21104-0N (x2) Drive Bays 0-15 SAS/SATA (controller 1) MCP-120-82927-0N BPN-NVME5-826N-B2B (x2)

  • Page 101: Hyper 2U Sys-221H-Tn24R Pcie Slot Configuration Options

    Chapter 6: Optional Components Hyper 2U SYS-221H-TN24R PCIe Slot Configuration Options For Drive Bay Configuration Option 1 (24 NVMe) Slots 1-2 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 1 Not Available MCP-120-21101-0N (Included with system) Slot 2 Not Available...
  • Page 102 Chapter 6: Optional Components Slots 3-4 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 3 Not Available MCP-120-21101-0N (Included with system) Slot 4 Not Available Option 1: 2 PCIe x8 Slots Slot # Slot Config Part Numbers MCP-240-21108-0N Slot 3 PCIe 5.0 x8 (CPU2) MCP-120-82927-0N RSC-H-68G5 CBL-GNZ4-1227M5YR21 Slot 4...
  • Page 103 Chapter 6: Optional Components Slots 5-8 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 5 Not Available Slot 6 Not Available MCP-120-21902-0N (Included with system) Slot 7 Not Available Slot 8 Not Available Option 1: 1 PCIe x16 Slot Slot # Slot Config Part Numbers Slot 5 Not Available Slot 6...

  • Page 104: For Drive Bay Configuration Option 2 & 3 (16 Nvme +8 Sas Or Sata)

    Chapter 6: Optional Components For Drive Bay Configuration Option 2 & 3 (16 NVMe +8 SAS or SATA) Slots 1-2 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 1 Not Available MCP-120-21101-0N (Included with system) Slot 2 Not Available Slots 3-4 Configuration Options Default: No PCIe Slots Slot #...
  • Page 105 Chapter 6: Optional Components Slots 5-8 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 5 Not Available Slot 6 Not Available MCP-120-21902-0N (Included with system) Slot 7 Not Available Slot 8 Not Available Option 1: 4 PCIe x8 Slots Slot # Slot Config Part Numbers Slot 5 PCIe 5.0 x8 (CPU1) MCP-240-21908-0N...

  • Page 106: For Drive Bay Configuration Options Excluding 24 Nvme & 16 Nvme

    Chapter 6: Optional Components For Drive Bay Configuration Options excluding 24 NVMe & 16 NVMe Slots 1-2 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 1 Not Available MCP-120-21101-0N (Included with system) Slot 2 Not Available 2 PCIe x8 Slots Slot # Slot Config Part Numbers MCP-240-21108-0N...
  • Page 107 Chapter 6: Optional Components Slots 5-8 Configuration Options Default: No PCIe Slots Slot # Slot Config Part Numbers Slot 5 Not Available Slot 6 Not Available MCP-120-21902-0N (Included with system) Slot 7 Not Available Slot 8 Not Available Option 1: 4 PCIe x8 Slots Slot # Slot Config Part Numbers Slot 5 PCIe 5.0 x8 (CPU1) MCP-240-21908-0N...

  • Page 108: Power Supply Configurations

    Chapter 6: Optional Components 6.3 Power Supply Configurations Power Supply Module Options Watts Part Number 80Plus Level 1200 PWS-1K24A-1R (default in SYS-221H-TNR) Titanium 1600 PWS-1K63A-1R (default in SYS-221H-TN24R) Titanium 2000 PWS-2K07A-1R Titanium 2600 PWS-2K63A-1R Titanium 6.4 Cable Management Arm The system supports a cable management arm (CMA), which keeps the rear cables organized and clear of the rail mechanisms when the system is extended out the front of the rack for maintenance.
  • Page 109 Chapter 6: Optional Components Figure 6-2. Installing the Connectors 3. Slide CMA connector #3 forward onto the two posts on the rear of the left middle rail. It snaps into place. 4. For CMA connector #4, align the metal tabs with the slots on the rear of the left outer rail and push it forward.

  • Page 110: Tpm Security Module

    It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Details and installation procedures are at: http://www.supermicro.com/manuals/other/TPM.pdf. • AOM-TPM-9670V •...

  • Page 111: Intel Virtual Raid On Cpu (Vroc)

    Chapter 6: Optional Components 6.6 Intel Virtual RAID on CPU (VROC) Intel Virtual RAID on CPU (Intel VROC) is an enterprise RAID solution for NVMe SSDs ® directly attached to Intel Xeon Scalable processors. Intel Volume Management Device (VMD) is an integrated controller inside the CPU PCIe root complex. •...

  • Page 112: Additional Information

    Chapter 6: Optional Components Additional Information Additional information is available on the product page for the Supermicro add-on card and the linked manuals. www.supermicro.com/products/accessories/addon/AOC-VROCxxxMOD.cfm Hardware Key The Intel VROC hardware key is a license key that detects the Intel VROC SKU and activates the function accordingly.

  • Page 113: Configuring Intel Vmd

    Chapter 6: Optional Components Configuring Intel VMD VMD must be enabled on PCIe ports which have NVMe drives attached to them in order for those drives to be added to a VROC RAID configuration. The default BIOS setting for the NVMe Mode Switch is Auto which automatically enables VMD on all installed NVMe drives. NVMe Mode Switch : •...
  • Page 114 Chapter 6: Optional Components This table identifies the NVMe Port Resources in the X13 Hyper servers. Enable VMD on the NVMe drive’s corresponding hardware stack according to the VMD BIOS Settings table. Intel VMD BIOS Settings for X13 Hyper Systems Model CPU1 NVMe Slots CPU2 NVMe Slots VMD Config for IOU 0: VMD Config for PCH ports: Socket 1 IOU0 port A...
  • Page 115 Chapter 6: Optional Components Intel VMD BIOS Settings for X13 Hyper Systems Model CPU1 NVMe Slots CPU2 NVMe Slots VMD Config for PCH ports: PCH Root Port 8 M.2 A,B PCH Root Port 9 VMD Config for IOU 3: SYS-621H-TN12R Socket 0 IOU3 port E NVMe 0,1. 4 NVMe Socket 0 IOU3 port G VMD Config for IOU 4:...
  • Page 116 Chapter 6: Optional Components Caution: VMD must only be enabled on NVMe port resources. If VMD is enabled on other PCIe ports, the functionality of those ports will be impacted. See the table below. 1. Select “Intel VMD for Volume Management Device on” on Socket 0 (CPU1) or Socket 2 (CPU2) to enable VMD for devices under the respective CPU.
  • Page 117 Chapter 6: Optional Components Figure 6-7. BIOS, Enabling VMD on Socket 1 (Example) 1. Enable the NVMe port resource according to table above for the NVMe drives that will be used in a RAID configuration. Figure 6-8. BIOS, Enabling Socket 1 (Example)
  • Page 118 Chapter 6: Optional Components 1. Choose whether to make the NVMe drives in this IOU Hot Plug Capable by selecting Enabled or Disabled. 2. Repeat steps 4 through 7 for each IOU # on each CPU to enable VMD on the desired NVMe ports.

  • Page 119: Creating Nvme Raid Configurations

    Chapter 6: Optional Components Creating NVMe RAID Configurations 1. Open Advanced > Intel(R) Virtual RAID on CPU > All Intel VMD Controllers > Create RAID Volume. Figure 6-10. Created Volume without Figure 6-11. Created Volume with enabling RAID spanned over VMD enabling RAID spanned over VMD controller controller 2. Set Name. 3. Set RAID Level. 4. If cross-controller RAID is required, select Enable RAID spanned over VMD Controller. 5. Select specific disks for RAID with an [X]. •...

  • Page 120: Status Indications

    Chapter 6: Optional Components Status Indications An LED indicator on the drive carrier shows the RAID status of the drive. Drive Carrier Status LED Indicator Status State (red) Normal function Locating 4 Hz blink Fault Solid ON Rebuilding 1 Hz Blink IBPI SFF 8489 Defined Status LED States Hot-Swap Drives Intel VMD enables hot-plug and hot-unplug for NVMe SSDs, whether from Intel or other manufacturers.

  • Page 121: Chapter 7 Troubleshooting And Support

    Chapter 7: Troubleshooting and Support Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website. Products Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by clicking Products.

  • Page 122: Baseboard Management Controller (Bmc)

    Security Center for recent security notices Supermicro Phone and Addresses 7.2 Baseboard Management Controller (BMC) The system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring, and management. There are several BIOS settings that are related to BMC.

  • Page 123: Troubleshooting Procedures

    Chapter 7: Troubleshooting and Support 7.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. Always disconnect the AC power cables before adding, changing or installing any non hot-swap hardware components.

  • Page 124: Memory Errors

    2. Memory: Make sure that the memory modules are supported. Refer to the product page on our website at www.supermicro.com. Test the modules using memtest86 or a similar utility. Note: Click on the "Tested Memory List" link on the motherboard's product page to see a list of supported memory.
  • Page 125 Chapter 7: Troubleshooting and Support 5. Adequate power supply: Make sure that the power supply provides adequate power to the system. Make sure that all power connectors are connected. Please refer to our website for more information on the minimum power requirements. 6.

  • Page 126: Cmos Clear

    7.5 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com/.

  • Page 127: Technical Support Procedures

    Before contacting Technical Support, please take the following steps. Also, please note that as a motherboard manufacturer, Supermicro also sells motherboards through its channels, so it is best to first check with your distributor or reseller for troubleshooting services. They should know of any possible problems with the specific system configuration that was sold to you.

  • Page 128: Returning Merchandise For Service

    Shipping and handling charges will be applied for all orders that must be mailed when service is complete. For faster service, RMA authorizations may be requested online (http://www.supermicro.com/ support/rma/). This warranty only covers normal consumer use and does not cover damages incurred in shipping or from failure due to the alternation, misuse, abuse or improper maintenance of products.

  • Page 129: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 130: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 131 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 132 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 133 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 134 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 135 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
  • Page 136 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 137 Appendix A: Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 138 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 139 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 140 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 141 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 142 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 143 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 144 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 145 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 146 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 147 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 148 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 149 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 150: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Dual 4th Generation Intel® Xeon® Scalable processors in socket E LGA4189 with four UPIs and a thermal design power (TDP) up to 350W. Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel C741 PCH BIOS...
  • Page 151 Appendix B: System Specifications Power Supply Model: PWS-1K24A-1R, 1200W redundant modules, 80Plus Titanium level AC Input 800W: 100-127Vac / 50-60Hz 1200W: 200-240Vac / 50-60Hz +12V Max: 83A (100Vac-127Vac) Max: 166A (200Vac-220Vac) 12V SB Max: 2.1A / Min: 0A Model: PWS-1K63A-1R 1600W redundant modules, 80Plus Titanium level AC Input 1600W: 200-240Vac/50-60Hz 1000W: 100-127Vac/50-60Hz...
  • Page 152 Appendix B: System Specifications Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN 55032 BS/EN 55035 CISPR 32 CISPR 24/CISPR 35 BS/EN 61000-3-2 BS/EN 61000-3-3 BS/EN 61000-4-2 BS/EN 61000-4-3 BS/EN 61000-4-4 BS/EN 61000-4-5...

This manual is also suitable for:

Superserver sys-221h-tn24r

Table of Contents
