1.2 System Features
The following views of the system display the main features. Refer to
specifications.
Front View
Power LED
Drive Activity LED
Power Button
Feature
Power Button
Power LED and
Drive Activity LED
Figure 1-1. Front View
System Features: Front
Description
The main power switch applies or removes primary power from the power supply to the
server but maintains standby power. To perform most maintenance tasks, unplug the
system to remove all power.
Indicates power is being supplied to the system power supply units. This LED is
illuminated when the system is operating normally. Indicates storage disk drive activity
when flashing.
8
Chapter 1: Introduction
Appendix B
for additional
