DEMO MANUAL DC2658A

parts List

ITEM QTY
Required Circuit Components
1 2
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 2
11 1
12 1
13 1
14 1
15 1
Additional Demo Board Circuit Components
1 1
2 2
3 2
4 0
5 1
6 0
7 1
Hardware: For Demo Board Only
1 8
2 4
3 1
4 1
5 4
6 4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
C2, C12 CAP ., X5R, 1μF, 50V, 10%, 0603
C5 CAP ., C0G, 330pF, 50V, 5%, 0603
C6 CAP ., X5R, 100μF, 10V, 20% 1210
C8 CAP ., X7R, 0.1μF, 16V, 10%, 0603
C9 CAP ., X5R, 22μF, 10V, 20%, 0603
C16 CAP ., C0G, 4.7pF, 50V, ±0.1pF, 0603
C17 CAP ., X7R, 10μF, 50V, 10%, 1210
C20 CAP ., X7R, 1μF, 10V, 10%, 0603
L1 INDUCTOR,1.5μH
R1, R5 RES., CHIP , 100k, 1/10W, 1% 0603
R2 RES., CHIP , 17.8k, 1/10W, 1% 0603
R3 RES., CHIP , 243k, 1/10W, 1%, 0603
R4 RES., CHIP , 8.45k, 1/10W, 1%, 0603
R7 RES., CHIP , 1M, 1/10W, 1%, 0603
U1 I.C., STEP-DOWN SWITCHER, 4mm × 4mm LQFN
C1 CAP ., ALUM 22μF, 63V
C3, C10 CAP ., X7R, 10μF, 50V, 10%, 1210
C14, C21 CAP ., X7R, 0.1μF, 50V, 10%, 0402
C15, C18 (OPT) CAP ., OPTION, 0603
FB1 BEAD, FERRITE, 100Ω, 1812
R6 (OPT) RES., OPTION, 0603
R8 RES., CHIP , 0Ω, 1/10W, 1%, 0603
E1, E5-E9, E11, E14 TESTPOINT, TURRET, .094"
E2, E10, E12, E13 TESTPOINT, TURRET, .064"
JP1 2×4, 0.079 DOUBLE ROW HEADER
XJP1 SHUNT, .079" CENTER
J1-J4 JACK BANANA
MH1-MH4 STAND-OFF , NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM188R61H105KAALD
MURATA, GRM1885C1H331JA01D
MURATA, GRM32ER61A107ME20L
MURATA, GRM188R71C104KA01D
SAMSUNG, CL10A226MPMNUBE
MURATA, GRM1885C1H4R7BA01D
MURATA, GRM32ER71H106KA12L
MURATA, GRM188R71A105KA61D
COILCRAFT, XEL6030-152ME
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060317K8FKEA
VISHAY, CRCW0603243KFKEA
VISHAY, CRCW06038K45FKEA
VISHAY, CRCW06031M00FKEA
LINEAR TECH., LT8643SEV#PBF
SUN ELECT., 63CE22BS
MURATA, GRM32ER71H106KA12L
MURATA, GRM155R71H104KE14D
WURTH ELEKTRONIK, 74279226101
VISHAY, CRCW06030000Z0EA
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000821121
WURTH ELEKTRONIK, 60800213421
KEYSTONE, 575-4
WURTH ELEKTRONIK, 702935000
dc2658af
