Parts List - Analog Devices Linear Technology DC2483A-B Demo Manual

PARTS LIST

ITEM QTY REFERENCE
DC2483A-A Required Circuit Components
1 5 C1-C3, C8, C9
2 3 C4, C6, C7
3 1 C5
4 2 C10, C11
5 1 C12
6 3 E1, E2, E3
7 3 J1-J3
8 3 L1-L3
9 1 L4
10 1 R1
11 1 T1
12 1 T2
13 1 U1
DC2483A-B Required Circuit Components
1 4 C1, C2, C4, C6
2 2 C3, C5
3 2 C7, C8
4 3 C9, C10, R1
5 2 C11, C12
6 1 C13
7 3 E1, E2, E3
8 3 J1, J2, J3
9 1 L1
10 2 L2, L3
11 1 T1
12 1 T2
13 1 U1
PART DESCRIPTION
CAP ., 1000pF, X7R, 50V, 10%, 0402
CAP ., 1.2pF, C0G, 50V, ±0.25pF, 0402
CAP ., 10pF, C0G, 50V, 5%, 0402
CAP ., 10nF, X7R, 50V, 10%, 0402
CAP ., 2.2µF, X5R, 10V, 10%, 0603
TEST POINT, TURRET, 0.064", MTG. HOLE
CONN., SMA, 50Ω EDGE-LAUNCH
IND., 3.6nH, 2%, 0402, WIRE-WOUND
IND., 1.5nH, ±0.3nH, 0402, MULTILAYER
RES., 0Ω JUMPER, 0402
XFMR, 1:1, 4.5MHz to 3000MHz
XFMR, 4:1, 3300MHz to 4200MHz
IC, LTC5562IUC, QFN 10-PIN, 2mm × 2mm
CAP ., 1000pF, X7R, 50V, 10%, 0402, SINGLE SOURCE ONLY
CAP ., OPTION, 0402
CAP ., OPTION, 0603
RES., 0Ω JUMPER, 0402
CAP ., 10nF, X7R, 50V, 10%, 0402, SINGLE SOURCE ONLY
CAP ., 2.2µF, X5R, 10V, 10%, 0603, SINGLE SOURCE ONLY
TEST POINT, TURRET, 0.064", MTG. HOLE
CONN., SMA, 50Ω EDGE-LAUNCH
IND., 7.5nH, 2%, 0402, WIRE-WOUND
IND., 100nH, 5%, 0402, WIRE-WOUND
XFMR, 1:1, 4.5MHz to 3000MHz
XFMR, 8:1, 2MHz to 500MHz
IC, LTC5562IUC, QFN 10-PIN, 2mm × 2mm
DEMO MANUAL
DC2483A-A/DC2483A-B
MANUFACTURER/PART NUMBER
MURATA GRM155R71H102KA01D
MURATA GJM1555C1H1R2CB01D
MURATA GRM1555C1H100JA01D
MURATA GRM155R71H103KA88D
MURATA GRM188R61A225KE34D
MILL-MAX 2308-2-00-80-00-00-07-0
CINCH CONNECTIVITY 142-0701-851
COILCRAFT 0402HP-3N6XGLW
MURATA LQG15HS1N5S02D
VISHAY CRCW04020000Z0ED
MINI-CIRCUITS TC1-1-13M+
MINI-CIRCUITS NCS4-442+
LINEAR TECH LTC5562IUC#PBF
MURATA, GRM155R71H102KA01D
DNI
DNI
VISHAY, CRCW04020000Z0ED
MURATA, GRM155R71H103KA88D
MURATA, GRM188R61A225KE34D
MILL-MAX, 2308-2-00-80-00-00-07-0
CINCH CONNECTIVITY, 142-0701-851
COILCRAFT, 0402HP-7N5XGLW
COILCRAFT, 0402AF-101XJL
MINI-CIRCUITS, TC1-1-13M+
MINI-CIRCUITS, TC8-1-10LN+
LINEAR TECH, LTC5562IUC#PBF
