DEMO MANUAL DC2668A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C3
4 3 E1-E3
5 2 J1, J2
6 1 J3
7 1 T1
8 1 U1
4
PART DESCRIPTION
CAP ., 18pF, C0G, 10V, 2%, 0402
CAP ., 18pF, C0G, 50V, 1%, 0402
CAP ., 1μF, X7R, 10V, 10%, 0603
TEST POINT, TURRET, 0.061" MTG. HOLE
CONN., SMA, 50Ω, EDGE-LAUNCH
CONN., SMA, 50Ω, EDGE-LAUNCH
XFMR., 1:1, 4.5-3000MHz
I.C., LTC5552IUDB, QFN 12 PIN, 3mm × 2mm
MANUFACTURER/PART NUMBER
AVX, 0402ZK180GBSTR
MURATA, GJM1555C1H180FB01
MURATA, GRM188R71A105KA61
MILL-MAX, 2308-2-00-80-00-00-07-0
E.F . JOHNSON, 142-0761-881
E.F . JOHNSON, 142-0701-851
MINI-CIRCUITS, TC1-1-13M+
LINEAR TECHNOLOGY, LTC5552IUDB#PBF
dc2668afa
