DEMO MANUAL DC2228A

parts list

The table below lists components that comprise both the IO-Link physical interface and an optional enclosure. The
complete parts list is found here:
ITEM QTY REFERENCE
IO-Link Physical Interface Components
20 14 C36, C39–41, C75–76,
C99, C101, C103, C105,
C107, C109, C111, C113
21 1 C37
23 8 C100, C102, C104, C106,
C108, C110, C112, C114
41 8 D28–35
43 16 D37–52
50 8 J21–28
64 8 Q11–18
95 8 R59–66
96 2 R67–68
97 8 R69–76
102 1 R107
123 2 U7–8
Optional Enclosure
134 0 ----
135 0 ----
136 0 ----
137 0 ----
18
www.linear.com/demo/DC2228A
PART DESCRIPTION
CAP , 1µF, 10%, 50V, X7R, 1206
CAP , 220µF, 20%, 50V, 12H10 ELEC
CAP , 560pF, 5%, 100V, C0G, 0603
DIODE, SCHOTTKY, SMA_2C
DIODE, TVS, 36V, SMB_2C
CONNECTOR, M12, 5 PIN
XSTR, 100V N-CH MOSFET SOT-223
RES, 0.2Ω, 1%, 1206
RES, 4.7k, 1%, 0402
RES, 10Ω, 1%, 0603
RES, 1Ω, 1%, 0603
IC, QUAD IO-LINK MASTER
HOUSING, BASE
HOUSING, SIDE
HOUSING, FRONT PLATE
SHEET METAL SCREW, PAN PHILLIPS #6
MANUFACTURER/PART NUMBER
TDK, C3216X7R1H105K160AB
PANASONIC, EEE-FT1H221AP
TDK, C1608C0G2A561J080AA
FAIRCHILD, S100
STM, SM6T36A
PHOENIX, 1694237
FAIRCHILD, FQT7N10LTF
SUSUMU, RL1632R-R200-F
VISHAY, CRCW04024K70FKED
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW06031R00FKEA
LINEAR TECH, LTC2874IUHF
DIGI-KEY, 2200939-ND
DIGI-KEY, 2200952-ND
DIGI-KEY, 2200947-ND
dc2228afa
