Quick start proceDure
100
98
96
94
92
90
88
86
84
82
80
0

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 CC1
2 1 CC2
3 2 CSS, C15
4 1 C11
5 1 C10
6 1 C24
7 2 CIN1, CIN2
8 2 COUT1, COUT2
9 6 C16, C17, C19-C21, C28
10 2 C4, C22
11 5 C9, C14, C25-C27
12 1 C18
13 2 D4, D7
14 2 D5, D6
15 1 D8
16 2 L1
17 3 Q2, Q4, Q6
1 2 3 4 5
LOAD CURRENT (A)
Figure 3. Efficiency vs Load Current (V
PART DESCRIPTION
CAP ., C0G, 100pF, 50V, 10% 0603
CAP ., X7R, 0.01µF, 50V, 10% 0603
CAP ., X7R, 0.1µF, 50V, 10% 0603
CAP ., NPO, 68pF, 50V, 10% 0603
CAP ., X5R, 2.2µF, 10V, 10% 0603
CAP ., X7R, 1µF, 16V, 20% 0603
CAP ., ALUM, 270µF, 50V, 20%
CAP ., OS-CON, 330µF, 16V, 20%
CAP ., X7R, 22µF, 16V, 20% 1210
CAP ., X7R, 0.22µF, 16V, 20% 0603
CAP ., X7R, 3.3µF, 50V, 20% 1210
CAP ., X5R, 10µF, 6.3V, 20% 1206
DIODE, SCHOTTKY 1A, 60V POWERDI123
DIODE, SCHOTTKY 3A, 40V SMA
DIODE, ZENER 5.1V 350MW SOT23-3
INDUCTOR, 3µH
MOSFET N-CHANNEL
DEMO MANUAL DC1757B
V
V
V
V
6 7 8 9 10
= 12V, CCM)
O
MANUFACTURER/PART NUMBER
AVX, 06035A101KAT2A
AVX, 06035C103KAT2A
AVX, 06035C104KAT2A
AVX, 06035A680KAT2A
AVX, 0603ZD225KAT2A
AVX, 0603YC105MAT2A
SUN ELECTRONICS, 50ME270WX+T
SANYO, 16SEP330M+T
AVX, 1210YC226MAT2A
AVX, 0603YC224MAT2A
AVX, 12105C335MAT2A
AVX, 12066D106MAT2A
DIODE INC., DFLS160-7
DIODE INC., B340A-13-F
DIODE INC., BZX84C5V1-7-F
COILCRAFT, XAL1580-302ME
INFINEON, BSC027N04LS G
= 6V
IN
= 12V
IN
= 24V
IN
= 36V
IN
11 12
dc1757bf
