DEMO MANUAL DC2815A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 7 C1, C2, C6-C8, C20-C21
2 1 C3
3 4 C4, C5, C29, C30
4 5 C9-C13
5 1 C22
6 1 C23
7 3 C24, C26, C28
8 1 C27
9 1 L1
10 1 R1
11 2 R2, R15
12 1 R3
13 1 R4
14 1 R5
15 1 R6
16 1 R7
17 3 R8, R9, R12
18 1 R16
19 1 R18
20 1 U1
Additional Demo Board Circuit Components
1 0 C14, C15
2 0 C16
3 0 C17
4 0 C18, C19
5 0 C25
6 0 L2
7 0 PCB1
8 0 R10, R11, R13, R14, R19 RES., OPTION, 0402
1 0 C14, C15
Hardware: For Demo Board Only
1 7 E1, E3, E5, E7, E9-E11
2 4 E2, E4, E6, E8
3 4 JP1-JP4
4 4 MP1-MP4
5 4 XJP1, XJP5-XJP7
6
PART DESCRIPTION
CAP ., 0.1µF, X7R, 25V, 10%, 0402, AEC-Q200
CAP ., 1µF, X7R, 50V, 10%, 0805
CAP ., 10µF, X5R, 50V, 10%, 1210
CAP ., 100µF, X5R, 10V, 20%, 1210
CAP ., 0.022µF, X7R, 16V, 10%, 0402
CAP ., 1200pF, X7R, 50V, 5%, 0603
CAP ., 27pF, C0G, 25V, 5%, 0603
CAP ., 4.7µF, X5R, 6.3V, 20%, 0603
IND., 3.3µH, PWR, SHIELDED, 20%, 15.1A, 9.42mΩ,
8mm × 7.7mm, AEC-Q200
RES., 49.9Ω, 1%, 1/16W, 0402, AEC-Q200
RES., 1M, 1%, 1/16W, 0402, AEC-Q200
RES., 187k, 1%, 1/16W, 0402
RES., 64.9k, 1%, 1/16W, 0402, AEC-Q200
RES., 75.0k, 1%, 1/16W, 0402
RES., 10k, 0.1%, 1/16W, 0402
RES., 0Ω, 1/16W, 0402, AEC-Q200
RES., 2M, 1%, 1/16W, 0402, AEC-Q200
RES., 1k, 1%, 1/16W, 0402
RES., 0.01Ω, 1%, 1W, 0805, HIGH PWR, METAL, SENSE,
AEC-Q200
IC, 26V, 9A SYNCHRONOUS BUCK-BOOST DC/DC CONVERTER
CAP ., OPTION, 1210
CAP ., 10µF, X5R, 50V, 20%, 1206, OPTION
CAP ., 330µF, ALUM, POLY, 35V, 20%, RADIAL, SMD, AEC-Q200,
OPTION
CAP ., OPTION, 0402
CAP ., OPTION, 0603
FIXED IND 1µH 11.5A 4.75MΩ, OPTION
PCB, DC2815A
CAP ., OPTION, 1210
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED, SWAGE,
0.218"
CONN., HDR, MALE, 1x3, 2mm, VERT, ST, THT
STANDOFF , NYLON, SNAP-ON, 0.375"
CONN., SHUNT, FEMALE, 2-POS, 2mm
MANUFACTURER/PART NUMBER
MURATA, GCM155R71E104KE02D
TAIYO YUDEN, UMK212B7105KG-T
TDK, C3225X5R1H106K250AB
KEMET, C1210C107M8PACTU
AVX, 0402YC223KAT2A
AVX, 06035C122JAT2A
MURATA, GQM1875C2E270JB12D
AVX, 06036D475MAT2A
COILCRAFT, XAL7070-332MEB
NIC, NRC04F49R9TRF
STACKPOLE ELECTRONICS, INC.,
RMCF0402FT1M00
VISHAY, CRCW0402187KFKED
NIC, NRC04F6492TRF
VISHAY, MCS04020C7502FE000
YAGEO, RT0402BRD0710KL
NIC, NRC04ZOTRF
VISHAY, CRCW04022M00FKED
NIC, NRC04F1001TRF
VISHAY, WSLP0805R0100FEA18
ANALOG DEVICES, INC., LT3120JV#PBF
TDK, C3216X5R1H106M160AB
PANASONIC, EEH-ZK1V331P
WURTH ELEKTRONIK, 744316100
MAO BANG, 600-DC2815A
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8832
SAMTEC, 2SN-BK-G
Rev. 0
